Brand siblingRow CropPerformance profile
Challenger MT565D
The Challenger MT565D is a powerful row crop tractor built from 2012 to 2014. It has a strong 4WD system and a 6-cylinder Sisu AGCO Power Diesel engine. This engine produces 162.3 hp, which is above average for tractors. The MT565D has a 24-speed transmission with both forward and reverse gears, giving farmers lots of options for different tasks. This tractor is big and sturdy, weighing 17,855 lb and measuring 200.2 inches long. It has a cabin with air conditioning for farmer comfort. The rear hitch can lift up to 12,502 lb, which is very high compared to other tractors. The MT565D also has a versatile PTO system with both 540 and 1000 rpm speeds. Its hydraulic system is strong, able to exert up to 14,410 lb of force. The tractor is quiet too, with a sound level of 69.0 dB(A) when not working.
ManufacturerChallengerPower162.3 hpEngine6-cylTransSix-speed power shift
Quick specs
- Category
- Row Crop
- Engine Power Output
- 162hp
- Operating Weight
- 17,855 lb
- Transmission
- Six-speed power shift
At a glance
How the MT565D compares
vs. Row Crop medianDistribution
Engine Power (hp)
Across all Row Crop tractors
162.3 hp · 63rd
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The MT565D ranks at the 63rd percentile for engine power among recorded row crop tractors.
Overview
About the Challenger MT565D
The Challenger MT565D is a powerful row crop tractor built from 2012 to 2014. It has a strong 4WD system and a 6-cylinder Sisu AGCO Power Diesel engine. This engine produces 162.3 hp, which is above average for tractors. The MT565D has a 24-speed transmission with both forward and reverse gears, giving farmers lots of options for different tasks. This tractor is big and sturdy, weighing 17,855 lb and measuring 200.2 inches long. It has a cabin with air conditioning for farmer comfort. The rear hitch can lift up to 12,502 lb, which is very high compared to other tractors. The MT565D also has a versatile PTO system with both 540 and 1000 rpm speeds. Its hydraulic system is strong, able to exert up to 14,410 lb of force. The tractor is quiet too, with a sound level of 69.0 dB(A) when not working.
Full specifications
Every recorded spec
General
| Manufacturer | Challenger |
|---|---|
| Model | MT565D |
| Category | Row Crop tractor |
| Type | 4x4 |
| Years built | 2012–2014 |
| Operating weight | 17,855lb |
Engine
| Make | Sisu AGCO Power Diesel |
|---|---|
| Model | Sisu Diesel, Serial No. W 00454 |
| Power | 162.3hp |
| Cylinders | 6 |
| Displacement | 402ci |
| Bore | 4.25in |
| Stroke | 4.72in |
Transmission
| Type | Six-speed power shift |
|---|---|
| Forward gears | 24 |
| Reverse gears | 24 |
Chassis & drive
| Chassis | 4x4 |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic Power |
| Brakes | Hydraulic wet disc |
| Cab | Cabin with air-conditioning |
Hydraulics
| Type | Direct engine drive |
|---|
Power take-off
| Rear PTO | Independent with electro-hydraulic clutch |
|---|---|
| PTO speed | 540rpm |
Dimensions
| Wheelbase | 117.8in |
|---|---|
| Length | 200.2in |
| Height | 120.8in |
| Operating weight | 17,855lb |
Tires
| Front | 480/70R30 |
|---|---|
| Rear | 620/70R42 |
Head to head
MT565D vs. Row Crop median
How the Challenger MT565D compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 162 hp | 138 hp | +18% | 63rd |
| Engine Displacement | 402 ci | 391 ci | +3% | 52nd |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 24 | 16 | +50% | 81st |
| Operating Weight | 17,855 lb | 12,307 lb | +45% | 77th |
| Length | 200 in | 180 in | +11% | 74th |
| Height | 121 in | 114 in | +6% | 75th |
| 3-Point Hitch Capacity | 12,502 lb | 11,023 lb | +13% | 57th |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 279–1,417 models).
Compare to tractors with similar specs
Commonly compared Challenger tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Challenger MT555B MFWD | 130 hp | 15,000 lb | — | Compare → |
| Challenger MT475D | 123 hp | 15,765 lb | — | Compare → |
| Challenger MT535 | — | 9,600 lb | — | Compare → |
| Challenger MT545 | — | 10,082 lb | — | Compare → |
| Challenger MT565 | — | 15,555 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO RT155A | 162.5 hp | — | — | Compare → |
| Allis Chalmers HD16A | 163 hp | 31,500 lb | — | Compare → |
| Agrinar T-160 | 161 hp | 13,450 lb | — | Compare → |
| AGCO DT160 | 160 hp | 18,500 lb | 2002–2004 | Compare → |
| Belarus 1507 | 165 hp | 20,283 lb | — | Compare → |
Explore
Challenger siblings
Explore
Similar-spec models
Gallery
Challenger MT565D photos
FAQ
Common questions
What years was the Challenger MT565D manufactured?
Production of the Challenger MT565D ran from 2012 through 2014.
What is the working weight of the Challenger MT565D?
The operating weight of the Challenger MT565D is approximately 17,855 lb.
What type of transmission does the Challenger MT565D have?
The Challenger MT565D uses a Six-speed power shift transmission offering 24 forward gears.
What type of hydraulic system does the Challenger MT565D use?
Hydraulics on the Challenger MT565D are Direct engine drive.
What size tires does the Challenger MT565D use?
Factory rubber for the Challenger MT565D is 480/70R30 front tires and 620/70R42 rear tires.
How powerful is the Challenger MT565D?
The Challenger MT565D has an engine power output of 162.3 hp. It is powered by a 6-cylinder engine displacing 402 ci.
What routine service does the Challenger MT565D need?
Regular maintenance for the Challenger MT565D includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
