Dongfeng DF-804

Dongfeng DF-804

Complete specifications and technical data for the Dongfeng DF-804. Compare with similar tractors from Dongfeng and other manufacturers.

Jump to Full Specifications List

Quick Specs

Engine Power Output

80hp

Operating Weight

7,883 lb

Transmission

8-Speed

The Dongfeng DF-804 is a powerful 4WD tractor built for tough farm work. It has a strong 80 hp diesel engine with four cylinders. This engine is liquid-cooled and runs at 2300 rpm, giving the tractor ...

Photo Gallery

Image Gallery
Dongfeng DF-804 Tractor
Dongfeng DF-804 Tractor
Dongfeng DF-804 Tractor
Dongfeng DF-804 Tractor
Dongfeng DF-804 Tractor

Specifications

Manufacturer
Dongfeng
Model
DF-804
Manufacturer
Dongfeng
Model
LR4108T
Power Output
80hp
Rated RPM
2,300RPM
Cylinders
4
Displacement
264.2ci
Bore
4.25in
Stroke
4.72in
Type
8-Speed
Length
180.8in
Width
80.7in
Height
110.6in
Operating Weight
7,883lb
Chassis Type
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydraulic Power

Compare to Other Tractors

Frequently Asked Questions

What is the engine power output of the Dongfeng DF-804?

The Dongfeng DF-804 has an engine power output of 80 hp.

How many cylinders does the Dongfeng DF-804 have?

The Dongfeng DF-804 is equipped with a 4-cylinder engine.

What is the operating weight of the Dongfeng DF-804?

The operating weight of the Dongfeng DF-804 is approximately 7,883 lb.

What type of transmission does the Dongfeng DF-804 have?

The Dongfeng DF-804 is equipped with a 8-Speed transmission.

What maintenance does the Dongfeng DF-804 require?

Regular maintenance for the Dongfeng DF-804 includes checking and changing engine oil, hydraulic fluid, filters, and performing routine inspections as recommended in the owner's manual. Always refer to the manufacturer's maintenance schedule for specific intervals and procedures.
