UtilityPerformance profile
JCB Fastrac 4160
The JCB Fastrac 4160 is a powerful utility tractor built for tough jobs. It has a strong 6-cylinder diesel engine made by AGCO Power. This engine gives the tractor 160 horsepower, which is very high compared to other tractors. The Fastrac 4160 is big and heavy, weighing 16,700 pounds. It has four-wheel drive, which helps it work well in different types of fields. This tractor has some special features that make it stand out. It uses a CVT transmission, which means it can change speeds smoothly without shifting gears. The Fastrac 4160 has a comfortable cab for the driver and a three-point hitch at the back for attaching tools. It's also quite tall, standing at 118.1 inches high, with good ground clearance of 17.7 inches. This helps it move easily over rough ground. JCB, the company that makes this tractor, is known for building tough machines for farms and construction sites.
ManufacturerJCBPower160 hpEngine6-cylTransCVT
Quick specs
- Category
- Utility
- Engine Power Output
- 160hp
- Operating Weight
- 16,700 lb
- Transmission
- CVT
At a glance
How the Fastrac 4160 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
160 hp · 93rd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Fastrac 4160 ranks at the 93rd percentile for engine power among recorded utility tractors.
Overview
About the JCB Fastrac 4160
The JCB Fastrac 4160 is a powerful utility tractor built for tough jobs. It has a strong 6-cylinder diesel engine made by AGCO Power. This engine gives the tractor 160 horsepower, which is very high compared to other tractors. The Fastrac 4160 is big and heavy, weighing 16,700 pounds. It has four-wheel drive, which helps it work well in different types of fields. This tractor has some special features that make it stand out. It uses a CVT transmission, which means it can change speeds smoothly without shifting gears. The Fastrac 4160 has a comfortable cab for the driver and a three-point hitch at the back for attaching tools. It's also quite tall, standing at 118.1 inches high, with good ground clearance of 17.7 inches. This helps it move easily over rough ground. JCB, the company that makes this tractor, is known for building tough machines for farms and construction sites.
Full specifications
Every recorded spec
General
| Manufacturer | JCB |
|---|---|
| Model | Fastrac 4160 |
| Category | Utility tractor |
| Type | 4x4 4WD |
| Operating weight | 16,700lb |
Engine
| Make | AGCO Power |
|---|---|
| Model | 66AWF |
| Power | 160hp |
| Cylinders | 6 |
| Displacement | 402.8ci |
| Bore | 4.25in |
| Stroke | 4.72in |
Transmission
| Type | CVT |
|---|
Chassis & drive
| Chassis | 4x4 4WD |
|---|---|
| Drive | 4WD |
| Cab | Cab |
Dimensions
| Length | 212.6in |
|---|---|
| Width | 100.4in |
| Height | 118.1in |
| Operating weight | 16,700lb |
Head to head
Fastrac 4160 vs. Utility median
How the JCB Fastrac 4160 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 160 hp | 55 hp | +191% | 93rd |
| Engine Displacement | 403 ci | 183 ci | +120% | 90th |
| Cylinders | 6 | 4 | +50% | 93rd |
| Operating Weight | 16,700 lb | 5,303 lb | +215% | 94th |
| Length | 213 in | 137 in | +56% | 95th |
| Width | 100 in | 66 in | +52% | 97th |
| Height | 118 in | 94.1 in | +26% | 94th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared JCB tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| JCB Fastrac 2150 | 158 hp | 14,034 lb | — | Compare → |
| JCB Fastrac 155 | 168 hp | 14,374 lb | 1993–1997 | Compare → |
| JCB Fastrac 3155 | 168 hp | 14,916 lb | — | Compare → |
| JCB Fastrac 2135 | 148 hp | 13,075 lb | — | Compare → |
| JCB Fastrac 135 | 147 hp | 14,374 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO DT160 | 160 hp | 18,500 lb | 2002–2004 | Compare → |
| Agrinar T-160 | 161 hp | 13,450 lb | — | Compare → |
| AGCO RT155A | 162.5 hp | — | — | Compare → |
| Allis Chalmers HD16A | 163 hp | 31,500 lb | — | Compare → |
| Allis Chalmers 7050 | 156.49 hp | 19,530 lb | 1973–1974 | Compare → |
Explore
JCB siblings
Explore
Similar-spec models
Gallery
JCB Fastrac 4160 photos
FAQ
Common questions
How powerful is the JCB Fastrac 4160?
The JCB Fastrac 4160 has an engine power output of 160 hp. It is powered by a 6-cylinder engine displacing 402.8 ci.
What three-point hitch category does the JCB Fastrac 4160 use?
The JCB Fastrac 4160 has a Category III three-point hitch.
What is the working weight of the JCB Fastrac 4160?
The operating weight of the JCB Fastrac 4160 is approximately 16,700 lb.
What type of transmission does the JCB Fastrac 4160 have?
The JCB Fastrac 4160 uses a CVT transmission.
What routine service does the JCB Fastrac 4160 need?
Regular maintenance for the JCB Fastrac 4160 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
