UtilityPerformance profile
Rhino 3124
The Rhino 3124 is a utility tractor built for farmers who need a reliable machine for various tasks. This 4-wheel drive tractor has power steering, making it easy to handle in tight spaces. It comes with a gear transmission that offers 8 forward gears and 2 reverse gears, giving you plenty of options for different jobs. Under the hood, the Rhino 3124 has a 2-cylinder diesel engine that's liquid-cooled. The engine puts out 32 horsepower, which is below average for tractors in its class. It has a displacement of 105.43 cubic inches and runs at 2200 RPM. The tractor is compact, measuring 109 inches long, 67 inches wide, and 89 inches tall with the roll-over protection system (ROPS). It weighs 3500 pounds, which is about average for its size. The Rhino 3124 uses agricultural tires and has a Category I hitch, making it suitable for a range of farm implements.
ManufacturerRhinoPower32 hpEngine2-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 32hp
- Operating Weight
- 3,500 lb
- Transmission
- Gear
At a glance
How the 3124 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
32 hp · 24th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 3124 ranks at the 24th percentile for engine power among recorded utility tractors.
Overview
About the Rhino 3124
The Rhino 3124 is a utility tractor built for farmers who need a reliable machine for various tasks. This 4-wheel drive tractor has power steering, making it easy to handle in tight spaces. It comes with a gear transmission that offers 8 forward gears and 2 reverse gears, giving you plenty of options for different jobs. Under the hood, the Rhino 3124 has a 2-cylinder diesel engine that's liquid-cooled. The engine puts out 32 horsepower, which is below average for tractors in its class. It has a displacement of 105.43 cubic inches and runs at 2200 RPM. The tractor is compact, measuring 109 inches long, 67 inches wide, and 89 inches tall with the roll-over protection system (ROPS). It weighs 3500 pounds, which is about average for its size. The Rhino 3124 uses agricultural tires and has a Category I hitch, making it suitable for a range of farm implements.
Full specifications
Every recorded spec
General
| Manufacturer | Rhino |
|---|---|
| Model | 3124 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 3,500lb |
Engine
| Power | 32hp |
|---|---|
| Cylinders | 2 |
| Displacement | 105.43ci |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 8 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power Steering |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 109in |
|---|---|
| Width | 67in |
| Height | 89in |
| Operating weight | 3,500lb |
Head to head
3124 vs. Utility median
How the Rhino 3124 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 32 hp | 55 hp | -42% | 24th |
| Engine Displacement | 105 ci | 183 ci | -42% | 25th |
| Cylinders | 2 | 4 | -50% | 3rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 3,500 lb | 5,303 lb | -34% | 29th |
| Length | 109 in | 137 in | -20% | 15th |
| Width | 67 in | 66 in | +2% | 53rd |
| Height | 89 in | 94.1 in | -5% | 39th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Rhino tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Rhino 3024 | 32 hp | 3,140 lb | — | Compare → |
| Rhino 3120 | 32 hp | 3,140 lb | — | Compare → |
| Rhino 3320 Classic | 32 hp | 3,140 lb | — | Compare → |
| Rhino 3324 Classic | 32 hp | 3,500 lb | — | Compare → |
| Rhino 284 | 28 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST32 | 33 hp | 2,642 lb | — | Compare → |
| AGCO ST33A | 33 hp | 2,400 lb | — | Compare → |
| AGCO ST34A | 33 hp | 3,000 lb | — | Compare → |
| AGCO ST35 | 33 hp | 3,168 lb | — | Compare → |
| Allis Chalmers 5030 | 31 hp | 2,530 lb | 1979–1985 | Compare → |
Explore
Rhino siblings
Explore
Similar-spec models
Gallery
Rhino 3124 photos
FAQ
Common questions
What is the engine power output of the Rhino 3124?
Rated engine output for the Rhino 3124 is 32 hp, delivered by a 2-cylinder engine. The engine displaces 105.43 ci.
Which transmission does the Rhino 3124 use?
The Rhino 3124 is equipped with a Gear transmission with 8 forward gears.
What type of hydraulic system does the Rhino 3124 use?
Hydraulics on the Rhino 3124 are Open center.
What hitch category is the Rhino 3124?
The Rhino 3124 uses a Category I hitch.
What is the operating weight of the Rhino 3124?
In working trim, the Rhino 3124 comes in at roughly 3,500 lb.
How do I maintain a Rhino 3124?
Routine service for the Rhino 3124 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
