Sub-CompactPerformance profile
Jinma JM-504
The Jinma JM-504 is a versatile 4WD tractor designed for various farming tasks. It features a powerful 50 hp diesel engine with 4 cylinders, cooled by liquid. This tractor can handle tough jobs with its 16 forward and 8 reverse gears, giving farmers lots of options for different tasks. The JM-504 is built to last, with a sturdy frame and agricultural tires for good traction in fields. It measures 152.2 inches long, 64 inches wide, and 81.3 inches tall, making it compact enough for many farm spaces. The tractor weighs 4,665 pounds, which helps it stay stable during work. It has a three-point hitch at the back, compatible with category I and II attachments, making it easy to use different tools.
ManufacturerJinmaPower50 hpEngine4-cyl
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 50hp
- Operating Weight
- 4,665 lb
At a glance
How the JM-504 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
50 hp · 90th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The JM-504 ranks at the 90th percentile for engine power among recorded sub-compact tractors.
Overview
About the Jinma JM-504
The Jinma JM-504 is a versatile 4WD tractor designed for various farming tasks. It features a powerful 50 hp diesel engine with 4 cylinders, cooled by liquid. This tractor can handle tough jobs with its 16 forward and 8 reverse gears, giving farmers lots of options for different tasks. The JM-504 is built to last, with a sturdy frame and agricultural tires for good traction in fields. It measures 152.2 inches long, 64 inches wide, and 81.3 inches tall, making it compact enough for many farm spaces. The tractor weighs 4,665 pounds, which helps it stay stable during work. It has a three-point hitch at the back, compatible with category I and II attachments, making it easy to use different tools.
Full specifications
Every recorded spec
General
| Manufacturer | Jinma |
|---|---|
| Model | JM-504 |
| Category | Sub-Compact tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 4,665lb |
Engine
| Make | Jinma |
|---|---|
| Power | 50hp |
| Cylinders | 4 |
Transmission
| Forward gears | 16 |
|---|---|
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
Dimensions
| Length | 152.2in |
|---|---|
| Width | 64in |
| Height | 81.3in |
| Operating weight | 4,665lb |
Head to head
JM-504 vs. Sub-Compact median
How the Jinma JM-504 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 50 hp | 26.9 hp | +86% | 90th |
| Cylinders | 4 | 3 | +33% | 90th |
| Forward Gears | 16 | 9 | +78% | 89th |
| Operating Weight | 4,665 lb | 2,700 lb | +73% | 90th |
| Length | 152 in | 113 in | +34% | 98th |
| Width | 64 in | 50.7 in | +26% | 83rd |
| Height | 81.3 in | 78.4 in | +4% | 54th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).
Compare to tractors with similar specs
Commonly compared Jinma tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Jinma JM-500 | 50 hp | 4,167 lb | — | Compare → |
| Jinma JM-450 | 45 hp | 4,166 lb | — | Compare → |
| Jinma 604 | 60 hp | 5,401 lb | — | Compare → |
| Jinma JM-350 | 35 hp | 3,263 lb | — | Compare → |
| Jinma JM-300 | 30 hp | 3,263 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5050 | 50 hp | 4,410 lb | 1977–1983 | Compare → |
| Allis Chalmers FD5 | 50 hp | 5,412 lb | — | Compare → |
| Belarus 4055 | 50 hp | 4,750 lb | — | Compare → |
| AGCO GT45 | 52 hp | 4,806 lb | — | Compare → |
| Agco GT45A | 52 hp | 5,820.3 lb | — | Compare → |
Explore
Jinma siblings
Explore
Similar-spec models
Gallery
Jinma JM-504 photos
FAQ
Common questions
What is the engine power output of the Jinma JM-504?
Rated engine output for the Jinma JM-504 is 50 hp, delivered by a 4-cylinder engine.
What hitch category is the Jinma JM-504?
The Jinma JM-504 uses a Category I,II hitch.
What is the operating weight of the Jinma JM-504?
In working trim, the Jinma JM-504 comes in at roughly 4,665 lb.
How do I maintain a Jinma JM-504?
Routine service for the Jinma JM-504 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
