CaseIH 485
The CaseIH 485 is a utility tractor built for everyday farm work. It has a 2WD drive system and hydrostatic power steering, making it easy to control. The tractor uses a synchromesh transmission with 8 forward gears and 4 reverse gears, giving drivers plenty of options for different tasks. Under the hood, the CaseIH 485 has a 3-cylinder diesel engine made by CaseIH. The engine is liquid-cooled and has average displacement for its class at 179 ci. It produces 53 hp at 2200 rpm, which is about average power for utility tractors. The tractor weighs 5200 lb and has a three-point hitch at the rear, compatible with Category I and II implements. It uses an open center hydraulic system, common for tractors of this type.
ManufacturerCaseIHPower53 hpEngine3-cylTransSynchromesh
Quick specs
- Category
- Utility
- Engine Power Output
- 53hp
- Operating Weight
- 5,200 lb
- Transmission
- Synchromesh
At a glance
How the 485 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
53 hp · 48th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 485 ranks at the 48th percentile for engine power among recorded utility tractors.
Overview
About the CaseIH 485
The CaseIH 485 is a utility tractor built for everyday farm work. It has a 2WD drive system and hydrostatic power steering, making it easy to control. The tractor uses a synchromesh transmission with 8 forward gears and 4 reverse gears, giving drivers plenty of options for different tasks. Under the hood, the CaseIH 485 has a 3-cylinder diesel engine made by CaseIH. The engine is liquid-cooled and has average displacement for its class at 179 ci. It produces 53 hp at 2200 rpm, which is about average power for utility tractors. The tractor weighs 5200 lb and has a three-point hitch at the rear, compatible with Category I and II implements. It uses an open center hydraulic system, common for tractors of this type.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | 485 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 5,200lb |
Engine
| Make | CaseIH |
|---|---|
| Model | D-179 |
| Power | 53hp |
| Cylinders | 3 |
| Displacement | 179ci |
| Bore | 3.88in |
| Stroke | 5.06in |
Transmission
| Type | Synchromesh |
|---|---|
| Forward gears | 8 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 141.6in |
|---|---|
| Width | 73.2in |
| Height | 93.5in |
| Operating weight | 5,200lb |
Tires
| Front | 6.00-16 |
|---|---|
| Rear | 13.6-28 |
Head to head
485 vs. Utility median
How the CaseIH 485 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 53 hp | 55 hp | -4% | 48th |
| Engine Displacement | 179 ci | 183 ci | -2% | 48th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 5,200 lb | 5,303 lb | -2% | 49th |
| Length | 142 in | 137 in | +4% | 57th |
| Width | 73.2 in | 66 in | +11% | 68th |
| Height | 93.5 in | 94.1 in | -1% | 49th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH 3220 | 53 hp | 5,617 lb | — | Compare → |
| CaseIH 495 | 53 hp | 5,200 lb | — | Compare → |
| CaseIH C50 | 53 hp | 7,595 lb | 1998–2002 | Compare → |
| CaseIH 485XL | 52 hp | 5,620 lb | — | Compare → |
| CaseIH CS 52 | 52 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Agco ST52a | 52.1 hp | 3,494.4 lb | — | Compare → |
| AGCO GT45 | 52 hp | 4,806 lb | — | Compare → |
| Agco GT45A | 52 hp | 5,820.3 lb | — | Compare → |
| Barreiros 50.55 | 52 hp | 5,100 lb | — | Compare → |
| Barreiros R-500 | 52 hp | — | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH 485 photos
FAQ
Common questions
What is the engine power output of the CaseIH 485?
Rated engine output for the CaseIH 485 is 53 hp, delivered by a 3-cylinder engine. The engine displaces 179 ci.
What size tires does the CaseIH 485 use?
Factory rubber for the CaseIH 485 is 6.00-16 front tires and 13.6-28 rear tires.
What hitch category is the CaseIH 485?
The CaseIH 485 uses a Category I,II hitch.
What is the operating weight of the CaseIH 485?
In working trim, the CaseIH 485 comes in at roughly 5,200 lb.
Which transmission does the CaseIH 485 use?
The CaseIH 485 is equipped with a Synchromesh transmission with 8 forward gears.
What type of hydraulic system does the CaseIH 485 use?
Hydraulics on the CaseIH 485 are Open center.
How do I maintain a CaseIH 485?
Routine service for the CaseIH 485 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
