AgriculturalPerformance profile
Belarus MTZ-505
The Belarus MTZ-505 is a versatile 2WD tractor designed for agricultural use. It features a 4-cylinder D60 engine manufactured by Belarus, delivering 67 hp at 1800 rpm. This power output is suitable for a wide range of farming tasks. The engine has a displacement of 289.8 ci, with a bore of 4.331 inches and a stroke of 4.921 inches. The MTZ-505 comes equipped with a 9-speed transmission, offering 9 forward gears and 2 reverse gears. This gives operators good control over speed and power in various field conditions. The tractor's hydrostatic power steering ensures easy maneuverability, while its 4x2 chassis provides a stable platform for work. It rides on agricultural tires, with 7.50-20 sizes in front and larger 13.6-38 sizes in the rear. The tractor measures 151.6 inches in length and stands 109.8 inches tall, with an operating weight of 7607 lb, making it a mid-sized option for farms of various scales.
ManufacturerBelarusPower67 hpEngine4-cylTrans9-Speed
Quick specs
- Category
- Agricultural
- Engine Power Output
- 67hp
- Operating Weight
- 7,607 lb
- Transmission
- 9-Speed
At a glance
How the MTZ-505 compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
67 hp · 17th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The MTZ-505 ranks at the 17th percentile for engine power among recorded agricultural tractors.
Overview
About the Belarus MTZ-505
The Belarus MTZ-505 is a versatile 2WD tractor designed for agricultural use. It features a 4-cylinder D60 engine manufactured by Belarus, delivering 67 hp at 1800 rpm. This power output is suitable for a wide range of farming tasks. The engine has a displacement of 289.8 ci, with a bore of 4.331 inches and a stroke of 4.921 inches. The MTZ-505 comes equipped with a 9-speed transmission, offering 9 forward gears and 2 reverse gears. This gives operators good control over speed and power in various field conditions. The tractor's hydrostatic power steering ensures easy maneuverability, while its 4x2 chassis provides a stable platform for work. It rides on agricultural tires, with 7.50-20 sizes in front and larger 13.6-38 sizes in the rear. The tractor measures 151.6 inches in length and stands 109.8 inches tall, with an operating weight of 7607 lb, making it a mid-sized option for farms of various scales.
Full specifications
Every recorded spec
General
| Manufacturer | Belarus |
|---|---|
| Model | MTZ-505 |
| Category | Agricultural tractor |
| Type | 4x2 2WD |
| Operating weight | 7,607lb |
Engine
| Make | Belarus |
|---|---|
| Model | D60 |
| Power | 67hp |
| Cylinders | 4 |
| Displacement | 289.8ci |
| Bore | 4.33in |
| Stroke | 4.92in |
Transmission
| Type | 9-Speed |
|---|---|
| Forward gears | 9 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Hydrostatic Power |
Dimensions
| Length | 151.6in |
|---|---|
| Height | 109.8in |
| Operating weight | 7,607lb |
Tires
| Front | 7.50-20 |
|---|---|
| Rear | 13.6-38 |
Head to head
MTZ-505 vs. Agricultural median
How the Belarus MTZ-505 compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 67 hp | 110 hp | -39% | 17th |
| Engine Displacement | 290 ci | 336 ci | -14% | 44th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 9 | 16 | -44% | 20th |
| Operating Weight | 7,607 lb | 10,914 lb | -30% | 28th |
| Length | 152 in | 173 in | -12% | 27th |
| Height | 110 in | 111 in | -1% | 48th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 795–1,130 models).
Compare to tractors with similar specs
Commonly compared Belarus tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Belarus 650 | 67 hp | 8,800 lb | — | Compare → |
| Belarus 652 | 67 hp | 8,800 lb | — | Compare → |
| Belarus MTZ-500 | 67 hp | 6,769 lb | — | Compare → |
| Belarus 6311 | 65 hp | 8,100 lb | — | Compare → |
| Belarus 560 | 70 hp | 6,700 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Barreiros 5500 | 67 hp | — | — | Compare → |
| Antonio Carraro SRX 8400 | 70 hp | 4,486 lb | — | Compare → |
| Barreiros 70.7 | 64 hp | 5,450 lb | — | Compare → |
| Barreiros 7000 | 70 hp | 5,335 lb | — | Compare → |
| Allis Chalmers 6060 | 63.21 hp | 6,465 lb | 1980–1984 | Compare → |
Explore
Belarus siblings
Explore
Similar-spec models
Gallery
Belarus MTZ-505 photos
FAQ
Common questions
How much horsepower does the Belarus MTZ-505 have?
The Belarus MTZ-505 produces 67 hp from its 4-cylinder engine. Engine displacement is 289.8 ci.
How much does the Belarus MTZ-505 weigh?
The Belarus MTZ-505 weighs about 7,607 lb in operating condition.
What transmission is in the Belarus MTZ-505?
Transmission on the Belarus MTZ-505 is 9-Speed, with 9 forward speeds.
What size tires does the Belarus MTZ-505 use?
Factory rubber for the Belarus MTZ-505 is 7.50-20 front tires and 13.6-38 rear tires.
What maintenance does the Belarus MTZ-505 require?
Like any tractor, the Belarus MTZ-505 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
