Shibaura SD5040T
The Shibaura SD5040T is a versatile utility tractor designed for various farming tasks. It features a powerful 4-cylinder, turbocharged diesel engine that produces 50 hp at 2400 rpm. The engine's displacement is 130.2 ci, which is below average for its class. This tractor offers a robust 4-wheel drive system with power steering, making it easy to handle in tough conditions. One of the standout features of the SD5040T is its transmission. It boasts 24 forward gears and 8 reverse gears, giving operators plenty of options for different jobs. The tractor's compact size, measuring 132.7 inches long, 59.8 inches wide, and 59.5 inches high, allows it to work well in tight spaces. With an operating weight of 3,705 lb, which is on the lighter side for utility tractors, it's less likely to compact soil. The SD5040T comes equipped with a three-point hitch (Category II/I) at the rear and an open center hydraulic system, making it compatible with a wide range of implements.
ManufacturerShibauraPower50 hpEngine4-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 50hp
- Operating Weight
- 3,705 lb
- Transmission
- Gear
At a glance
How the SD5040T compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
50 hp · 45th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The SD5040T ranks at the 45th percentile for engine power among recorded utility tractors.
Overview
About the Shibaura SD5040T
The Shibaura SD5040T is a versatile utility tractor designed for various farming tasks. It features a powerful 4-cylinder, turbocharged diesel engine that produces 50 hp at 2400 rpm. The engine's displacement is 130.2 ci, which is below average for its class. This tractor offers a robust 4-wheel drive system with power steering, making it easy to handle in tough conditions. One of the standout features of the SD5040T is its transmission. It boasts 24 forward gears and 8 reverse gears, giving operators plenty of options for different jobs. The tractor's compact size, measuring 132.7 inches long, 59.8 inches wide, and 59.5 inches high, allows it to work well in tight spaces. With an operating weight of 3,705 lb, which is on the lighter side for utility tractors, it's less likely to compact soil. The SD5040T comes equipped with a three-point hitch (Category II/I) at the rear and an open center hydraulic system, making it compatible with a wide range of implements.
Full specifications
Every recorded spec
General
| Manufacturer | Shibaura |
|---|---|
| Model | SD5040T |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 3,705lb |
Engine
| Make | Shibaura |
|---|---|
| Model | LEP854A |
| Power | 50hp |
| Cylinders | 4 |
| Displacement | 130.2ci |
| Bore | 3.35in |
| Stroke | 3.7in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 24 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 132.7in |
|---|---|
| Width | 59.8in |
| Height | 59.5in |
| Operating weight | 3,705lb |
Head to head
SD5040T vs. Utility median
How the Shibaura SD5040T compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 50 hp | 55 hp | -9% | 45th |
| Engine Displacement | 130 ci | 183 ci | -29% | 31st |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 24 | 12 | +100% | 92nd |
| Operating Weight | 3,705 lb | 5,303 lb | -30% | 32nd |
| Length | 133 in | 137 in | -3% | 44th |
| Width | 59.8 in | 66 in | -9% | 36th |
| Height | 59.5 in | 94.1 in | -37% | 9th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Shibaura tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Shibaura V450F | 50 hp | 4,630 lb | — | Compare → |
| Shibaura SP5040 | 49.3 hp | 4,211 lb | — | Compare → |
| Shibaura SE5346 | 53 hp | 5,566 lb | — | Compare → |
| Shibaura SD4643 | 46 hp | 4,151 lb | — | Compare → |
| Shibaura S445 | 45 hp | 3,516 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5050 | 50 hp | 4,410 lb | 1977–1983 | Compare → |
| Allis Chalmers FD5 | 50 hp | 5,412 lb | — | Compare → |
| Belarus 4055 | 50 hp | 4,750 lb | — | Compare → |
| AGCO GT45 | 52 hp | 4,806 lb | — | Compare → |
| Agco GT45A | 52 hp | 5,820.3 lb | — | Compare → |
Explore
Shibaura siblings
Explore
Similar-spec models
Gallery
Shibaura SD5040T photos
FAQ
Common questions
What is the engine power output of the Shibaura SD5040T?
Rated engine output for the Shibaura SD5040T is 50 hp, delivered by a 4-cylinder engine. The engine displaces 130.2 ci.
What is the operating weight of the Shibaura SD5040T?
In working trim, the Shibaura SD5040T comes in at roughly 3,705 lb.
Which transmission does the Shibaura SD5040T use?
The Shibaura SD5040T is equipped with a Gear transmission with 24 forward gears.
What hydraulics does the Shibaura SD5040T have?
The Shibaura SD5040T uses an Open Center hydraulic system.
What three-point hitch category does the Shibaura SD5040T use?
The Shibaura SD5040T has a Category II/I three-point hitch.
How do I maintain a Shibaura SD5040T?
Routine service for the Shibaura SD5040T covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
