Sub-CompactPerformance profile
Antonio Carraro TRX 7800S
The Antonio Carraro TRX 7800S is a powerful and compact tractor designed for versatile farm work. It features a Yanmar diesel engine with 4 cylinders and 16 valves, producing 71 hp at 2500 rpm. This engine is liquid-cooled and uses direct injection for efficient fuel use. The tractor has a 16-forward and 16-reverse gear transmission, giving the operator plenty of speed options. This tractor is built for maneuverability, with hydraulic power steering and compact dimensions. It measures 133.6 inches long, 54.3 inches wide, and 93.3 inches tall. Despite its small size, it packs a punch with an operating weight of 4806 lb. The TRX 7800S comes equipped with a rear Type I hitch, making it easy to attach various implements. It also features an electric starter for quick and easy engine starts, even in cold weather.
ManufacturerAntonio CarraroPower71 hpEngine4-cyl
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 71hp
- Operating Weight
- 4,806 lb
At a glance
How the TRX 7800S compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
71 hp · 99th
This model
4
Median 26.85 hp
49
71
This modelSub-Compact tractorsMediann = 816
The TRX 7800S ranks at the 99th percentile for engine power among recorded sub-compact tractors.
Overview
About the Antonio Carraro TRX 7800S
The Antonio Carraro TRX 7800S is a powerful and compact tractor designed for versatile farm work. It features a Yanmar diesel engine with 4 cylinders and 16 valves, producing 71 hp at 2500 rpm. This engine is liquid-cooled and uses direct injection for efficient fuel use. The tractor has a 16-forward and 16-reverse gear transmission, giving the operator plenty of speed options. This tractor is built for maneuverability, with hydraulic power steering and compact dimensions. It measures 133.6 inches long, 54.3 inches wide, and 93.3 inches tall. Despite its small size, it packs a punch with an operating weight of 4806 lb. The TRX 7800S comes equipped with a rear Type I hitch, making it easy to attach various implements. It also features an electric starter for quick and easy engine starts, even in cold weather.
Full specifications
Every recorded spec
General
| Manufacturer | Antonio Carraro |
|---|---|
| Model | TRX 7800S |
| Category | Sub-Compact tractor |
| Operating weight | 4,806lb |
Engine
| Make | Yanmar |
|---|---|
| Power | 71hp |
| Cylinders | 4 |
| Displacement | 202.5ci |
| Bore | 3.86in |
| Stroke | 4.33in |
Transmission
| Forward gears | 16 |
|---|---|
| Reverse gears | 16 |
Chassis & drive
| Steering | Hydraulic Power |
|---|
Dimensions
| Length | 133.6in |
|---|---|
| Width | 54.3in |
| Height | 93.3in |
| Operating weight | 4,806lb |
Head to head
TRX 7800S vs. Sub-Compact median
How the Antonio Carraro TRX 7800S compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 71 hp | 26.9 hp | +164% | 99th |
| Engine Displacement | 203 ci | 91.4 ci | +122% | 97th |
| Cylinders | 4 | 3 | +33% | 90th |
| Forward Gears | 16 | 9 | +78% | 89th |
| Operating Weight | 4,806 lb | 2,700 lb | +78% | 91st |
| Length | 134 in | 113 in | +18% | 85th |
| Width | 54.3 in | 50.7 in | +7% | 58th |
| Height | 93.3 in | 78.4 in | +19% | 82nd |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).
Compare to tractors with similar specs
Commonly compared Antonio Carraro tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro SX 7800S | 71 hp | 4,773 lb | — | Compare → |
| Antonio Carraro TGF 7800S | 71 hp | 5,093 lb | — | Compare → |
| Antonio Carraro TTR 7800 | 71 hp | 5,159 lb | — | Compare → |
| Antonio Carraro TX 7800S | 71 hp | 4,784 lb | — | Compare → |
| Antonio Carraro SRX 8400 | 70 hp | 4,486 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO GT65 | 71 hp | 5,335 lb | — | Compare → |
| Agco GT65A | 71 hp | 5,864.3 lb | — | Compare → |
| Belarus 572 | 71.62 hp | 9,146 lb | — | Compare → |
| Barreiros 7000 | 70 hp | 5,335 lb | — | Compare → |
| Belarus 560 | 70 hp | 6,700 lb | — | Compare → |
Explore
Antonio Carraro siblings
Explore
Similar-spec models
Gallery
Antonio Carraro TRX 7800S photos
FAQ
Common questions
How much horsepower does the Antonio Carraro TRX 7800S have?
The Antonio Carraro TRX 7800S produces 71 hp from its 4-cylinder engine. Engine displacement is 202.5 ci.
How much does the Antonio Carraro TRX 7800S weigh?
The Antonio Carraro TRX 7800S weighs about 4,806 lb in operating condition.
What maintenance does the Antonio Carraro TRX 7800S require?
Like any tractor, the Antonio Carraro TRX 7800S needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
