International Harvester 504
The International Harvester 504 is a 2WD tractor made from 1961 to 1968. It has a 4-cylinder diesel engine that's liquid-cooled and naturally aspirated. The engine, made by International Harvester, has a displacement of 187.5 cubic inches. This tractor has power steering and a 5-speed unsynchronized gear transmission with one reverse gear. The 504 model is built for farm work, with ag tires on both front and rear. It's 128 inches long and 61 inches tall, weighing 4,458 pounds. The tractor comes with an optional IH Fast Hitch at the rear, which is a Category 1 hitch. It has an independent PTO that runs at 540 rpm. The tractor has an open operator station and uses a 12-volt electrical system with an electric starter. This model is designed for durability and practical use on the farm.
ManufacturerInternational HarvesterEngine4-cylTransUnsynchronized gear
Quick specs
- Category
- Utility
- Operating Weight
- 4,458 lb
- Transmission
- Unsynchronized gear
Overview
About the International Harvester 504
The International Harvester 504 is a 2WD tractor made from 1961 to 1968. It has a 4-cylinder diesel engine that's liquid-cooled and naturally aspirated. The engine, made by International Harvester, has a displacement of 187.5 cubic inches. This tractor has power steering and a 5-speed unsynchronized gear transmission with one reverse gear. The 504 model is built for farm work, with ag tires on both front and rear. It's 128 inches long and 61 inches tall, weighing 4,458 pounds. The tractor comes with an optional IH Fast Hitch at the rear, which is a Category 1 hitch. It has an independent PTO that runs at 540 rpm. The tractor has an open operator station and uses a 12-volt electrical system with an electric starter. This model is designed for durability and practical use on the farm.
Full specifications
Every recorded spec
General
| Manufacturer | International Harvester |
|---|---|
| Model | 504 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Years built | 1961–1968 |
| Operating weight | 4,458lb |
Engine
| Make | International Harvester |
|---|---|
| Model | D188 |
| Cylinders | 4 |
| Displacement | 187.5ci |
| Bore | 3.69in |
| Stroke | 4.39in |
Transmission
| Type | Unsynchronized gear |
|---|---|
| Forward gears | 5 |
| Reverse gears | 1 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | Open operator station |
Power take-off
| Rear PTO | Independent |
|---|---|
| PTO speed | 540rpm |
Dimensions
| Length | 128in |
|---|---|
| Height | 61in |
| Operating weight | 4,458lb |
Capacities
| Cooling system | 4.65gal |
|---|
Head to head
504 vs. Utility median
How the International Harvester 504 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 188 ci | 183 ci | +2% | 50th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 5 | 12 | -58% | 6th |
| Operating Weight | 4,458 lb | 5,303 lb | -16% | 43rd |
| Length | 128 in | 137 in | -6% | 38th |
| Height | 61 in | 94.1 in | -35% | 11th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,321–5,720 models).
Compare to tractors with similar specs
Commonly compared International Harvester tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| International Harvester 100 | — | 2,600 lb | — | Compare → |
| International Harvester 1026 | 127 hp | 11,100 lb | — | Compare → |
| International Harvester 1255 | 125 hp | 12,215 lb | — | Compare → |
| International Harvester 1256 | 113 hp | 10,405 lb | 1967–1969 | Compare → |
| International Harvester 130 | — | 2,800 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
International Harvester siblings
Brand sibling
Brand sibling
Brand sibling
Brand siblingExplore
Similar-spec models
Gallery
International Harvester 504 photos
FAQ
Common questions
When was the International Harvester 504 made?
The International Harvester 504 was manufactured from 1961 to 1968.
What hitch category is the International Harvester 504?
The International Harvester 504 uses a Category Category 1 hitch.
How many cylinders does the International Harvester 504 have?
The International Harvester 504 runs a 4-cylinder engine with a displacement of 187.5 ci.
What is the operating weight of the International Harvester 504?
In working trim, the International Harvester 504 comes in at roughly 4,458 lb.
Which transmission does the International Harvester 504 use?
The International Harvester 504 is equipped with an Unsynchronized gear transmission with 5 forward gears.
How do I maintain a International Harvester 504?
Routine service for the International Harvester 504 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
