Brand siblingStandard Tread
Caterpillar Twenty-Two
The Caterpillar Twenty-Two is a classic tractor built for tough farm work. It has a 4.1L 4-cylinder gasoline engine made by Caterpillar. This engine has 251 cubic inches of displacement and runs at 1250 RPM. The tractor uses a Zenith K5A Carburetor to mix fuel and air. The Twenty-Two has a gear transmission with 3 forward gears and 1 reverse gear. It's steered using manual clutches, which gives the driver good control. The tractor is 108 inches long, 57.75 inches wide, and 56.125 inches tall. It weighs 6200 pounds, making it a sturdy machine for farm tasks. The engine's cooling system holds 20 quarts of coolant to keep it running smoothly.
ManufacturerCaterpillarEngine4-cylTransGear
Quick specs
- Category
- Standard Tread
- Operating Weight
- 6,200 lb
- Transmission
- Gear
Overview
About the Caterpillar Twenty-Two
The Caterpillar Twenty-Two is a classic tractor built for tough farm work. It has a 4.1L 4-cylinder gasoline engine made by Caterpillar. This engine has 251 cubic inches of displacement and runs at 1250 RPM. The tractor uses a Zenith K5A Carburetor to mix fuel and air. The Twenty-Two has a gear transmission with 3 forward gears and 1 reverse gear. It's steered using manual clutches, which gives the driver good control. The tractor is 108 inches long, 57.75 inches wide, and 56.125 inches tall. It weighs 6200 pounds, making it a sturdy machine for farm tasks. The engine's cooling system holds 20 quarts of coolant to keep it running smoothly.
Full specifications
Every recorded spec
General
| Manufacturer | Caterpillar |
|---|---|
| Model | Twenty-Two |
| Category | Standard Tread tractor |
| Operating weight | 6,200lb |
Engine
| Make | Caterpillar |
|---|---|
| Model | 4.1L 4-cyl |
| Cylinders | 4 |
| Displacement | 251ci |
| Bore | 4in |
| Stroke | 5in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 3 |
| Reverse gears | 1 |
Chassis & drive
| Steering | Manual Clutches |
|---|
Dimensions
| Length | 108in |
|---|---|
| Width | 57.75in |
| Height | 56.13in |
| Operating weight | 6,200lb |
Capacities
| Cooling system | 5gal |
|---|
Head to head
Twenty-Two vs. Standard Tread median
How the Caterpillar Twenty-Two compares to other Standard Tread tractors
| Spec | This model | Standard Tread median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 251 ci | 382 ci | -34% | 22nd |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 3 | 4 | -25% | 39th |
| Operating Weight | 6,200 lb | 6,834 lb | -9% | 40th |
| Length | 108 in | 137 in | -21% | 7th |
| Width | 57.8 in | 72.4 in | -20% | 11th |
| Height | 56.1 in | 72.3 in | -22% | 7th |
Medians and percentiles are computed from the standard tread tractors in our database with a recorded value for each spec (sample sizes 233–367 models).
Compare to tractors with similar specs
Commonly compared Caterpillar tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Caterpillar Diesel Thirty-Five | — | — | — | Compare → |
| Caterpillar Forty | — | 13,625 lb | — | Compare → |
| Caterpillar Sixty | — | 19,000 lb | — | Compare → |
| Caterpillar Thirty | — | — | — | Compare → |
| Caterpillar Twenty-Five | — | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
Caterpillar siblings
Explore
Similar-spec models
Gallery
Caterpillar Twenty-Two photos
FAQ
Common questions
What engine configuration does the Caterpillar Twenty-Two use?
The Caterpillar Twenty-Two is equipped with a 4-cylinder engine displacing 251 ci.
What is the working weight of the Caterpillar Twenty-Two?
The operating weight of the Caterpillar Twenty-Two is approximately 6,200 lb.
What type of transmission does the Caterpillar Twenty-Two have?
The Caterpillar Twenty-Two uses a Gear transmission offering 3 forward gears.
What routine service does the Caterpillar Twenty-Two need?
Regular maintenance for the Caterpillar Twenty-Two includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
