Fendt Farmer 270V

The Fendt Farmer 270V is a specialized tractor designed for orchards and vineyards. It's also great for general farm work. This tractor has a narrow build, measuring just 46.1 inches wide, which helps it move easily between rows of trees or vines. Under the hood, the Farmer 270V has a KHD F4L912 engine. This 4-cylinder diesel engine is air-cooled and naturally aspirated. It produces 69.7 horsepower, which is about average for tractors in its class. The engine size is above average at 230.1 cubic inches. The tractor has a manual transmission with 20 forward gears and 6 reverse gears, giving the driver lots of options for different tasks. It's a two-wheel drive tractor with power steering, making it easy to handle. Farmers can choose between a ROPS (Roll-Over Protective Structure) or a cab for the operator station. The Farmer 270V weighs 5,004 pounds and has a Category 3 hitch, allowing it to work with many different attachments.

ManufacturerFendtPower69.7 hp(52.0 kW)Class60–100 HP tractors →Engine4-cylinderTransmissionManual
Fendt Farmer 270V

Key specifications

Category
Agricultural
Engine power
70hp
Operating weight
5,004 lb
Transmission
Manual
Compare this model

Category comparison

Farmer 270V compared with its category

vs. Agricultural median

Distribution

Engine Power (hp)

All recorded Agricultural tractors

69.7 hp · 20th

This model

13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028

The Farmer 270V ranks at the 20th percentile for engine power among recorded agricultural tractors.

Overview

About the Fendt Farmer 270V

The Fendt Farmer 270V is a specialized tractor designed for orchards and vineyards. It's also great for general farm work. This tractor has a narrow build, measuring just 46.1 inches wide, which helps it move easily between rows of trees or vines. Under the hood, the Farmer 270V has a KHD F4L912 engine. This 4-cylinder diesel engine is air-cooled and naturally aspirated. It produces 69.7 horsepower, which is about average for tractors in its class. The engine size is above average at 230.1 cubic inches. The tractor has a manual transmission with 20 forward gears and 6 reverse gears, giving the driver lots of options for different tasks. It's a two-wheel drive tractor with power steering, making it easy to handle. Farmers can choose between a ROPS (Roll-Over Protective Structure) or a cab for the operator station. The Farmer 270V weighs 5,004 pounds and has a Category 3 hitch, allowing it to work with many different attachments.

Full specifications

Recorded specifications

General

ManufacturerFendt
ModelFarmer 270V
CategoryAgricultural tractor
Type4x2 2WD
Operating weight5,004lb(2,270 kg)

Engine

MakeKHD
ModelF4L912
Power69.7hp(51.98 kW)
Cylinders4
Displacement230.1ci(3.77 L)
Bore3.94in(100 mm)
Stroke4.72in(119.9 mm)

Transmission

TypeManual
Forward gears20
Reverse gears6

Chassis & drive

Chassis4x2 2WD
Drive2WD
SteeringPower
CabAvailable in ROPS or Cab

Dimensions

Length135.6in(3,444 mm)
Width46.1in(1,171 mm)
Operating weight5,004lb(2,270 kg)

Closest alternatives

Farmer 270V compared with the nearest models by horsepower

By engine horsepower, the nearest agricultural models to the Farmer 270V are the Antonio Carraro SRX 8400 and the Belarus 560. The Antonio Carraro SRX 8400 matches it on rated power and weighs 520 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The Belarus 560 matches it on rated power and weighs 1,700 lb more, at 96 lb per horsepower against 72 lb.

Fendt Farmer 270V compared with Antonio Carraro SRX 8400 and Belarus 560
SpecFendt Farmer 270VAntonio Carraro SRX 8400Belarus 560
Engine power69.7 hp52 kW70 hp52.2 kW70 hp52.2 kW
Operating weight5,004 lb2,270 kg4,486 lb2,035 kg6,700 lb3,039 kg
Weight per hp72 lb/hp44 kg/kW64 lb/hp39 kg/kW96 lb/hp58 kg/kW
Displacement230.1 ci3.77 L136 ci2.23 L290 ci4.75 L
Cylinders434
TransmissionManualManualSliding Gear
Drive2WD4WD2WD

Calculators

Calculators for the Farmer 270V

Parts and manuals

Parts and manuals for the Fendt Farmer 270V

Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.

Filters

  • Oil filter for the KHD F4L912Amazon

    Fits the KHD F4L912 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.

  • Air filter for the KHD F4L912Amazon

    Fits the KHD F4L912 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.

  • Fuel filter for the KHD F4L912Amazon

    Fits the KHD F4L912 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.

  • Hydraulic filter for the KHD F4L912Amazon

    Fits the KHD F4L912 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.

Manuals

Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure

Category medians

Farmer 270V vs. Agricultural median

Fendt Farmer 270V compared with other Agricultural tractors

SpecThis modelAgricultural medianDifferencePercentile
Engine Power69.7 hp110 hp-37%20th
Engine Displacement230 ci336 ci-31%21st
Cylinders45.5-27%31st
Forward Gears2016+25%74th
Operating Weight5,004 lb10,914 lb-54%13th
Length136 in173 in-22%17th
Width46.1 in79.5 in-42%7th

Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 497–1,130 models).

Same manufacturer

Other Fendt models

All Fendt models →

Other manufacturers

Models with similar horsepower

FAQ

Frequently asked questions

How much horsepower does the Fendt Farmer 270V have?

The Fendt Farmer 270V produces 69.7 hp from its 4-cylinder engine. Engine displacement is 230.1 ci.

How much does the Fendt Farmer 270V weigh?

The Fendt Farmer 270V weighs about 5,004 lb in operating condition.

What transmission is in the Fendt Farmer 270V?

Transmission on the Fendt Farmer 270V is Manual, with 20 forward speeds.

What hitch category is the Fendt Farmer 270V?

The Fendt Farmer 270V uses a Category Category 3 hitch.

What maintenance does the Fendt Farmer 270V require?

The Fendt Farmer 270V needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
