Lawn and Garden tractorsSpec sheet
Cub Cadet HDS 2135
The Cub Cadet HDS 2135 is a compact lawn and garden tractor designed for homeowners with small to medium-sized yards. This 2WD tractor features a shaft-driven hydrostatic transmission, offering smooth operation with infinite forward and reverse speeds. It's powered by a Kohler Command CH12.5 engine, which is air-cooled and runs on gasoline. The engine has one cylinder and produces 12.5 hp at 3600 rpm, which is average for its class. This tractor measures 71.7 inches long, 44.9 inches wide, and 41.7 inches tall, making it easy to maneuver in tight spaces. It weighs 562 lb, which is about average for its size. The HDS 2135 comes with lawn/turf tires, an independent PTO with electric clutch, and an open operator station for comfort. It also features electric start and internal expanding brakes for safety. The fuel tank can hold 3 US gallons, allowing for extended use without frequent refueling. With its durable build and user-friendly design, the Cub Cadet HDS 2135 is a solid choice for regular lawn maintenance tasks.
ManufacturerCub CadetPower12.5 hp(9.3 kW)ClassUnder 25 HP tractors →Engine1-cylinderTransmissionShaft-driven hydrostatic
Key specifications
- Category
- Lawn and Garden
- Engine power
- 13hp
- Operating weight
- 562 lb
- Transmission
- Shaft-driven hydrostatic
Category comparison
HDS 2135 compared with its category
vs. Lawn and Garden medianDistribution
Engine Power (hp)
All recorded Lawn and Garden tractors
12.5 hp · 20th
This model
4
Median 18 hp
28
This modelLawn and Garden tractorsMediann = 380
The HDS 2135 ranks at the 20th percentile for engine power among recorded lawn and garden tractors.
Overview
About the Cub Cadet HDS 2135
The Cub Cadet HDS 2135 is a compact lawn and garden tractor designed for homeowners with small to medium-sized yards. This 2WD tractor features a shaft-driven hydrostatic transmission, offering smooth operation with infinite forward and reverse speeds. It's powered by a Kohler Command CH12.5 engine, which is air-cooled and runs on gasoline. The engine has one cylinder and produces 12.5 hp at 3600 rpm, which is average for its class. This tractor measures 71.7 inches long, 44.9 inches wide, and 41.7 inches tall, making it easy to maneuver in tight spaces. It weighs 562 lb, which is about average for its size. The HDS 2135 comes with lawn/turf tires, an independent PTO with electric clutch, and an open operator station for comfort. It also features electric start and internal expanding brakes for safety. The fuel tank can hold 3 US gallons, allowing for extended use without frequent refueling. With its durable build and user-friendly design, the Cub Cadet HDS 2135 is a solid choice for regular lawn maintenance tasks.
Full specifications
Recorded specifications
General
| Manufacturer | Cub Cadet |
|---|---|
| Model | HDS 2135 |
| Category | Lawn and Garden tractor |
| Type | 4x2 2WD |
| Operating weight | 562lb(254.9 kg) |
Engine
| Make | Kohler |
|---|---|
| Model | Command CH12.5 |
| Power | 12.5hp(9.32 kW) |
| Cylinders | 1 |
| Displacement | 24.3ci(0.4 L) |
| Bore | 3.43in(87.12 mm) |
| Stroke | 2.64in(67.06 mm) |
Transmission
| Type | Shaft-driven hydrostatic |
|---|
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
| Brakes | Internal expanding |
| Cab | Open operator station |
Power take-off
| Rear PTO | Independent with electric clutch |
|---|
Dimensions
| Length | 71.7in(1,821 mm) |
|---|---|
| Width | 44.9in(1,140 mm) |
| Height | 41.7in(1,059 mm) |
| Operating weight | 562lb(254.9 kg) |
Closest alternatives
HDS 2135 compared with the nearest models by horsepower
Among lawn and garden tractors, the Cub Cadet AGS 2130 and the Cub Cadet 1315 are closest to the Cub Cadet HDS 2135 in rated horsepower. The Cub Cadet AGS 2130 matches it on rated power at almost the same operating weight. The Cub Cadet 1315 matches it on rated power and weighs 420 lb more, so it carries more weight per horsepower, which helps traction in draft work. Of the 3 models, the HDS 2135 has the lowest weight per horsepower at 45 lb per hp.
| Spec | Cub Cadet HDS 2135 | Cub Cadet AGS 2130 | Cub Cadet 1315 |
|---|---|---|---|
| Engine power | 12.5 hp9.3 kW | 12.5 hp9.3 kW | 12.5 hp9.3 kW |
| Operating weight | 562 lb255 kg | 562 lb255 kg | 985 lb447 kg |
| Weight per hp | 45 lb/hp27 kg/kW | 45 lb/hp27 kg/kW | 79 lb/hp48 kg/kW |
| Displacement | 24.3 ci0.4 L | 24.3 ci0.4 L | 24.3 ci0.4 L |
| Cylinders | 1 | 1 | 1 |
| Transmission | Shaft-driven hydrostatic | Shaft-driven gear type | Gear |
| Drive | 2WD | 2WD | 2WD |
| Years built | - | 1994-1999 | 1989-1991 |
Calculators
Calculators for the HDS 2135
PTO power
About 10 to 11 PTO hp
Estimated from the 12.5 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 12.5 hp tractor can run
The calculator sizes mowers, tillers, discs, plows and balers for this tractor.
Ballast
52 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
12.5 hp is 9.3 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the Cub Cadet HDS 2135
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Kohler Command CH12.5Amazon
Fits the Kohler Command CH12.5 1-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Kohler Command CH12.5Amazon
Fits the Kohler Command CH12.5 1-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Kohler Command CH12.5Amazon
Fits the Kohler Command CH12.5 1-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Kohler Command CH12.5Amazon
Fits the Kohler Command CH12.5 1-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Cub Cadet HDS 2135 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Cub Cadet HDS 2135 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Cub Cadet HDS 2135 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
HDS 2135 vs. Lawn and Garden median
Cub Cadet HDS 2135 compared with other Lawn and Garden tractors
| Spec | This model | Lawn and Garden median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 12.5 hp | 18 hp | -31% | 20th |
| Engine Displacement | 24.3 ci | 41.1 ci | -41% | 15th |
| Cylinders | 1 | 2 | -50% | 17th |
| Operating Weight | 562 lb | 738 lb | -24% | 30th |
| Length | 71.7 in | 71.7 in | at median | 50th |
| Width | 44.9 in | 43.3 in | +4% | 56th |
| Height | 41.7 in | 42.9 in | -3% | 33rd |
Medians and percentiles are calculated from the lawn and garden tractors in the database that have a recorded value for each specification (sample size 269–380 models).
Same manufacturer
Other Cub Cadet models
Other manufacturers
Models with similar horsepower
Gallery
Cub Cadet HDS 2135 photos
FAQ
Frequently asked questions
What is the engine power output of the Cub Cadet HDS 2135?
Rated engine output for the Cub Cadet HDS 2135 is 12.5 hp, delivered by a 1-cylinder engine. The engine displaces 24.3 ci.
What is the operating weight of the Cub Cadet HDS 2135?
The Cub Cadet HDS 2135 has an operating weight of about 562 lb.
Which transmission does the Cub Cadet HDS 2135 use?
The Cub Cadet HDS 2135 is equipped with a Shaft-driven hydrostatic transmission.
How do I maintain a Cub Cadet HDS 2135?
Routine service for the Cub Cadet HDS 2135 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
