Kubota B2630HSD
The Kubota B2630HSD is a compact tractor designed for various farming and landscaping tasks. It's powered by a Kubota D1105-E2-D21 engine, which is liquid-cooled and has 3 cylinders. This engine produces 26 hp at 2800 rpm, making it suitable for small to medium-sized jobs. The tractor uses a hydrostatic transmission with 3 forward and 3 reverse gears, allowing for smooth operation and easy speed control. This Kubota model is built for versatility and efficiency. It features a three-point hitch with a Category I rating, capable of lifting up to 1675.6 lb. The tractor's compact size, with a width of 54 inches, makes it easy to maneuver in tight spaces. Despite its small size, it has a solid operating weight of 1785.8 lb, providing good stability during work. The B2630HSD also comes with useful features like an 8.2-gallon fuel tank and can reach a maximum speed of 11.6 mph, making it suitable for various farm and garden tasks.
ManufacturerKubotaPower26 hp(19.4 kW)Class25–40 HP tractors →Engine3-cylinderTransmissionHST (Hydrostatic Transmission) 3 range
Key specifications
- Engine power
- 26hp
- Operating weight
- 1,785.8 lb
- Transmission
- HST (Hydrostatic Transmission) 3 range
Overview
About the Kubota B2630HSD
The Kubota B2630HSD is a compact tractor designed for various farming and landscaping tasks. It's powered by a Kubota D1105-E2-D21 engine, which is liquid-cooled and has 3 cylinders. This engine produces 26 hp at 2800 rpm, making it suitable for small to medium-sized jobs. The tractor uses a hydrostatic transmission with 3 forward and 3 reverse gears, allowing for smooth operation and easy speed control. This Kubota model is built for versatility and efficiency. It features a three-point hitch with a Category I rating, capable of lifting up to 1675.6 lb. The tractor's compact size, with a width of 54 inches, makes it easy to maneuver in tight spaces. Despite its small size, it has a solid operating weight of 1785.8 lb, providing good stability during work. The B2630HSD also comes with useful features like an 8.2-gallon fuel tank and can reach a maximum speed of 11.6 mph, making it suitable for various farm and garden tasks.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | B2630HSD |
| Operating weight | 1,785.8lb(810 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | D1105-E2-D21 |
| Power | 26hp(19.39 kW) |
| Cylinders | 3 |
| Displacement | 68.5ci(1.12 L) |
Transmission
| Type | HST (Hydrostatic Transmission) 3 range |
|---|---|
| Forward gears | 3 |
| Reverse gears | 3 |
Dimensions
| Width | 54in(1,372 mm) |
|---|---|
| Operating weight | 1,785.8lb(810 kg) |
Capacities
| Cooling system | 0.28gal(1.06 L) |
|---|
Calculators
Calculators for the B2630HSD
PTO power
About 22 to 23 PTO hp
Estimated from the 26 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 26 hp tractor can run
The calculator sizes mowers, tillers, discs, plows and balers for this tractor.
Ballast
80 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
26 hp is 19.4 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
B2630HSD vs. category median
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota B2630HSD photos
FAQ
Frequently asked questions
How powerful is the Kubota B2630HSD?
The Kubota B2630HSD has an engine power output of 26 hp. It is powered by a 3-cylinder engine displacing 68.5 ci.
What hitch category is the Kubota B2630HSD?
The Kubota B2630HSD uses a Category I hitch with a lift capacity of 1,675.6 lb.
What is the working weight of the Kubota B2630HSD?
The operating weight of the Kubota B2630HSD is approximately 1,785.8 lb.
What type of transmission does the Kubota B2630HSD have?
The Kubota B2630HSD uses a HST (Hydrostatic Transmission) 3 range transmission offering 3 forward gears.
What routine service does the Kubota B2630HSD need?
Regular maintenance for the Kubota B2630HSD includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
