AgriculturalPerformance profile
SAME Diamond 270
The SAME Diamond 270 is a powerful tractor built for serious farm work. It has a strong Deutz engine with 6 cylinders and 266 horsepower. This engine is turbocharged and intercooled, which means it can work hard without getting too hot. The tractor has a special transmission with 40 forward gears and 40 reverse gears, giving the driver lots of options for different tasks. This tractor is big and sturdy. It's about 197 inches long, 108 inches wide, and 128 inches tall. It weighs nearly 20,000 pounds, which helps it handle tough jobs. The Diamond 270 has a comfortable cab for the driver and uses radial tires for better traction. It also has a good hydraulic system for lifting heavy equipment. With its strong engine and many features, this SAME tractor is great for large farms that need a reliable machine for big jobs.
ManufacturerSAMEPower266 hpEngine6-cylTransFour-speed power shift
Quick specs
- Category
- Agricultural
- Engine Power Output
- 266hp
- Operating Weight
- 19,951 lb
- Transmission
- Four-speed power shift
At a glance
How the Diamond 270 compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
266 hp · 90th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The Diamond 270 ranks at the 90th percentile for engine power among recorded agricultural tractors.
Overview
About the SAME Diamond 270
The SAME Diamond 270 is a powerful tractor built for serious farm work. It has a strong Deutz engine with 6 cylinders and 266 horsepower. This engine is turbocharged and intercooled, which means it can work hard without getting too hot. The tractor has a special transmission with 40 forward gears and 40 reverse gears, giving the driver lots of options for different tasks. This tractor is big and sturdy. It's about 197 inches long, 108 inches wide, and 128 inches tall. It weighs nearly 20,000 pounds, which helps it handle tough jobs. The Diamond 270 has a comfortable cab for the driver and uses radial tires for better traction. It also has a good hydraulic system for lifting heavy equipment. With its strong engine and many features, this SAME tractor is great for large farms that need a reliable machine for big jobs.
Full specifications
Every recorded spec
General
| Manufacturer | SAME |
|---|---|
| Model | Diamond 270 |
| Category | Agricultural tractor |
| Operating weight | 19,951lb |
Engine
| Make | Deutz |
|---|---|
| Model | TCD2013 |
| Power | 266hp |
| Cylinders | 6 |
| Displacement | 436.1ci |
| Bore | 4.25in |
| Stroke | 5.12in |
Transmission
| Type | Four-speed power shift |
|---|---|
| Forward gears | 40 |
| Reverse gears | 40 |
Chassis & drive
| Cab | Cab |
|---|
Hydraulics
| Type | Load sensing |
|---|
Dimensions
| Length | 196.9in |
|---|---|
| Width | 108.3in |
| Height | 128.2in |
| Operating weight | 19,951lb |
Head to head
Diamond 270 vs. Agricultural median
How the SAME Diamond 270 compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 266 hp | 110 hp | +142% | 90th |
| Engine Displacement | 436 ci | 336 ci | +30% | 77th |
| Cylinders | 6 | 5.5 | +9% | 74th |
| Forward Gears | 40 | 16 | +150% | 96th |
| Operating Weight | 19,951 lb | 10,914 lb | +83% | 84th |
| Length | 197 in | 173 in | +14% | 76th |
| Width | 108 in | 79.5 in | +36% | 91st |
| Height | 128 in | 111 in | +16% | 88th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared SAME tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| SAME Diamond 260 | 260 hp | 18,632 lb | — | Compare → |
| SAME Diamond 265 | 277 hp | 19,952 lb | — | Compare → |
| SAME Diamond | 239 hp | 18,541 lb | — | Compare → |
| SAME Diamond 230 | 230 hp | 18,411 lb | — | Compare → |
| SAME Diamond 215 | 211 hp | 18,541 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO DT225B | 266.3 hp | 25,795 lb | 2009–2010 | Compare → |
| CaseIH 4694 | 261 hp | 22,310 lb | — | Compare → |
| AGCO DT220A | 260 hp | 19,951 lb | 2005–2008 | Compare → |
| CaseIH 9150 | 280 hp | 23,000 lb | — | Compare → |
| Big Bud HN250 | 250 hp | 34,000 lb | — | Compare → |
Explore
SAME siblings
Explore
Similar-spec models
Gallery
SAME Diamond 270 photos
FAQ
Common questions
What is the engine power output of the SAME Diamond 270?
Rated engine output for the SAME Diamond 270 is 266 hp, delivered by a 6-cylinder engine. The engine displaces 436.1 ci.
What hitch category is the SAME Diamond 270?
The SAME Diamond 270 uses a Category Category 3 hitch.
What is the operating weight of the SAME Diamond 270?
In working trim, the SAME Diamond 270 comes in at roughly 19,951 lb.
Which transmission does the SAME Diamond 270 use?
The SAME Diamond 270 is equipped with a Four-speed power shift transmission with 40 forward gears.
What type of hydraulic system does the SAME Diamond 270 use?
Hydraulics on the SAME Diamond 270 are Load sensing.
How do I maintain a SAME Diamond 270?
Routine service for the SAME Diamond 270 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
