UtilityPerformance profile
Fiat 505C
The Fiat 505C is a utility tractor that packs a punch in a compact package. It's powered by a Fiat 8035 engine, which is a 3-cylinder diesel motor with liquid cooling. This engine has an average displacement of 158.2 ci and can produce 50 hp at 2600 rpm, which is about average for tractors in its class. The 505C has a gear transmission with 6 forward and 2 reverse speeds, giving farmers good control over their work. This tractor is built for versatility on the farm. It measures 105.3 inches long, 56.7 inches wide, and 48.4 inches tall, making it easy to maneuver in tight spaces. The 505C weighs 5512 lb, which is about average for its size. It has a rear hitch that can handle both category II and I implements, and an open center hydraulic system for powering attachments. The open operator station gives the driver a clear view of their surroundings. With features like electric start and good ground clearance of 10.6 inches, the Fiat 505C is ready to tackle a variety of farm tasks with ease.
ManufacturerFiatPower50 hpEngine3-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 50hp
- Operating Weight
- 5,512 lb
- Transmission
- Gear
At a glance
How the 505C compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
50 hp · 45th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 505C ranks at the 45th percentile for engine power among recorded utility tractors.
Overview
About the Fiat 505C
The Fiat 505C is a utility tractor that packs a punch in a compact package. It's powered by a Fiat 8035 engine, which is a 3-cylinder diesel motor with liquid cooling. This engine has an average displacement of 158.2 ci and can produce 50 hp at 2600 rpm, which is about average for tractors in its class. The 505C has a gear transmission with 6 forward and 2 reverse speeds, giving farmers good control over their work. This tractor is built for versatility on the farm. It measures 105.3 inches long, 56.7 inches wide, and 48.4 inches tall, making it easy to maneuver in tight spaces. The 505C weighs 5512 lb, which is about average for its size. It has a rear hitch that can handle both category II and I implements, and an open center hydraulic system for powering attachments. The open operator station gives the driver a clear view of their surroundings. With features like electric start and good ground clearance of 10.6 inches, the Fiat 505C is ready to tackle a variety of farm tasks with ease.
Full specifications
Every recorded spec
General
| Manufacturer | Fiat |
|---|---|
| Model | 505C |
| Category | Utility tractor |
| Operating weight | 5,512lb |
Engine
| Make | Fiat |
|---|---|
| Model | 8035 |
| Power | 50hp |
| Cylinders | 3 |
| Displacement | 158.2ci |
| Bore | 3.94in |
| Stroke | 4.33in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 6 |
| Reverse gears | 2 |
Chassis & drive
| Cab | Open |
|---|
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 105.3in |
|---|---|
| Width | 56.7in |
| Height | 48.4in |
| Operating weight | 5,512lb |
Head to head
505C vs. Utility median
How the Fiat 505C compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 50 hp | 55 hp | -9% | 45th |
| Engine Displacement | 158 ci | 183 ci | -14% | 42nd |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 6 | 12 | -50% | 11th |
| Operating Weight | 5,512 lb | 5,303 lb | +4% | 52nd |
| Length | 105 in | 137 in | -23% | 12th |
| Width | 56.7 in | 66 in | -14% | 31st |
| Height | 48.4 in | 94.1 in | -49% | 2nd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Fiat tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Fiat 446 | 50 hp | 4,299 lb | — | Compare → |
| Fiat 466 | 50 hp | 5,930 lb | — | Compare → |
| Fiat 500 | 50 hp | 4,023 lb | — | Compare → |
| Fiat 50-66S | 49.4 hp | 4,685 lb | — | Compare → |
| Fiat 50-66 | 49.3 hp | 4,255 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5050 | 50 hp | 4,410 lb | 1977–1983 | Compare → |
| Allis Chalmers FD5 | 50 hp | 5,412 lb | — | Compare → |
| Belarus 4055 | 50 hp | 4,750 lb | — | Compare → |
| AGCO GT45 | 52 hp | 4,806 lb | — | Compare → |
| Agco GT45A | 52 hp | 5,820.3 lb | — | Compare → |
Explore
Fiat siblings
Explore
Similar-spec models
Gallery
Fiat 505C photos
FAQ
Common questions
How powerful is the Fiat 505C?
The Fiat 505C has an engine power output of 50 hp. It is powered by a 3-cylinder engine displacing 158.2 ci.
What is the working weight of the Fiat 505C?
The operating weight of the Fiat 505C is approximately 5,512 lb.
What type of transmission does the Fiat 505C have?
The Fiat 505C uses a Gear transmission offering 6 forward gears.
What hydraulics does the Fiat 505C have?
The Fiat 505C uses an Open Center hydraulic system.
What three-point hitch category does the Fiat 505C use?
The Fiat 505C has a Category II/I three-point hitch.
What routine service does the Fiat 505C need?
Regular maintenance for the Fiat 505C includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
