Kubota M110X
The Kubota M110X is a powerful row crop tractor built for tough farm work. It has a strong 4-wheel drive system and a sturdy 4x4 chassis, making it great for handling rough terrain. The tractor is powered by a Kubota V3800-TI-CRS engine, which is a 4-cylinder diesel engine with turbocharging. This engine gives the M110X 110 horsepower, which is above average for its class. The M110X has a partial powershift transmission with 16 forward and 16 reverse gears, offering plenty of options for different tasks. It features hydrostatic power steering for easy control and a Category 2/3 hitch at the rear for attaching various implements. The tractor's size is compact yet capable, measuring 167 inches long, 83.7 inches wide, and 105.9 inches tall. With an operating weight of 9,050 pounds, it's built to handle heavy-duty farm work while being lighter than many other tractors in its class.
ManufacturerKubotaPower110 hp(82.0 kW)Class100–150 HP tractors →Engine4-cylinderTransmissionPartial powershift
Key specifications
- Category
- Row Crop
- Engine power
- 110hp
- Operating weight
- 9,050 lb
- Transmission
- Partial powershift
Category comparison
M110X compared with its category
vs. Row Crop medianDistribution
Engine Power (hp)
All recorded Row Crop tractors
110 hp · 32nd
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The M110X ranks at the 32nd percentile for engine power among recorded row crop tractors.
Overview
About the Kubota M110X
The Kubota M110X is a powerful row crop tractor built for tough farm work. It has a strong 4-wheel drive system and a sturdy 4x4 chassis, making it great for handling rough terrain. The tractor is powered by a Kubota V3800-TI-CRS engine, which is a 4-cylinder diesel engine with turbocharging. This engine gives the M110X 110 horsepower, which is above average for its class. The M110X has a partial powershift transmission with 16 forward and 16 reverse gears, offering plenty of options for different tasks. It features hydrostatic power steering for easy control and a Category 2/3 hitch at the rear for attaching various implements. The tractor's size is compact yet capable, measuring 167 inches long, 83.7 inches wide, and 105.9 inches tall. With an operating weight of 9,050 pounds, it's built to handle heavy-duty farm work while being lighter than many other tractors in its class.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | M110X |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 9,050lb(4,105 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | V3800-TI-CRS |
| Power | 110hp(82.03 kW) |
| Cylinders | 4 |
| Displacement | 230ci(3.77 L) |
| Bore | 3.94in(100.1 mm) |
| Stroke | 4.72in(119.9 mm) |
Transmission
| Type | Partial powershift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 167in(4,242 mm) |
|---|---|
| Width | 83.7in(2,126 mm) |
| Height | 105.9in(2,690 mm) |
| Operating weight | 9,050lb(4,105 kg) |
Capacities
| Cooling system | 2.38gal(9.01 L) |
|---|
Closest alternatives
M110X compared with the nearest models by horsepower
The closest row crop models to the Kubota M110X by rated horsepower are the John Deere 7220 and the John Deere 7210. The John Deere 7220 matches it on rated power and weighs 2,790 lb more, at 108 lb per horsepower against 82 lb. The John Deere 7210 matches it on rated power and weighs 2,440 lb more, so it carries more weight per horsepower, which helps traction in draft work. Of the 3 models, the M110X has the lowest weight per horsepower at 82 lb per hp.
| Spec | Kubota M110X | John Deere 7220 | John Deere 7210 |
|---|---|---|---|
| Engine power | 110 hp82 kW | 110 hp82 kW | 110 hp82 kW |
| Operating weight | 9,050 lb4,105 kg | 11,839 lb5,370 kg | 11,491 lb5,212 kg |
| Weight per hp | 82 lb/hp50 kg/kW | 108 lb/hp65 kg/kW | 104 lb/hp64 kg/kW |
| Displacement | 230 ci3.77 L | 359 ci5.88 L | 414 ci6.78 L |
| Cylinders | 4 | 6 | 6 |
| Transmission | Partial powershift | Partial power shift | Synchronized / Partial Power Shift |
| Drive | 4WD | - | 2WD |
| Years built | - | 2003-2007 | 1997-2002 |
Calculators
Calculators for the M110X
PTO power
About 91 to 99 PTO hp
Estimated from the 110 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 110 hp tractor can run
Maximum size is about a 13 ft rotary cutter or a 11 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
96 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
110 hp is 82.0 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
M110X vs. Row Crop median
Kubota M110X compared with other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 110 hp | 138 hp | -20% | 32nd |
| Engine Displacement | 230 ci | 391 ci | -41% | 12th |
| Cylinders | 4 | 6 | -33% | 17th |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 9,050 lb | 12,307 lb | -26% | 26th |
| Length | 167 in | 180 in | -7% | 32nd |
| Width | 83.7 in | 91.2 in | -8% | 33rd |
| Height | 106 in | 114 in | -7% | 27th |
Medians and percentiles are calculated from the row crop tractors in the database that have a recorded value for each specification (sample size 806–1,417 models).
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota M110X photos
FAQ
Frequently asked questions
How powerful is the Kubota M110X?
The Kubota M110X has an engine power output of 110 hp. It is powered by a 4-cylinder engine displacing 230 ci.
What is the working weight of the Kubota M110X?
The operating weight of the Kubota M110X is approximately 9,050 lb.
What type of transmission does the Kubota M110X have?
The Kubota M110X uses a Partial powershift transmission offering 16 forward gears.
What hydraulics does the Kubota M110X have?
The Kubota M110X uses an Open center hydraulic system.
What three-point hitch category does the Kubota M110X use?
The Kubota M110X has a Category Category 3 three-point hitch.
What routine service does the Kubota M110X need?
Regular maintenance for the Kubota M110X includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
