Row Crop
CO-OP G
The CO-OP G is a row crop tractor designed for small-scale farming. It features a 2WD chassis with manual steering, making it easy to handle in tight spaces. The tractor has a simple gear transmission with 3 forward gears and 1 reverse gear, allowing for basic speed control during field operations. Under the hood, the CO-OP G is powered by a Hercules IXA3 engine. This 4-cylinder gasoline engine is liquid-cooled and has a displacement of 113.12 ci, which is below average compared to other tractors. The engine runs at 1400 rpm, which is also lower than most tractors. Despite its small size, the CO-OP G weighs 2105 lb, making it one of the lightest tractors in its class. It has agricultural tires on both front and rear, with the front tires measuring 5.5 inches wide. The tractor stands 55 inches tall and features a manual start system, which may require some physical effort to get it running.
ManufacturerCO-OPEngine4-cylTransGear
Quick specs
- Category
- Row Crop
- Operating Weight
- 2,105 lb
- Transmission
- Gear
Overview
About the CO-OP G
The CO-OP G is a row crop tractor designed for small-scale farming. It features a 2WD chassis with manual steering, making it easy to handle in tight spaces. The tractor has a simple gear transmission with 3 forward gears and 1 reverse gear, allowing for basic speed control during field operations. Under the hood, the CO-OP G is powered by a Hercules IXA3 engine. This 4-cylinder gasoline engine is liquid-cooled and has a displacement of 113.12 ci, which is below average compared to other tractors. The engine runs at 1400 rpm, which is also lower than most tractors. Despite its small size, the CO-OP G weighs 2105 lb, making it one of the lightest tractors in its class. It has agricultural tires on both front and rear, with the front tires measuring 5.5 inches wide. The tractor stands 55 inches tall and features a manual start system, which may require some physical effort to get it running.
Full specifications
Every recorded spec
General
| Manufacturer | CO-OP |
|---|---|
| Model | G |
| Category | Row Crop tractor |
| Type | 4x2 2WD |
| Operating weight | 2,105lb |
Engine
| Make | Hercules |
|---|---|
| Model | IXA3 |
| Cylinders | 4 |
| Displacement | 113.12ci |
| Bore | 3in |
| Stroke | 4in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 3 |
| Reverse gears | 1 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
Dimensions
| Height | 55in |
|---|---|
| Operating weight | 2,105lb |
Capacities
| Cooling system | 3gal |
|---|
Head to head
G vs. Row Crop median
How the CO-OP G compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 113 ci | 391 ci | -71% | 1st |
| Cylinders | 4 | 6 | -33% | 17th |
| Forward Gears | 3 | 16 | -81% | 1st |
| Operating Weight | 2,105 lb | 12,307 lb | -83% | 1st |
| Height | 55 in | 114 in | -52% | 1st |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 1,140–1,417 models).
Compare to tractors with similar specs
Commonly compared CO-OP tractors
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
CO-OP siblings
Explore
Similar-spec models
Gallery
CO-OP G photos
FAQ
Common questions
What engine configuration does the CO-OP G use?
The CO-OP G is equipped with a 4-cylinder engine displacing 113.12 ci.
What is the working weight of the CO-OP G?
The operating weight of the CO-OP G is approximately 2,105 lb.
What type of transmission does the CO-OP G have?
The CO-OP G uses a Gear transmission offering 3 forward gears.
What routine service does the CO-OP G need?
Regular maintenance for the CO-OP G includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
