UtilityPerformance profile
Kubota BX1860
The Kubota BX1860 is a small but capable utility tractor. It was made from 2009 to 2013. This tractor has a 4-wheel drive system and hydrostatic power steering, which makes it easy to control. It uses a hydrostatic transmission with 2 ranges, allowing for smooth speed changes. Under the hood, the BX1860 has a Kubota D722 diesel engine. This engine has 3 cylinders and is liquid-cooled. It produces 18 horsepower, which is on the lower end for tractors. The engine runs at a very high 3200 rpm. The tractor is compact, measuring 80.1 inches long, 45.1 inches wide, and 69.3 inches tall. It weighs 1256 pounds, which is quite light for a tractor. The BX1860 has lawn/turf tires, making it good for use on grass. It also has a three-point hitch at the back that can lift up to 992 pounds, which is about average for its size.
ManufacturerKubotaPower18 hpEngine3-cylTransHydrostatic
Quick specs
- Category
- Utility
- Engine Power Output
- 18hp
- Operating Weight
- 1,256 lb
- Transmission
- Hydrostatic
At a glance
How the BX1860 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
18 hp · 6th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The BX1860 ranks at the 6th percentile for engine power among recorded utility tractors.
Overview
About the Kubota BX1860
The Kubota BX1860 is a small but capable utility tractor. It was made from 2009 to 2013. This tractor has a 4-wheel drive system and hydrostatic power steering, which makes it easy to control. It uses a hydrostatic transmission with 2 ranges, allowing for smooth speed changes. Under the hood, the BX1860 has a Kubota D722 diesel engine. This engine has 3 cylinders and is liquid-cooled. It produces 18 horsepower, which is on the lower end for tractors. The engine runs at a very high 3200 rpm. The tractor is compact, measuring 80.1 inches long, 45.1 inches wide, and 69.3 inches tall. It weighs 1256 pounds, which is quite light for a tractor. The BX1860 has lawn/turf tires, making it good for use on grass. It also has a three-point hitch at the back that can lift up to 992 pounds, which is about average for its size.
Full specifications
Every recorded spec
General
| Manufacturer | Kubota |
|---|---|
| Model | BX1860 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Years built | 2009–2013 |
| Operating weight | 1,256lb |
Engine
| Make | Kubota |
|---|---|
| Model | D722 |
| Power | 18hp |
| Cylinders | 3 |
| Displacement | 43.9ci |
| Bore | 2.64in |
| Stroke | 2.68in |
Transmission
| Type | Hydrostatic |
|---|
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
| Brakes | Wet disc type |
| Cab | Two-post fixed ROPS |
Hydraulics
| Type | Open center |
|---|
Power take-off
| Rear PTO | Independent |
|---|---|
| PTO speed | 540rpm |
Dimensions
| Length | 80.1in |
|---|---|
| Width | 45.1in |
| Height | 69.3in |
| Operating weight | 1,256lb |
Capacities
| Cooling system | 0.65gal |
|---|
Head to head
BX1860 vs. Utility median
How the Kubota BX1860 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 18 hp | 55 hp | -67% | 6th |
| Engine Displacement | 43.9 ci | 183 ci | -76% | 1st |
| Cylinders | 3 | 4 | -25% | 23rd |
| Operating Weight | 1,256 lb | 5,303 lb | -76% | 2nd |
| Length | 80.1 in | 137 in | -41% | 2nd |
| Width | 45.1 in | 66 in | -32% | 10th |
| Height | 69.3 in | 94.1 in | -26% | 15th |
| 3-Point Hitch Capacity | 992 lb | 3,197 lb | -69% | 5th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 1,083–5,720 models).
Compare to tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota B1710 | 18 hp | 1,455 lb | 2000–2005 | Compare → |
| Kubota B7410 | 18 hp | 1,323 lb | 2004–2007 | Compare → |
| Kubota BX1800 | 18 hp | 1,257 lb | 2001–2003 | Compare → |
| Kubota BX1830 | 18 hp | 1,255 lb | 2004–2006 | Compare → |
| Kubota BX1850 | 18 hp | 1,255 lb | 2006–2008 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5015 | 18 hp | 1,278 lb | 1982–1985 | Compare → |
| Allis Chalmers WC (1938-1948) | 18 hp | 3,792 lb | 1938–1948 | Compare → |
| Bolens 1886 | 18 hp | — | 1971–1972 | Compare → |
| CaseIH 235 | 18 hp | 1,350 lb | — | Compare → |
| CaseIH Farmall DX18E | 18 hp | 1,314 lb | — | Compare → |
Explore
Kubota siblings
Explore
Similar-spec models
Gallery
Kubota BX1860 photos
FAQ
Common questions
When was the Kubota BX1860 in production?
Kubota BX1860 production started in 2009 and ended in 2013.
What transmission is in the Kubota BX1860?
Transmission on the Kubota BX1860 is Hydrostatic.
What hydraulics does the Kubota BX1860 have?
The Kubota BX1860 uses an Open center hydraulic system.
What three-point hitch category does the Kubota BX1860 use?
The Kubota BX1860 has a Category I three-point hitch rated to lift 992 lb.
How much horsepower does the Kubota BX1860 have?
The Kubota BX1860 produces 18 hp from its 3-cylinder engine. Engine displacement is 43.9 ci.
How much does the Kubota BX1860 weigh?
The Kubota BX1860 weighs about 1,256 lb in operating condition.
What maintenance does the Kubota BX1860 require?
Like any tractor, the Kubota BX1860 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
