Row CropPerformance profile
CaseIH Magnum 245
The CaseIH Magnum 245 is a powerful row crop tractor built for tough farm work. It has a strong four-wheel drive system and a full powershift transmission with 23 forward gears and 6 reverse gears. This gives farmers lots of options when working in different field conditions. Under the hood, the Magnum 245 has a big 6-cylinder diesel engine made by CNH. The engine is turbocharged and intercooled, which helps it make 248 horsepower. This is a very high power output compared to many other tractors. The engine size is also above average at 504.5 cubic inches. The tractor weighs 21,010 pounds, which is heavy enough to handle big jobs. It has a cab for the driver's comfort and uses power steering to make it easier to control. The hydraulic system is pressure-flow compensated (PFC) for smooth operation of attachments.
ManufacturerCaseIHPower248 hpEngine6-cylTransFull powershift
Quick specs
- Category
- Row Crop
- Engine Power Output
- 248hp
- Operating Weight
- 21,010 lb
- Transmission
- Full powershift
At a glance
How the Magnum 245 compares
vs. Row Crop medianDistribution
Engine Power (hp)
Across all Row Crop tractors
248 hp · 87th
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The Magnum 245 ranks at the 87th percentile for engine power among recorded row crop tractors.
Overview
About the CaseIH Magnum 245
The CaseIH Magnum 245 is a powerful row crop tractor built for tough farm work. It has a strong four-wheel drive system and a full powershift transmission with 23 forward gears and 6 reverse gears. This gives farmers lots of options when working in different field conditions. Under the hood, the Magnum 245 has a big 6-cylinder diesel engine made by CNH. The engine is turbocharged and intercooled, which helps it make 248 horsepower. This is a very high power output compared to many other tractors. The engine size is also above average at 504.5 cubic inches. The tractor weighs 21,010 pounds, which is heavy enough to handle big jobs. It has a cab for the driver's comfort and uses power steering to make it easier to control. The hydraulic system is pressure-flow compensated (PFC) for smooth operation of attachments.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | Magnum 245 |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 21,010lb |
Engine
| Make | CNH |
|---|---|
| Power | 248hp |
| Cylinders | 6 |
| Displacement | 504.5ci |
| Bore | 4.49in |
| Stroke | 5.32in |
Transmission
| Type | Full powershift |
|---|---|
| Forward gears | 23 |
| Reverse gears | 6 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | Four-Wheel Drive (4WD) |
| Steering | Power |
| Cab | Cab |
Hydraulics
| Type | PFC |
|---|
Dimensions
| Height | 128.5in |
|---|---|
| Operating weight | 21,010lb |
Capacities
| Cooling system | 6gal |
|---|
Head to head
Magnum 245 vs. Row Crop median
How the CaseIH Magnum 245 compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 248 hp | 138 hp | +80% | 87th |
| Engine Displacement | 505 ci | 391 ci | +29% | 87th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 23 | 16 | +44% | 74th |
| Operating Weight | 21,010 lb | 12,307 lb | +71% | 86th |
| Height | 129 in | 114 in | +13% | 88th |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 1,140–1,417 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH MX245 Magnum | 248 hp | 21,185 lb | — | Compare → |
| CaseIH Magnum 250 | 252 hp | 20,140 lb | — | Compare → |
| CaseIH Magnum 240 | 240 hp | 22,305 lb | — | Compare → |
| CaseIH Puma 240 | 240 hp | 16,800 lb | — | Compare → |
| CaseIH Magnum 260 | 257 hp | 27,180 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Big Bud HN250 | 250 hp | 34,000 lb | — | Compare → |
| Caterpillar D7G SA Special Application | 250 hp | 40,700 lb | — | Compare → |
| AGCO DT205B | 242.3 hp | 25,840 lb | 2009–2010 | Compare → |
| Challenger MT645C | 242.3 hp | 25,795 lb | — | Compare → |
| Caterpillar AG6 | 240 hp | 32,600 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Similar specGallery
CaseIH Magnum 245 photos
FAQ
Common questions
What is the engine power output of the CaseIH Magnum 245?
Rated engine output for the CaseIH Magnum 245 is 248 hp, delivered by a 6-cylinder engine. The engine displaces 504.5 ci.
Which transmission does the CaseIH Magnum 245 use?
The CaseIH Magnum 245 is equipped with a Full powershift transmission with 23 forward gears.
What type of hydraulic system does the CaseIH Magnum 245 use?
Hydraulics on the CaseIH Magnum 245 are PFC.
What is the operating weight of the CaseIH Magnum 245?
In working trim, the CaseIH Magnum 245 comes in at roughly 21,010 lb.
How do I maintain a CaseIH Magnum 245?
Routine service for the CaseIH Magnum 245 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
