Minneapolis-Moline M-604
The Minneapolis-Moline M-604 is a powerful gasoline-powered tractor designed for farm work. It features a 4-cylinder engine with a displacement of 336 cubic inches, which provides strong performance for various tasks. The engine runs at 1500 RPM, offering a good balance of power and efficiency. This tractor comes with a two-speed power shift transmission, giving the operator 10 forward gears and 2 reverse gears. This wide range of speeds allows for versatility in different field conditions. The M-604 is equipped with a three-point hitch at the rear, which is category II, making it compatible with many farm implements. It has agricultural tires on both front and rear, with sizes of 9.50-24 and 18.4-34 respectively. The tractor's dimensions are 140 inches long, 84 inches wide, and 72 inches high, with a wheelbase of 84.5 inches. Weighing 7,220 pounds, it's a sturdy machine built to handle tough jobs on the farm.
ManufacturerMinneapolis-MolineEngine4-cylTransTwo-speed power shift
Quick specs
- Category
- Utility
- Operating Weight
- 7,220 lb
- Transmission
- Two-speed power shift
Overview
About the Minneapolis-Moline M-604
The Minneapolis-Moline M-604 is a powerful gasoline-powered tractor designed for farm work. It features a 4-cylinder engine with a displacement of 336 cubic inches, which provides strong performance for various tasks. The engine runs at 1500 RPM, offering a good balance of power and efficiency. This tractor comes with a two-speed power shift transmission, giving the operator 10 forward gears and 2 reverse gears. This wide range of speeds allows for versatility in different field conditions. The M-604 is equipped with a three-point hitch at the rear, which is category II, making it compatible with many farm implements. It has agricultural tires on both front and rear, with sizes of 9.50-24 and 18.4-34 respectively. The tractor's dimensions are 140 inches long, 84 inches wide, and 72 inches high, with a wheelbase of 84.5 inches. Weighing 7,220 pounds, it's a sturdy machine built to handle tough jobs on the farm.
Full specifications
Every recorded spec
General
| Manufacturer | Minneapolis-Moline |
|---|---|
| Model | M-604 |
| Category | Utility tractor |
| Operating weight | 7,220lb |
Engine
| Make | Minneapolis-Moline |
|---|---|
| Cylinders | 4 |
| Displacement | 336ci |
| Bore | 4.63in |
| Stroke | 5in |
Transmission
| Type | Two-speed power shift |
|---|---|
| Forward gears | 10 |
| Reverse gears | 2 |
Dimensions
| Length | 140in |
|---|---|
| Width | 84in |
| Height | 72in |
| Operating weight | 7,220lb |
Head to head
M-604 vs. Utility median
How the Minneapolis-Moline M-604 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 336 ci | 183 ci | +84% | 86th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 10 | 12 | -17% | 39th |
| Operating Weight | 7,220 lb | 5,303 lb | +36% | 69th |
| Length | 140 in | 137 in | +2% | 55th |
| Width | 84 in | 66 in | +27% | 87th |
| Height | 72 in | 94.1 in | -23% | 17th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Minneapolis-Moline tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Minneapolis-Moline 335 | 35.71 hp | 3,070 lb | — | Compare → |
| Minneapolis-Moline 445 Universal | 41.95 hp | 7,885 lb | — | Compare → |
| Minneapolis-Moline A4T-1600 | 169 hp | 19,850 lb | — | Compare → |
| Minneapolis-Moline BF | — | 3,636 lb | — | Compare → |
| Minneapolis-Moline BG | — | 2,880 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
Minneapolis-Moline siblings
Brand sibling
Brand siblingExplore
Similar-spec models
Gallery
Minneapolis-Moline M-604 photos
FAQ
Common questions
How many cylinders does the Minneapolis-Moline M-604 have?
The Minneapolis-Moline M-604 runs a 4-cylinder engine with a displacement of 336 ci.
How much does the Minneapolis-Moline M-604 weigh?
The Minneapolis-Moline M-604 weighs about 7,220 lb in operating condition.
What transmission is in the Minneapolis-Moline M-604?
Transmission on the Minneapolis-Moline M-604 is Two-speed power shift, with 10 forward speeds.
What hitch category is the Minneapolis-Moline M-604?
The Minneapolis-Moline M-604 uses a Category II hitch.
What maintenance does the Minneapolis-Moline M-604 require?
Like any tractor, the Minneapolis-Moline M-604 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
