CaseIH Steiger 330
The CaseIH Steiger 330 is a powerful utility tractor built for tough jobs. It has a strong four-wheel drive system and can turn easily with its special steering. The tractor has a big engine made by CNH that runs on diesel fuel. This engine is very powerful, giving the Steiger 330 a high 330 horsepower rating. This tractor is heavy, weighing 32,295 pounds, which helps it work well in tough conditions. It has a full power shift transmission with 16 forward gears and 2 reverse gears, making it easy to change speeds. The Steiger 330 also has a good hydraulic system and a sturdy hitch for attaching tools. It uses big agricultural tires that help it grip the ground well. With its high power and weight, this CaseIH tractor is ready for big farming tasks.

Key specifications
- Category
- Utility
- Engine power
- 330hp
- Operating weight
- 32,295 lb
- Transmission
- Full Power Shift
Category comparison
Steiger 330 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
This model
The Steiger 330 ranks at the 97th percentile for engine power among recorded utility tractors.
Overview
About the CaseIH Steiger 330
The CaseIH Steiger 330 is a powerful utility tractor built for tough jobs. It has a strong four-wheel drive system and can turn easily with its special steering. The tractor has a big engine made by CNH that runs on diesel fuel. This engine is very powerful, giving the Steiger 330 a high 330 horsepower rating. This tractor is heavy, weighing 32,295 pounds, which helps it work well in tough conditions. It has a full power shift transmission with 16 forward gears and 2 reverse gears, making it easy to change speeds. The Steiger 330 also has a good hydraulic system and a sturdy hitch for attaching tools. It uses big agricultural tires that help it grip the ground well. With its high power and weight, this CaseIH tractor is ready for big farming tasks.
Full specifications
Recorded specifications
General
| Manufacturer | CaseIH |
|---|---|
| Model | Steiger 330 |
| Category | Utility tractor |
| Type | 4x4 articulated 4WD |
| Operating weight | 32,295lb(14,650 kg) |
Engine
| Make | CNH |
|---|---|
| Power | 330hp(246.1 kW) |
| Cylinders | 6 |
| Displacement | 540ci(8.85 L) |
| Bore | 4.49in(114 mm) |
| Stroke | 5.69in(144.5 mm) |
Transmission
| Type | Full Power Shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x4 articulated 4WD |
|---|---|
| Drive | Four-wheel Drive (4WD) |
| Steering | Articulated Power Steering |
Hydraulics
| Type | PFC |
|---|
Dimensions
| Operating weight | 32,295lb(14,650 kg) |
|---|
Closest alternatives
Steiger 330 compared with the nearest models by horsepower
The closest utility models to the CaseIH Steiger 330 by rated horsepower are the CaseIH STX330 and the Fiat 44-33. The CaseIH STX330 matches it on rated power at almost the same operating weight. The Fiat 44-33 matches it on rated power and weighs 2,970 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. Of the 3 models, the Steiger 330 has the highest weight per horsepower at 98 lb per hp.
| Spec | CaseIH Steiger 330 | CaseIH STX330 | Fiat 44-33 |
|---|---|---|---|
| Engine power | 330 hp246.1 kW | 330 hp246.1 kW | 330 hp246.1 kW |
| Operating weight | 32,295 lb14,649 kg | 32,295 lb14,649 kg | 29,326 lb13,302 kg |
| Weight per hp | 98 lb/hp60 kg/kW | 98 lb/hp60 kg/kW | 89 lb/hp54 kg/kW |
| Displacement | 540 ci8.85 L | 540 ci8.85 L | 903.1 ci14.8 L |
| Cylinders | 6 | 6 | 8 |
| Transmission | Full Power Shift | Full Power Shift | Manual |
| Drive | Four-wheel Drive (4WD) | Four-wheel drive (4WD) | 4WD |
Calculators
Calculators for the Steiger 330
PTO power
About 274 to 297 PTO hp
Estimated from the 330 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 330 hp tractor can run
Maximum size is about a 39 ft rotary cutter or a 33.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
114 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
330 hp is 246.1 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the CaseIH Steiger 330
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the CNHAmazon
Fits the CNH 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the CNHAmazon
Fits the CNH 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the CNHAmazon
Fits the CNH 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the CNHAmazon
Fits the CNH 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- CaseIH Steiger 330 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- CaseIH Steiger 330 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- CaseIH Steiger 330 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Steiger 330 vs. Utility median
CaseIH Steiger 330 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 330 hp | 55 hp | +500% | 97th |
| Engine Displacement | 540 ci | 183 ci | +195% | 94th |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 32,295 lb | 5,303 lb | +509% | 98th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 4,941–5,720 models).
Same manufacturer
Other CaseIH models
Other manufacturers
Models with similar horsepower
Gallery
CaseIH Steiger 330 photos




FAQ
Frequently asked questions
How much horsepower does the CaseIH Steiger 330 have?
The CaseIH Steiger 330 produces 330 hp from its 6-cylinder engine. Engine displacement is 540 ci.
How much does the CaseIH Steiger 330 weigh?
The CaseIH Steiger 330 weighs about 32,295 lb in operating condition.
What transmission is in the CaseIH Steiger 330?
Transmission on the CaseIH Steiger 330 is Full Power Shift, with 16 forward speeds.
What hydraulics does the CaseIH Steiger 330 have?
The CaseIH Steiger 330 uses a PFC hydraulic system.
What maintenance does the CaseIH Steiger 330 require?
The CaseIH Steiger 330 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
