Fendt Farmer 1D
The Fendt Farmer 1D is a utility tractor designed for various farm tasks. It has a 2-wheel drive system and a manual transmission with 12 forward gears and 4 reverse gears. This tractor is powered by a 3-cylinder diesel engine made by MWM. The engine has a displacement of 155.6 cubic inches and produces 34 horsepower at 2100 rpm, which is below average for its class. The Farmer 1D is compact, measuring 130.3 inches long and 91.3 inches tall. It weighs 5291 pounds, which is about average for utility tractors. The tractor features agricultural tires, with 5.50-16 tires in front and 11.2-28 tires in the rear. It has a wheelbase of 78.35 inches and is equipped with a Category III hitch, making it suitable for a wide range of farm implements.
Key specifications
- Category
- Utility
- Engine power
- 34hp
- Operating weight
- 5,291 lb
- Transmission
- Manual
Category comparison
Farmer 1D compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
34 hp · 26th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Farmer 1D ranks at the 26th percentile for engine power among recorded utility tractors.
Overview
About the Fendt Farmer 1D
The Fendt Farmer 1D is a utility tractor designed for various farm tasks. It has a 2-wheel drive system and a manual transmission with 12 forward gears and 4 reverse gears. This tractor is powered by a 3-cylinder diesel engine made by MWM. The engine has a displacement of 155.6 cubic inches and produces 34 horsepower at 2100 rpm, which is below average for its class. The Farmer 1D is compact, measuring 130.3 inches long and 91.3 inches tall. It weighs 5291 pounds, which is about average for utility tractors. The tractor features agricultural tires, with 5.50-16 tires in front and 11.2-28 tires in the rear. It has a wheelbase of 78.35 inches and is equipped with a Category III hitch, making it suitable for a wide range of farm implements.
Full specifications
Recorded specifications
General
| Manufacturer | Fendt |
|---|---|
| Model | Farmer 1D |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 5,291lb(2,400 kg) |
Engine
| Make | MWM |
|---|---|
| Power | 34hp(25.35 kW) |
| Cylinders | 3 |
| Displacement | 155.6ci(2.55 L) |
| Bore | 3.74in(95 mm) |
| Stroke | 4.72in(119.9 mm) |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 12 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 130.3in(3,310 mm) |
|---|---|
| Height | 91.3in(2,319 mm) |
| Operating weight | 5,291lb(2,400 kg) |
Closest alternatives
Farmer 1D compared with the nearest models by horsepower
The closest utility models to the Fendt Farmer 1D by rated horsepower are the Massey Ferguson 1734E and the Bobcat CT235. The Massey Ferguson 1734E matches it on rated power and weighs 2,560 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The Bobcat CT235 matches it on rated power and weighs 2,240 lb less, carrying 90 lb per horsepower against 156 lb. Of the 3 models, the Farmer 1D has the highest weight per horsepower at 156 lb per hp.
| Spec | Fendt Farmer 1D | Massey Ferguson 1734E | Bobcat CT235 |
|---|---|---|---|
| Engine power | 34 hp25.4 kW | 34 hp25.4 kW | 34 hp25.4 kW |
| Operating weight | 5,291 lb2,400 kg | 2,734 lb1,240 kg | 3,056 lb1,386 kg |
| Weight per hp | 156 lb/hp95 kg/kW | 80 lb/hp49 kg/kW | 90 lb/hp55 kg/kW |
| Displacement | 155.6 ci2.55 L | 91.3 ci1.5 L | 97.6 ci1.6 L |
| Cylinders | 3 | 3 | 3 |
| Transmission | Manual | Gear type with dry disc clutch | Hydrostatic |
| Drive | 2WD | 4WD | 4WD |
| Years built | - | 2013+ | 2008-2013 |
Calculators
Calculators for the Farmer 1D
PTO power
About 28 to 31 PTO hp
Estimated from the 34 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 34 hp tractor can run
The calculator sizes mowers, tillers, discs, plows and balers for this tractor.
Ballast
181 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
34 hp is 25.4 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
Farmer 1D vs. Utility median
Fendt Farmer 1D compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 34 hp | 55 hp | -38% | 26th |
| Engine Displacement | 156 ci | 183 ci | -15% | 42nd |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 5,291 lb | 5,303 lb | 0% | 50th |
| Length | 130 in | 137 in | -5% | 41st |
| Height | 91.3 in | 94.1 in | -3% | 44th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 4,321–5,720 models).
Same manufacturer
Other Fendt models
Other manufacturers
Models with similar horsepower
Gallery
Fendt Farmer 1D photos
FAQ
Frequently asked questions
What is the engine power output of the Fendt Farmer 1D?
Rated engine output for the Fendt Farmer 1D is 34 hp, delivered by a 3-cylinder engine. The engine displaces 155.6 ci.
Which transmission does the Fendt Farmer 1D use?
The Fendt Farmer 1D is equipped with a Manual transmission with 12 forward gears.
What hitch category is the Fendt Farmer 1D?
The Fendt Farmer 1D uses a Category III hitch.
What is the operating weight of the Fendt Farmer 1D?
The Fendt Farmer 1D has an operating weight of about 5,291 lb.
How do I maintain a Fendt Farmer 1D?
Routine service for the Fendt Farmer 1D covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
