Utility
Branson 4225C
The Branson 4225C is a versatile utility tractor designed for various farming tasks. It features a 4WD drive system with power steering, making it easy to maneuver in different terrains. The tractor is equipped with a 12-forward and 12-reverse shuttle transmission, offering plenty of options for different work speeds. Under the hood, the 4225C boasts a Kukje A2000N2-UTR4 diesel engine. This 4-cylinder, naturally aspirated engine has a displacement of 127.2 ci, which is below average for its class. It runs at a high rated speed of 2600 rpm, allowing for efficient operation. The tractor weighs 4221 lb, putting it in the mid-range for utility tractors. It comes with a comfortable cab for the operator and uses an open center hydraulic system. The 4225C also features a Category I rear hitch, making it compatible with a wide range of implements. With its Tier IV emissions technology, this tractor meets modern environmental standards while providing reliable performance for farmers and landowners.
ManufacturerBransonEngine4-cylTransShuttle
Quick specs
- Category
- Utility
- Operating Weight
- 4,221 lb
- Transmission
- Shuttle
Overview
About the Branson 4225C
The Branson 4225C is a versatile utility tractor designed for various farming tasks. It features a 4WD drive system with power steering, making it easy to maneuver in different terrains. The tractor is equipped with a 12-forward and 12-reverse shuttle transmission, offering plenty of options for different work speeds. Under the hood, the 4225C boasts a Kukje A2000N2-UTR4 diesel engine. This 4-cylinder, naturally aspirated engine has a displacement of 127.2 ci, which is below average for its class. It runs at a high rated speed of 2600 rpm, allowing for efficient operation. The tractor weighs 4221 lb, putting it in the mid-range for utility tractors. It comes with a comfortable cab for the operator and uses an open center hydraulic system. The 4225C also features a Category I rear hitch, making it compatible with a wide range of implements. With its Tier IV emissions technology, this tractor meets modern environmental standards while providing reliable performance for farmers and landowners.
Full specifications
Every recorded spec
General
| Manufacturer | Branson |
|---|---|
| Model | 4225C |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 4,221lb |
Engine
| Make | Kukje |
|---|---|
| Model | A2000N2-UTR4 |
| Cylinders | 4 |
| Displacement | 127.2ci |
| Bore | 3.31in |
| Stroke | 3.7in |
Transmission
| Type | Shuttle |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Cab |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Height | 96.8in |
|---|---|
| Operating weight | 4,221lb |
Capacities
| Cooling system | 1.6gal |
|---|
Head to head
4225C vs. Utility median
How the Branson 4225C compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 127 ci | 183 ci | -31% | 30th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 4,221 lb | 5,303 lb | -20% | 40th |
| Height | 96.8 in | 94.1 in | +3% | 57th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,321–5,720 models).
Compare to tractors with similar specs
Commonly compared Branson tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Branson 1905 | 19 hp | 1,433 lb | — | Compare → |
| Branson 2205h | 21.5 hp | 1,433 lb | — | Compare → |
| Branson 2400 | 24 hp | 1,958 lb | 2007+ | Compare → |
| Branson 2400H | 24 hp | 1,810 lb | — | Compare → |
| Branson 2505h | 21.5 hp | 1,638 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
Branson siblings
Explore
Similar-spec models
Gallery
Branson 4225C photos
FAQ
Common questions
What engine configuration does the Branson 4225C use?
The Branson 4225C is equipped with a 4-cylinder engine displacing 127.2 ci.
What hydraulics does the Branson 4225C have?
The Branson 4225C uses an Open Center hydraulic system.
What three-point hitch category does the Branson 4225C use?
The Branson 4225C has a Category I three-point hitch.
What is the working weight of the Branson 4225C?
The operating weight of the Branson 4225C is approximately 4,221 lb.
What type of transmission does the Branson 4225C have?
The Branson 4225C uses a Shuttle transmission offering 12 forward gears.
What routine service does the Branson 4225C need?
Regular maintenance for the Branson 4225C includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
