Shibaura SD5040T
Complete specifications and technical data for the Shibaura SD5040T. Compare with similar tractors from Shibaura and other manufacturers.
Quick Specs
Category
Engine Power Output
Operating Weight
Transmission
Strength vs Median
The Shibaura SD5040T is a versatile utility tractor designed for various farming tasks. It features a powerful 4-cylinder, turbocharged diesel engine that produces 50 hp at 2400 rpm. The engine's disp...
Photo Gallery
Specifications
Engine Power Output Comparison of Shibaura SD5040T vs. Other Utility Tractors
Loading Chart...
Operating Weight Comparison of Shibaura SD5040T vs. Other Utility Tractors
Loading Chart...
Compare to Other Tractors
How the Shibaura SD5040T compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 50 hp | 50.3 hp | at median | 49th |
| Engine Displacement | 130 ci | 175 ci | -26% | 35th |
| Cylinders | 4 | 4 | at median | 65th |
| Forward Gears | 24 | 12 | +100% | 91st |
| Operating Weight | 3,705 lb | 4,850 lb | -24% | 36th |
| Length | 133 in | 134 in | at median | 48th |
| Width | 59.8 in | 65 in | -8% | 38th |
| Height | 59.5 in | 92.9 in | -36% | 10th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,570–4,952 models).
Compare to other tractors with similar specs
Compare to other tractors from Shibaura
Compare to tractors with similar horsepower from other brands
Frequently Asked Questions
What is the engine power output of the Shibaura SD5040T?
The Shibaura SD5040T has an engine power output of 50 hp.
How many cylinders does the Shibaura SD5040T have?
The Shibaura SD5040T is equipped with a 4-cylinder engine.
What is the operating weight of the Shibaura SD5040T?
The operating weight of the Shibaura SD5040T is approximately 3,705 lb.
What type of transmission does the Shibaura SD5040T have?
The Shibaura SD5040T is equipped with a Gear transmission.
What type of hydraulic system does the Shibaura SD5040T use?
The Shibaura SD5040T uses a Open Center hydraulic system.
What hitch category is the Shibaura SD5040T?
The Shibaura SD5040T is a Category II/I hitch.
What maintenance does the Shibaura SD5040T require?
Regular maintenance for the Shibaura SD5040T includes checking and changing engine oil, hydraulic fluid, filters, and performing routine inspections as recommended in the owner's manual. Always refer to the manufacturer's maintenance schedule for specific intervals and procedures.
