Utility
Belarus 5480
The Belarus 5480 is a powerful 4-wheel drive tractor built for tough farm work. It has a strong 4-cylinder diesel engine that doesn't need a turbocharger to perform well. The engine is liquid-cooled, which helps it stay at the right temperature while working hard. This tractor has a transmission with 14 forward gears and 4 reverse gears. This gives the driver lots of options for different speeds and tasks. The steering is hydrostatic power, making it easier to turn and control. The Belarus 5480 also has a Category II hitch at the back, which lets it connect to many different farm tools. It uses an open center hydraulic system to power these tools. The Belarus 5480 is made to handle big jobs on the farm. It has a sturdy 4x4 chassis and electric starter for easy use. While it may not have fancy features, it's a reliable workhorse that gets the job done.
ManufacturerBelarusEngine4-cylTransPartially synchronized
Quick specs
- Category
- Utility
- Transmission
- Partially synchronized
Overview
About the Belarus 5480
The Belarus 5480 is a powerful 4-wheel drive tractor built for tough farm work. It has a strong 4-cylinder diesel engine that doesn't need a turbocharger to perform well. The engine is liquid-cooled, which helps it stay at the right temperature while working hard. This tractor has a transmission with 14 forward gears and 4 reverse gears. This gives the driver lots of options for different speeds and tasks. The steering is hydrostatic power, making it easier to turn and control. The Belarus 5480 also has a Category II hitch at the back, which lets it connect to many different farm tools. It uses an open center hydraulic system to power these tools. The Belarus 5480 is made to handle big jobs on the farm. It has a sturdy 4x4 chassis and electric starter for easy use. While it may not have fancy features, it's a reliable workhorse that gets the job done.
Full specifications
Every recorded spec
General
| Manufacturer | Belarus |
|---|---|
| Model | 5480 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
Engine
| Make | Belarus |
|---|---|
| Cylinders | 4 |
| Displacement | 289.9ci |
| Bore | 4.33in |
| Stroke | 4.92in |
Transmission
| Type | Partially synchronized |
|---|---|
| Forward gears | 14 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Open Center |
|---|
Head to head
5480 vs. Utility median
How the Belarus 5480 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 290 ci | 183 ci | +58% | 84th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 14 | 12 | +17% | 63rd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,941–5,720 models).
Compare to tractors with similar specs
Commonly compared Belarus tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Belarus 1025 MIG | 115 hp | 9,469 lb | — | Compare → |
| Belarus 1052 | 105 hp | 7,209 lb | — | Compare → |
| Belarus 1221 MIG | 130 hp | 11,350 lb | — | Compare → |
| Belarus 1507 | 165 hp | 20,283 lb | — | Compare → |
| Belarus 1770 | 185 hp | 19,585 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
Belarus siblings
Explore
Similar-spec models
Gallery
Belarus 5480 photos
FAQ
Common questions
What engine configuration does the Belarus 5480 use?
The Belarus 5480 is equipped with a 4-cylinder engine displacing 289.9 ci.
What transmission is in the Belarus 5480?
Transmission on the Belarus 5480 is Partially synchronized, with 14 forward speeds.
What hydraulics does the Belarus 5480 have?
The Belarus 5480 uses an Open Center hydraulic system.
What three-point hitch category does the Belarus 5480 use?
The Belarus 5480 has a Category II three-point hitch.
What maintenance does the Belarus 5480 require?
Like any tractor, the Belarus 5480 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
