UtilityPerformance profile
IMT 5630
The IMT 5630 is a powerful utility tractor built for tough jobs. It has a strong Mercedes OM-404 engine with 12 cylinders and 360 horsepower. This engine is very big for a tractor, with a displacement of 1276 cubic inches. It runs on diesel fuel and has direct injection for better performance. The tractor has a 4x4 articulated chassis and four-wheel drive, which helps it work well in different conditions. It has big 20.8-38 agricultural tires on both the front and back. The transmission has 16 forward gears and 2 reverse gears, giving the driver lots of options. The engine runs at 2000 RPM, which is lower than many other tractors. This tractor starts with an electric starter, making it easy to get going. Overall, the IMT 5630 is a very strong tractor that can handle big jobs on the farm.
ManufacturerIMTPower360 hpEngine12-cyl
Quick specs
- Category
- Utility
- Engine Power Output
- 360hp
At a glance
How the 5630 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
360 hp · 98th
This model
9
Median 55 hp
177
360
This modelUtility tractorsMediann = 5,383
The 5630 ranks at the 98th percentile for engine power among recorded utility tractors.
Overview
About the IMT 5630
The IMT 5630 is a powerful utility tractor built for tough jobs. It has a strong Mercedes OM-404 engine with 12 cylinders and 360 horsepower. This engine is very big for a tractor, with a displacement of 1276 cubic inches. It runs on diesel fuel and has direct injection for better performance. The tractor has a 4x4 articulated chassis and four-wheel drive, which helps it work well in different conditions. It has big 20.8-38 agricultural tires on both the front and back. The transmission has 16 forward gears and 2 reverse gears, giving the driver lots of options. The engine runs at 2000 RPM, which is lower than many other tractors. This tractor starts with an electric starter, making it easy to get going. Overall, the IMT 5630 is a very strong tractor that can handle big jobs on the farm.
Full specifications
Every recorded spec
General
| Manufacturer | IMT |
|---|---|
| Model | 5630 |
| Category | Utility tractor |
| Type | 4x4 articulated 4WD |
Engine
| Make | Mercedes |
|---|---|
| Model | OM-404 |
| Power | 360hp |
| Cylinders | 12 |
| Displacement | 1,276ci |
| Bore | 4.92in |
| Stroke | 5.59in |
Transmission
| Forward gears | 16 |
|---|---|
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x4 articulated 4WD |
|---|---|
| Drive | 4WD |
Tires
| Front | 20.8-38 |
|---|---|
| Rear | 20.8-38 |
Head to head
5630 vs. Utility median
How the IMT 5630 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 360 hp | 55 hp | +555% | 98th |
| Engine Displacement | 1,276 ci | 183 ci | +597% | 99th |
| Cylinders | 12 | 4 | +200% | 99th |
| Forward Gears | 16 | 12 | +33% | 73rd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,941–5,720 models).
Compare to tractors with similar specs
Commonly compared IMT tractors
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO AGCOSTAR 8360 | 360 hp | — | 1995–2001 | Compare → |
| Big Bud 360/10 | 360 hp | 39,000 lb | — | Compare → |
| Big Bud 360/30 | 360 hp | 39,000 lb | — | Compare → |
| Big Bud HN360 | 360 hp | 39,000 lb | — | Compare → |
| Big Bud KT360 | 360 hp | 39,500 lb | — | Compare → |
Explore
IMT siblings
Explore
Similar-spec models
Gallery
IMT 5630 photos
FAQ
Common questions
What is the engine power output of the IMT 5630?
Rated engine output for the IMT 5630 is 360 hp, delivered by a 12-cylinder engine. The engine displaces 1,276 ci.
What size tires does the IMT 5630 use?
Factory rubber for the IMT 5630 is 20.8-38 front tires and 20.8-38 rear tires.
How do I maintain a IMT 5630?
Routine service for the IMT 5630 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
