Kubota L5240HST
The Kubota L5240HST is a versatile utility tractor built for various farm and land management tasks. It features a powerful 4-cylinder, turbocharged diesel engine that produces 54 horsepower. This engine power is above average compared to similar tractors, making it suitable for demanding jobs. The tractor has a fuel capacity of 14.3 gallons, allowing for long work sessions without frequent refueling. One of the standout features of the L5240HST is its hydrostatic transmission with three forward and reverse gears. This transmission type offers smooth operation and easy speed control. The tractor's four-wheel drive system provides excellent traction in various terrains. With a turning radius of 9.2 feet and a top speed of 15.5 mph, it offers good maneuverability and efficiency. The three-point hitch at the rear can lift up to 2,976.3 pounds, which is very high compared to other tractors in its class. This high lifting capacity makes it ideal for handling heavy implements and loads.
ManufacturerKubotaPower54 hp(40.3 kW)Class40–60 HP tractors →Engine4-cylinderTransmissionHydrostatic
Key specifications
- Category
- Utility
- Engine power
- 54hp
- PTO horsepower
- 45
- Operating weight
- 3,902.2 lb
- Transmission
- Hydrostatic
Category comparison
L5240HST compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
54 hp · 49th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The L5240HST ranks at the 49th percentile for engine power among recorded utility tractors.
Overview
About the Kubota L5240HST
The Kubota L5240HST is a versatile utility tractor built for various farm and land management tasks. It features a powerful 4-cylinder, turbocharged diesel engine that produces 54 horsepower. This engine power is above average compared to similar tractors, making it suitable for demanding jobs. The tractor has a fuel capacity of 14.3 gallons, allowing for long work sessions without frequent refueling. One of the standout features of the L5240HST is its hydrostatic transmission with three forward and reverse gears. This transmission type offers smooth operation and easy speed control. The tractor's four-wheel drive system provides excellent traction in various terrains. With a turning radius of 9.2 feet and a top speed of 15.5 mph, it offers good maneuverability and efficiency. The three-point hitch at the rear can lift up to 2,976.3 pounds, which is very high compared to other tractors in its class. This high lifting capacity makes it ideal for handling heavy implements and loads.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | L5240HST |
| Category | Utility tractor |
| Type | 4WD |
| Operating weight | 3,902.2lb(1,770 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | E-TVCS |
| Power | 54hp(40.27 kW) |
| Cylinders | 4 |
| Displacement | 148.5ci(2.43 L) |
Transmission
| Type | Hydrostatic |
|---|---|
| Forward gears | 3 |
| Reverse gears | 3 |
Chassis & drive
| Drive | 4WD |
|---|
Hydraulics
| Pump flow | 14.7gpm(55.65 L/min) |
|---|
Power take-off
| PTO power | 45hp(33.56 kW) |
|---|
Dimensions
| Length | 126in(3,200 mm) |
|---|---|
| Width | 68.4in(1,737 mm) |
| Height | 102in(2,591 mm) |
| Operating weight | 3,902.2lb(1,770 kg) |
Capacities
| Fuel tank | 14.3gal(54.13 L) |
|---|
Closest alternatives
L5240HST compared with the nearest models by horsepower
The closest utility models to the Kubota L5240HST by rated horsepower are the Kubota L5460 and the Kubota M5030. The Kubota L5460 matches it on rated power and weighs 90 lb more. The Kubota M5030 matches it on rated power and weighs 290 lb more. Of the 3 models, the L5240HST has the lowest weight per horsepower at 72 lb per hp.
| Spec | Kubota L5240HST | Kubota L5460 | Kubota M5030 |
|---|---|---|---|
| Engine power | 54 hp40.3 kW | 54 hp40.3 kW | 54 hp40.3 kW |
| Operating weight | 3,902 lb1,770 kg | 3,990 lb1,810 kg | 4,188 lb1,900 kg |
| Weight per hp | 72 lb/hp44 kg/kW | 74 lb/hp45 kg/kW | 78 lb/hp47 kg/kW |
| Displacement | 148.5 ci2.43 L | 148.5 ci2.43 L | 170.3 ci2.79 L |
| Cylinders | 4 | 4 | 6 |
| Transmission | Hydrostatic | Hydrostatic | Partially Synchronized |
| Drive | 4WD | 4WD | 2WD |
| Years built | - | 2013+ | 1986-1996 |
Calculators
Calculators for the L5240HST
PTO power
About 45 to 49 PTO hp
Rated PTO power is 45 hp. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 54 hp tractor can run
Maximum size is about a 6.5 ft rotary cutter or a 5.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
84 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
54 hp is 40.3 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
L5240HST vs. Utility median
Kubota L5240HST compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 54 hp | 55 hp | -2% | 49th |
| Engine Displacement | 149 ci | 183 ci | -19% | 37th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 3 | 12 | -75% | 3rd |
| Operating Weight | 3,902 lb | 5,303 lb | -26% | 36th |
| Length | 126 in | 137 in | -8% | 36th |
| Width | 68.4 in | 66 in | +4% | 56th |
| Height | 102 in | 94.1 in | +8% | 70th |
| 3-Point Hitch Capacity | 2,976 lb | 3,197 lb | -7% | 46th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 1,083–5,720 models).
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota L5240HST photos
FAQ
Frequently asked questions
How powerful is the Kubota L5240HST?
The Kubota L5240HST has an engine power output of 54 hp. It is powered by a 4-cylinder engine displacing 148.5 ci.
What hitch category is the Kubota L5240HST?
The Kubota L5240HST uses a Category Cat I & II hitch with a lift capacity of 2,976.3 lb.
What is the PTO power rating of the Kubota L5240HST?
The Kubota L5240HST delivers 45 hp at the power take-off.
What is the working weight of the Kubota L5240HST?
The operating weight of the Kubota L5240HST is approximately 3,902.2 lb.
What is the fuel capacity of the Kubota L5240HST?
The Kubota L5240HST's fuel tank holds 14.3 gal.
What type of transmission does the Kubota L5240HST have?
The Kubota L5240HST uses a Hydrostatic transmission offering 3 forward gears.
What routine service does the Kubota L5240HST need?
Regular maintenance for the Kubota L5240HST includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
