CaseIH MX200 Magnum
The CaseIH MX200 Magnum is a powerful row crop tractor built for serious farming. It has a 2WD drive system and a strong 6-cylinder diesel engine made by CDC. This engine is turbocharged and has a very high displacement of 504.5 ci, making it one of the biggest in its class. The tractor runs at 2000 rpm, which is lower than average, potentially saving fuel. This Magnum model is heavy, weighing 19,660 lb, which is above average for tractors like this. It has a full power shift transmission with 18 forward gears and 4 reverse gears, giving farmers lots of options for different tasks. The tractor uses big ag tires, with 11.00-24 in the front and 18.4R46 in the back. It has a Category III and IIIN hitch at the rear for attaching various farm tools. The hydraulic system is pressure-flow compensated (PFC), which helps manage the tractor's power efficiently. Special features include an air cleaner with dual paper elements and wet disc clutches that are controlled electronically and hydraulically.
Key specifications
- Category
- Row Crop
- Operating weight
- 19,660 lb
- Transmission
- Full power shift
Overview
About the CaseIH MX200 Magnum
The CaseIH MX200 Magnum is a powerful row crop tractor built for serious farming. It has a 2WD drive system and a strong 6-cylinder diesel engine made by CDC. This engine is turbocharged and has a very high displacement of 504.5 ci, making it one of the biggest in its class. The tractor runs at 2000 rpm, which is lower than average, potentially saving fuel. This Magnum model is heavy, weighing 19,660 lb, which is above average for tractors like this. It has a full power shift transmission with 18 forward gears and 4 reverse gears, giving farmers lots of options for different tasks. The tractor uses big ag tires, with 11.00-24 in the front and 18.4R46 in the back. It has a Category III and IIIN hitch at the rear for attaching various farm tools. The hydraulic system is pressure-flow compensated (PFC), which helps manage the tractor's power efficiently. Special features include an air cleaner with dual paper elements and wet disc clutches that are controlled electronically and hydraulically.
Full specifications
Recorded specifications
General
| Manufacturer | CaseIH |
|---|---|
| Model | MX200 Magnum |
| Category | Row Crop tractor |
| Type | 4x2 2WD |
| Operating weight | 19,660lb(8,918 kg) |
Engine
| Make | CDC |
|---|---|
| Cylinders | 6 |
| Displacement | 504.5ci(8.27 L) |
| Bore | 4.49in(114 mm) |
| Stroke | 5.32in(135 mm) |
Transmission
| Type | Full power shift |
|---|---|
| Forward gears | 18 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
Hydraulics
| Type | PFC |
|---|
Dimensions
| Operating weight | 19,660lb(8,918 kg) |
|---|
Tires
| Front | 11.00-24Convert |
|---|---|
| Rear | 18.4R46Convert |
Calculators
Calculators for the MX200 Magnum
Category medians
MX200 Magnum vs. Row Crop median
CaseIH MX200 Magnum compared with other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 505 ci | 391 ci | +29% | 87th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 18 | 16 | +13% | 61st |
| Operating Weight | 19,660 lb | 12,307 lb | +60% | 83rd |
Medians and percentiles are calculated from the row crop tractors in the database that have a recorded value for each specification (sample size 1,200–1,417 models).
Same manufacturer
Other CaseIH models
Other manufacturers
Models with similar horsepower
Gallery
CaseIH MX200 Magnum photos
FAQ
Frequently asked questions
How many cylinders does the CaseIH MX200 Magnum have?
The CaseIH MX200 Magnum runs a 6-cylinder engine with a displacement of 504.5 ci.
What hitch category is the CaseIH MX200 Magnum?
The CaseIH MX200 Magnum uses a Category III, IIIN hitch.
What is the operating weight of the CaseIH MX200 Magnum?
The CaseIH MX200 Magnum has an operating weight of about 19,660 lb.
Which transmission does the CaseIH MX200 Magnum use?
The CaseIH MX200 Magnum is equipped with a Full power shift transmission with 18 forward gears.
What type of hydraulic system does the CaseIH MX200 Magnum use?
Hydraulics on the CaseIH MX200 Magnum are PFC.
What size tires does the CaseIH MX200 Magnum use?
The CaseIH MX200 Magnum is fitted with 11.00-24 front tires and 18.4R46 rear tires from the factory.
How do I maintain a CaseIH MX200 Magnum?
Routine service for the CaseIH MX200 Magnum covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
