AgriculturalPerformance profile
Ursus 1234
The Ursus 1234 is a powerful 4WD tractor designed for tough farm work. It features a 4x4 MFWD chassis and power steering, making it easy to handle in various conditions. The tractor has a two-speed power shift transmission with 16 forward and 8 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the Ursus 1234 boasts a Zetor Z 8701.12 engine. This 6-cylinder diesel engine is liquid-cooled and uses direct injection. It has a displacement of 416.4 ci and produces 117.5 hp at 2200 rpm. The tractor's large ag tires (14.9-24 front and 18.4-34 rear) provide excellent traction in the field. With a Category III hitch capable of lifting 12,125.5 lb, this tractor can handle heavy implements with ease. The Ursus 1234 also comes with a comfortable cab for the operator and an electric starter for quick and easy engine starts.
ManufacturerUrsusPower117.5 hpEngine6-cylTransTwo-speed power shift
Quick specs
- Category
- Agricultural
- Engine Power Output
- 118hp
- Operating Weight
- 11,244 lb
- Transmission
- Two-speed power shift
At a glance
How the 1234 compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
117.5 hp · 55th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The 1234 ranks at the 55th percentile for engine power among recorded agricultural tractors.
Overview
About the Ursus 1234
The Ursus 1234 is a powerful 4WD tractor designed for tough farm work. It features a 4x4 MFWD chassis and power steering, making it easy to handle in various conditions. The tractor has a two-speed power shift transmission with 16 forward and 8 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the Ursus 1234 boasts a Zetor Z 8701.12 engine. This 6-cylinder diesel engine is liquid-cooled and uses direct injection. It has a displacement of 416.4 ci and produces 117.5 hp at 2200 rpm. The tractor's large ag tires (14.9-24 front and 18.4-34 rear) provide excellent traction in the field. With a Category III hitch capable of lifting 12,125.5 lb, this tractor can handle heavy implements with ease. The Ursus 1234 also comes with a comfortable cab for the operator and an electric starter for quick and easy engine starts.
Full specifications
Every recorded spec
General
| Manufacturer | Ursus |
|---|---|
| Model | 1234 |
| Category | Agricultural tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 11,244lb |
Engine
| Make | Zetor |
|---|---|
| Model | Z 8701.12 |
| Power | 117.5hp |
| Cylinders | 6 |
| Displacement | 416.4ci |
| Bore | 4.33in |
| Stroke | 4.72in |
Transmission
| Type | Two-speed power shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Cab |
Dimensions
| Length | 177in |
|---|---|
| Width | 89.3in |
| Height | 118in |
| Operating weight | 11,244lb |
Tires
| Front | 14.9-24 |
|---|---|
| Rear | 18.4-34 |
Capacities
| Cooling system | 6.88gal |
|---|
Head to head
1234 vs. Agricultural median
How the Ursus 1234 compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 118 hp | 110 hp | +7% | 55th |
| Engine Displacement | 416 ci | 336 ci | +24% | 72nd |
| Cylinders | 6 | 5.5 | +9% | 74th |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 11,244 lb | 10,914 lb | +3% | 51st |
| Length | 177 in | 173 in | +2% | 54th |
| Width | 89.3 in | 79.5 in | +12% | 65th |
| Height | 118 in | 111 in | +7% | 70th |
| 3-Point Hitch Capacity | 12,126 lb | 12,126 lb | at median | 50th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 93–1,130 models).
Compare to tractors with similar specs
Commonly compared Ursus tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Ursus 1232 | 117.5 hp | 10,075 lb | — | Compare → |
| Ursus 8024 Mido | 108.6 hp | 9,039 lb | — | Compare → |
| Ursus C-3110 | 100.5 hp | 8,379 lb | — | Compare → |
| Ursus 1434 | 136 hp | — | — | Compare → |
| Ursus 1132 | 94.5 hp | 9,612 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 7000 | 117 hp | 9,550 lb | 1975–1979 | Compare → |
| AGCO RT110A | 116.9 hp | 12,200 lb | — | Compare → |
| Allis Chalmers 8010 | 119 hp | 12,630 lb | 1982–1985 | Compare → |
| Agrinar T-120 | 119.3 hp | 4,580 lb | — | Compare → |
| Belarus 1025 MIG | 115 hp | 9,469 lb | — | Compare → |
Explore
Ursus siblings
Explore
Similar-spec models
Gallery
Ursus 1234 photos
FAQ
Common questions
How much horsepower does the Ursus 1234 have?
The Ursus 1234 produces 117.5 hp from its 6-cylinder engine. Engine displacement is 416.4 ci.
What hitch category is the Ursus 1234?
The Ursus 1234 uses a Category Category 3 hitch with a lift capacity of 12,125.5 lb.
How much does the Ursus 1234 weigh?
The Ursus 1234 weighs about 11,244 lb in operating condition.
What transmission is in the Ursus 1234?
Transmission on the Ursus 1234 is Two-speed power shift, with 16 forward speeds.
What size tires does the Ursus 1234 use?
Factory rubber for the Ursus 1234 is 14.9-24 front tires and 18.4-34 rear tires.
What maintenance does the Ursus 1234 require?
Like any tractor, the Ursus 1234 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
