Row Crop tractorsSpec sheet
New Holland T6.145
The New Holland T6.145 is a powerful row crop tractor built for tough farm work. It has a 4WD drive system and a 4x4 MFWD chassis, making it great for handling various field tasks. The tractor comes with a partial power shift transmission that offers 16 forward and 16 reverse gears, giving farmers lots of options for different jobs. Under the hood, the T6.145 has a FPT engine with 4 cylinders and 274 cubic inches of displacement. This diesel engine is turbocharged and liquid-cooled, producing 116 horsepower at 2200 RPM. The tractor has average engine power for its class, but its engine size is below average. It's built to meet Tier IV emissions standards and uses selective catalytic reduction (SCR) to keep exhaust clean. The T6.145 weighs 10,561 pounds and has a comfortable cab for the operator. It also features a Category II hitch at the rear for attaching various implements.
ManufacturerNew HollandPower116 hp(86.5 kW)Class100–150 HP tractors →Engine4-cylinderTransmissionPartial Power Shift
Image not recorded
Key specifications
- Category
- Row Crop
- Engine power
- 116hp
- Operating weight
- 10,561 lb
- Transmission
- Partial Power Shift
Category comparison
T6.145 compared with its category
vs. Row Crop medianDistribution
Engine Power (hp)
All recorded Row Crop tractors
116 hp · 36th
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The T6.145 ranks at the 36th percentile for engine power among recorded row crop tractors.
Overview
About the New Holland T6.145
The New Holland T6.145 is a powerful row crop tractor built for tough farm work. It has a 4WD drive system and a 4x4 MFWD chassis, making it great for handling various field tasks. The tractor comes with a partial power shift transmission that offers 16 forward and 16 reverse gears, giving farmers lots of options for different jobs. Under the hood, the T6.145 has a FPT engine with 4 cylinders and 274 cubic inches of displacement. This diesel engine is turbocharged and liquid-cooled, producing 116 horsepower at 2200 RPM. The tractor has average engine power for its class, but its engine size is below average. It's built to meet Tier IV emissions standards and uses selective catalytic reduction (SCR) to keep exhaust clean. The T6.145 weighs 10,561 pounds and has a comfortable cab for the operator. It also features a Category II hitch at the rear for attaching various implements.
Full specifications
Recorded specifications
General
| Manufacturer | New Holland |
|---|---|
| Model | T6.145 |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 10,561lb(4,790 kg) |
Engine
| Make | FPT |
|---|---|
| Power | 116hp(86.5 kW) |
| Cylinders | 4 |
| Displacement | 274ci(4.49 L) |
| Bore | 4.1in(104 mm) |
| Stroke | 5.2in(132.1 mm) |
Transmission
| Type | Partial Power Shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Cab | Cab |
Dimensions
| Length | 179in(4,547 mm) |
|---|---|
| Operating weight | 10,561lb(4,790 kg) |
Closest alternatives
T6.145 compared with the nearest models by horsepower
The closest row crop models to the New Holland T6.145 by rated horsepower are the New Holland T6.155 and the John Deere 7130. The New Holland T6.155 matches it on rated power and weighs 480 lb more. The John Deere 7130 matches it on rated power and weighs 1,530 lb more, at 104 lb per horsepower against 91 lb. Of the 3 models, the T6.145 has the lowest weight per horsepower at 91 lb per hp.
| Spec | New Holland T6.145 | New Holland T6.155 | John Deere 7130 |
|---|---|---|---|
| Engine power | 116 hp86.5 kW | 116 hp86.5 kW | 116 hp86.5 kW |
| Operating weight | 10,561 lb4,790 kg | 11,045 lb5,010 kg | 12,090 lb5,484 kg |
| Weight per hp | 91 lb/hp55 kg/kW | 95 lb/hp58 kg/kW | 104 lb/hp63 kg/kW |
| Displacement | 274 ci4.49 L | 410.6 ci6.73 L | 274 ci4.49 L |
| Cylinders | 4 | 6 | 4 |
| Transmission | Partial Power Shift | Dual Command | PowrQuad-Plus Diesel, 16-speed selective gear fixed ratio with partial (4) range operator controlled power shift |
| Drive | 4WD | MFWD | 4WD |
Calculators
Calculators for the T6.145
PTO power
About 96 to 104 PTO hp
Estimated from the 116 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 116 hp tractor can run
Maximum size is about a 14 ft rotary cutter or a 12 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
106 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
116 hp is 86.5 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
T6.145 vs. Row Crop median
New Holland T6.145 compared with other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 116 hp | 138 hp | -16% | 36th |
| Engine Displacement | 274 ci | 391 ci | -30% | 24th |
| Cylinders | 4 | 6 | -33% | 17th |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 10,561 lb | 12,307 lb | -14% | 36th |
| Length | 179 in | 180 in | 0% | 50th |
Medians and percentiles are calculated from the row crop tractors in the database that have a recorded value for each specification (sample size 1,157–1,417 models).
Same manufacturer
Other New Holland models
Other manufacturers
Models with similar horsepower
FAQ
Frequently asked questions
How much horsepower does the New Holland T6.145 have?
The New Holland T6.145 produces 116 hp from its 4-cylinder engine. Engine displacement is 274 ci.
How much does the New Holland T6.145 weigh?
The New Holland T6.145 weighs about 10,561 lb in operating condition.
What transmission is in the New Holland T6.145?
Transmission on the New Holland T6.145 is Partial Power Shift, with 16 forward speeds.
What hitch category is the New Holland T6.145?
The New Holland T6.145 uses a Category Category 3 hitch.
What maintenance does the New Holland T6.145 require?
The New Holland T6.145 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
