UtilityPerformance profile
New Holland TB110
The New Holland TB110 is a powerful utility tractor built for tough farm work. It has a 2WD chassis with power steering, making it easy to handle. The tractor runs on a New Holland diesel engine with four cylinders and a turbocharger. This engine is liquid-cooled and puts out an impressive 110 hp at 2100 rpm, which is very high for its class. The engine size is also above average at 304 cubic inches. This tractor is built to last, weighing 6125 lb and measuring 147 inches long and 99.5 inches tall. It has a Category II hitch at the rear for attaching various farm tools. The TB110 comes with an open center hydraulic system and a ROPS (Roll-Over Protective Structure) for safety. It offers different transmission options, including a standard gear type, a Dual Command with two-speed power shift, and a creeper for slow-speed work. The tractor meets Tier II emissions standards, showing New Holland's commitment to cleaner farming.
ManufacturerNew HollandPower110 hpEngine4-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 110hp
- Operating Weight
- 6,125 lb
- Transmission
- Gear
At a glance
How the TB110 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
110 hp · 87th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The TB110 ranks at the 87th percentile for engine power among recorded utility tractors.
Overview
About the New Holland TB110
The New Holland TB110 is a powerful utility tractor built for tough farm work. It has a 2WD chassis with power steering, making it easy to handle. The tractor runs on a New Holland diesel engine with four cylinders and a turbocharger. This engine is liquid-cooled and puts out an impressive 110 hp at 2100 rpm, which is very high for its class. The engine size is also above average at 304 cubic inches. This tractor is built to last, weighing 6125 lb and measuring 147 inches long and 99.5 inches tall. It has a Category II hitch at the rear for attaching various farm tools. The TB110 comes with an open center hydraulic system and a ROPS (Roll-Over Protective Structure) for safety. It offers different transmission options, including a standard gear type, a Dual Command with two-speed power shift, and a creeper for slow-speed work. The tractor meets Tier II emissions standards, showing New Holland's commitment to cleaner farming.
Full specifications
Every recorded spec
General
| Manufacturer | New Holland |
|---|---|
| Model | TB110 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 6,125lb |
Engine
| Make | New Holland |
|---|---|
| Power | 110hp |
| Cylinders | 4 |
| Displacement | 304ci |
| Bore | 4.4in |
| Stroke | 5in |
Transmission
| Type | Gear |
|---|
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power Steering |
| Cab | ROPS |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 147in |
|---|---|
| Height | 99.5in |
| Operating weight | 6,125lb |
Capacities
| Cooling system | 3.4gal |
|---|
Head to head
TB110 vs. Utility median
How the New Holland TB110 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 110 hp | 55 hp | +100% | 87th |
| Engine Displacement | 304 ci | 183 ci | +66% | 84th |
| Cylinders | 4 | 4 | at median | 50th |
| Operating Weight | 6,125 lb | 5,303 lb | +16% | 58th |
| Length | 147 in | 137 in | +8% | 63rd |
| Height | 99.5 in | 94.1 in | +6% | 64th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,321–5,720 models).
Compare to tractors with similar specs
Commonly compared New Holland tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| New Holland T5.110 | 110 hp | — | — | Compare → |
| New Holland T6020 Delta | 110 hp | 9,090 lb | — | Compare → |
| New Holland TS6110 | 110 hp | — | 2012+ | Compare → |
| New Holland TB110 Low-Profile | 108 hp | 6,124.5 lb | — | Compare → |
| New Holland TS110A | 112 hp | 10,560 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO LT90A | 110 hp | 8,820 lb | — | Compare → |
| Agrinar T-110 | 110 hp | — | — | Compare → |
| Allis Chalmers HD11 | 110 hp | 21,000 lb | 1955–1965 | Compare → |
| Apollo 1104 | 110 hp | 10,710 lb | — | Compare → |
| AGCO LT85A | 110.1 hp | 10,605 lb | — | Compare → |
Explore
New Holland siblings
Explore
Similar-spec models
Gallery
New Holland TB110 photos
FAQ
Common questions
What is the engine power output of the New Holland TB110?
Rated engine output for the New Holland TB110 is 110 hp, delivered by a 4-cylinder engine. The engine displaces 304 ci.
What is the operating weight of the New Holland TB110?
In working trim, the New Holland TB110 comes in at roughly 6,125 lb.
Which transmission does the New Holland TB110 use?
The New Holland TB110 is equipped with a Gear transmission.
What hydraulics does the New Holland TB110 have?
The New Holland TB110 uses an Open Center hydraulic system.
What three-point hitch category does the New Holland TB110 use?
The New Holland TB110 has a Category Category 3 three-point hitch.
How do I maintain a New Holland TB110?
Routine service for the New Holland TB110 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
