AgriculturalPerformance profile
McCormick Intl F120
The McCormick Intl F120 is a powerful orchard and vineyard tractor designed for agricultural use. It features a 2WD chassis and a synchro shuttle transmission, making it easy to maneuver in tight spaces. The tractor is powered by a Perkins 1104D-44TA engine, which is a liquid-cooled, turbocharged diesel engine with 4 cylinders. This engine packs a punch, delivering 110.2 hp at 2200 RPM, which is very high compared to other tractors in its class. The F120 has a compact design, measuring 157.8 inches long and 56.6 inches wide, perfect for working in orchards and vineyards. It weighs 5600 lb, which is above average for its size, providing good stability during operation. The tractor comes with agricultural tires on both front and rear, a category II hitch, and an optional transmission or live PTO. It features an open operator station and an electric starter for convenience. With its high torque of 302.4 lb-ft at 1400 RPM, the F120 can handle tough jobs with ease, making it a reliable choice for farmers looking for a strong and efficient orchard tractor.
ManufacturerMcCormick IntlPower110.2 hpEngine4-cylTransSynchro Shuttle
Quick specs
- Category
- Agricultural
- Engine Power Output
- 110hp
- Operating Weight
- 5,600 lb
- Transmission
- Synchro Shuttle
At a glance
How the F120 compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
110.2 hp · 51st
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The F120 ranks at the 51st percentile for engine power among recorded agricultural tractors.
Overview
About the McCormick Intl F120
The McCormick Intl F120 is a powerful orchard and vineyard tractor designed for agricultural use. It features a 2WD chassis and a synchro shuttle transmission, making it easy to maneuver in tight spaces. The tractor is powered by a Perkins 1104D-44TA engine, which is a liquid-cooled, turbocharged diesel engine with 4 cylinders. This engine packs a punch, delivering 110.2 hp at 2200 RPM, which is very high compared to other tractors in its class. The F120 has a compact design, measuring 157.8 inches long and 56.6 inches wide, perfect for working in orchards and vineyards. It weighs 5600 lb, which is above average for its size, providing good stability during operation. The tractor comes with agricultural tires on both front and rear, a category II hitch, and an optional transmission or live PTO. It features an open operator station and an electric starter for convenience. With its high torque of 302.4 lb-ft at 1400 RPM, the F120 can handle tough jobs with ease, making it a reliable choice for farmers looking for a strong and efficient orchard tractor.
Full specifications
Every recorded spec
General
| Manufacturer | McCormick Intl |
|---|---|
| Model | F120 |
| Category | Agricultural tractor |
| Type | 4x2 2WD |
| Operating weight | 5,600lb |
Engine
| Make | Perkins |
|---|---|
| Model | 1104D-44TA |
| Power | 110.2hp |
| Cylinders | 4 |
| Displacement | 268ci |
| Bore | 4.13in |
| Stroke | 5in |
Transmission
| Type | Synchro Shuttle |
|---|
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Cab | Open Station |
Power take-off
| Rear PTO | Optional Transmission or Live PTO |
|---|
Dimensions
| Length | 157.8in |
|---|---|
| Width | 56.6in |
| Operating weight | 5,600lb |
Head to head
F120 vs. Agricultural median
How the McCormick Intl F120 compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 110 hp | 110 hp | 0% | 51st |
| Engine Displacement | 268 ci | 336 ci | -20% | 36th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Operating Weight | 5,600 lb | 10,914 lb | -49% | 16th |
| Length | 158 in | 173 in | -9% | 35th |
| Width | 56.6 in | 79.5 in | -29% | 22nd |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared McCormick Intl tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| McCormick Intl F110 | 102 hp | 6,316 lb | — | Compare → |
| McCormick Intl F105 | 98 hp | 5,766 lb | — | Compare → |
| McCormick Intl F95 | 95 hp | 5,766 lb | — | Compare → |
| McCormick Intl VF100 | 95 hp | — | — | Compare → |
| McCormick Intl F100 | 92.5 hp | 5,765 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO LT85A | 110.1 hp | 10,605 lb | — | Compare → |
| AGCO LT90A | 110 hp | 8,820 lb | — | Compare → |
| Agrinar T-110 | 110 hp | — | — | Compare → |
| Allis Chalmers HD11 | 110 hp | 21,000 lb | 1955–1965 | Compare → |
| Apollo 1104 | 110 hp | 10,710 lb | — | Compare → |
Explore
McCormick Intl siblings
Explore
Similar-spec models
Gallery
McCormick Intl F120 photos
FAQ
Common questions
What is the engine power output of the McCormick Intl F120?
Rated engine output for the McCormick Intl F120 is 110.2 hp, delivered by a 4-cylinder engine. The engine displaces 268 ci.
Which transmission does the McCormick Intl F120 use?
The McCormick Intl F120 is equipped with a Synchro Shuttle transmission.
What three-point hitch category does the McCormick Intl F120 use?
The McCormick Intl F120 has a Category II three-point hitch.
What is the operating weight of the McCormick Intl F120?
In working trim, the McCormick Intl F120 comes in at roughly 5,600 lb.
How do I maintain a McCormick Intl F120?
Routine service for the McCormick Intl F120 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
