Utility tractorsSpec sheet
SAME Explorer 70C
The SAME Explorer 70C is a versatile tractor designed for various farming tasks. It features a shuttle transmission with 8 forward and 8 reverse gears, giving farmers good control over their speed. The tractor is powered by a SAME 1000.4A engine, which is air-cooled and runs on diesel fuel. This 4-cylinder engine has a displacement of 244 ci and produces 70 hp at 2350 rpm, providing solid power for most farm jobs. The Explorer 70C is built to be compact yet capable. It measures 132.3 inches long, 55.5 inches wide, and 51.1 inches tall, making it easy to maneuver in tight spaces. With an operating weight of 7716 lb, it's sturdy enough for heavy-duty work. The tractor comes with a Category II hitch, which is suitable for attaching a wide range of farm implements. It also has an electric starter for easy operation and a wheelbase of 62 inches for good stability. Overall, the SAME Explorer 70C is a reliable choice for farmers looking for a mid-sized tractor with a good balance of power and maneuverability.
Key specifications
- Category
- Utility
- Engine power
- 70hp
- Operating weight
- 7,716 lb
- Transmission
- Shuttle
Category comparison
Explorer 70C compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
70 hp · 63rd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Explorer 70C ranks at the 63rd percentile for engine power among recorded utility tractors.
Overview
About the SAME Explorer 70C
The SAME Explorer 70C is a versatile tractor designed for various farming tasks. It features a shuttle transmission with 8 forward and 8 reverse gears, giving farmers good control over their speed. The tractor is powered by a SAME 1000.4A engine, which is air-cooled and runs on diesel fuel. This 4-cylinder engine has a displacement of 244 ci and produces 70 hp at 2350 rpm, providing solid power for most farm jobs. The Explorer 70C is built to be compact yet capable. It measures 132.3 inches long, 55.5 inches wide, and 51.1 inches tall, making it easy to maneuver in tight spaces. With an operating weight of 7716 lb, it's sturdy enough for heavy-duty work. The tractor comes with a Category II hitch, which is suitable for attaching a wide range of farm implements. It also has an electric starter for easy operation and a wheelbase of 62 inches for good stability. Overall, the SAME Explorer 70C is a reliable choice for farmers looking for a mid-sized tractor with a good balance of power and maneuverability.
Full specifications
Recorded specifications
General
| Manufacturer | SAME |
|---|---|
| Model | Explorer 70C |
| Category | Utility tractor |
| Operating weight | 7,716lb(3,500 kg) |
Engine
| Make | SAME |
|---|---|
| Model | 1000.4A |
| Power | 70hp(52.2 kW) |
| Cylinders | 4 |
| Displacement | 244ci(4 L) |
| Bore | 4.13in(104.9 mm) |
| Stroke | 4.54in(115.3 mm) |
Transmission
| Type | Shuttle |
|---|---|
| Forward gears | 8 |
| Reverse gears | 8 |
Dimensions
| Length | 132.3in(3,360 mm) |
|---|---|
| Width | 55.5in(1,410 mm) |
| Height | 51.1in(1,298 mm) |
| Operating weight | 7,716lb(3,500 kg) |
Closest alternatives
Explorer 70C compared with the nearest models by horsepower
The closest utility models to the SAME Explorer 70C by rated horsepower are the SAME Argon Classic 70 and the SAME Dorado 76. The SAME Argon Classic 70 matches it on rated power and weighs 3,150 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The SAME Dorado 76 matches it on rated power and weighs 1,760 lb less, carrying 85 lb per horsepower against 110 lb. Of the 3 models, the Explorer 70C has the highest weight per horsepower at 110 lb per hp.
| Spec | SAME Explorer 70C | SAME Argon Classic 70 | SAME Dorado 76 |
|---|---|---|---|
| Engine power | 70 hp52.2 kW | 70 hp52.2 kW | 70 hp52.2 kW |
| Operating weight | 7,716 lb3,500 kg | 4,564 lb2,070 kg | 5,953 lb2,700 kg |
| Weight per hp | 110 lb/hp67 kg/kW | 65 lb/hp40 kg/kW | 85 lb/hp52 kg/kW |
| Displacement | 244 ci4 L | 183 ci3 L | 244 ci4 L |
| Cylinders | 4 | 3 | 4 |
| Transmission | Shuttle | Manual | - |
| Drive | - | 2WD | 2WD |
Calculators
Calculators for the Explorer 70C
PTO power
About 58 to 63 PTO hp
Estimated from the 70 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 70 hp tractor can run
Maximum size is about a 8.5 ft rotary cutter or a 7 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
128 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
70 hp is 52.2 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
Explorer 70C vs. Utility median
SAME Explorer 70C compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 70 hp | 55 hp | +27% | 63rd |
| Engine Displacement | 244 ci | 183 ci | +33% | 68th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 7,716 lb | 5,303 lb | +46% | 73rd |
| Length | 132 in | 137 in | -3% | 44th |
| Width | 55.5 in | 66 in | -16% | 28th |
| Height | 51.1 in | 94.1 in | -46% | 3rd |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other SAME models
Other manufacturers
Models with similar horsepower
Gallery
SAME Explorer 70C photos
FAQ
Frequently asked questions
How powerful is the SAME Explorer 70C?
The SAME Explorer 70C has an engine power output of 70 hp. It is powered by a 4-cylinder engine displacing 244 ci.
What hitch category is the SAME Explorer 70C?
The SAME Explorer 70C uses a Category Category II hitch.
What is the working weight of the SAME Explorer 70C?
The operating weight of the SAME Explorer 70C is approximately 7,716 lb.
What type of transmission does the SAME Explorer 70C have?
The SAME Explorer 70C uses a Shuttle transmission offering 8 forward gears.
What routine service does the SAME Explorer 70C need?
Regular maintenance for the SAME Explorer 70C includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
