UtilityPerformance profile
Volvo T36
The Volvo T36 is a sturdy tractor built for farm work. It has a Bolinder 1053 engine with 3 cylinders and runs on diesel fuel. This engine is liquid-cooled and can produce 41.9 hp at 1800 rpm. The tractor has a 5-speed gear transmission for moving forward and 1 gear for going backward. This tractor is quite big, measuring 124 inches long, 66.9 inches wide, and 85.8 inches tall. It weighs 5424 pounds, which helps it handle tough jobs. The T36 has large tires, with 19-inch front tires and 38-inch rear tires. It also has a Category 3 hitch, making it easy to attach different tools. The electric starter helps you get the tractor running quickly and easily.
ManufacturerVolvoPower41.9 hpEngine3-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 42hp
- Operating Weight
- 5,424 lb
- Transmission
- Gear
At a glance
How the T36 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
41.9 hp · 36th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The T36 ranks at the 36th percentile for engine power among recorded utility tractors.
Overview
About the Volvo T36
The Volvo T36 is a sturdy tractor built for farm work. It has a Bolinder 1053 engine with 3 cylinders and runs on diesel fuel. This engine is liquid-cooled and can produce 41.9 hp at 1800 rpm. The tractor has a 5-speed gear transmission for moving forward and 1 gear for going backward. This tractor is quite big, measuring 124 inches long, 66.9 inches wide, and 85.8 inches tall. It weighs 5424 pounds, which helps it handle tough jobs. The T36 has large tires, with 19-inch front tires and 38-inch rear tires. It also has a Category 3 hitch, making it easy to attach different tools. The electric starter helps you get the tractor running quickly and easily.
Full specifications
Every recorded spec
General
| Manufacturer | Volvo |
|---|---|
| Model | T36 |
| Category | Utility tractor |
| Operating weight | 5,424lb |
Engine
| Make | Bolinder |
|---|---|
| Model | 1053 |
| Power | 41.9hp |
| Cylinders | 3 |
| Displacement | 205ci |
| Bore | 4.13in |
| Stroke | 5.12in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 5 |
| Reverse gears | 1 |
Dimensions
| Length | 124in |
|---|---|
| Width | 66.9in |
| Height | 85.8in |
| Operating weight | 5,424lb |
Head to head
T36 vs. Utility median
How the Volvo T36 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 41.9 hp | 55 hp | -24% | 36th |
| Engine Displacement | 205 ci | 183 ci | +12% | 56th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 5 | 12 | -58% | 6th |
| Operating Weight | 5,424 lb | 5,303 lb | +2% | 51st |
| Length | 124 in | 137 in | -9% | 33rd |
| Width | 66.9 in | 66 in | +1% | 52nd |
| Height | 85.8 in | 94.1 in | -9% | 34th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Volvo tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Volvo T35 | 41.9 hp | 5,424 lb | — | Compare → |
| Volvo T430 | 42.5 hp | 5,291 lb | — | Compare → |
| Volvo T32 | 45 hp | 5,060 lb | — | Compare → |
| Volvo T320 Buster | 37 hp | 3,175 lb | — | Compare → |
| Volvo T400 | 47 hp | 4,167 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers ED40 | 41 hp | 3,527 lb | — | Compare → |
| AGCO ST40 | 40.1 hp | 3,323 lb | — | Compare → |
| AGCO ST41A | 40.1 hp | 3,000 lb | — | Compare → |
| Advance-Rumely OilPull K 12/20 | 40 hp | 6,430 lb | — | Compare → |
| Allis Chalmers 160 | 40 hp | 4,674 lb | 1970–1975 | Compare → |
Explore
Volvo siblings
Explore
Similar-spec models
Gallery
Volvo T36 photos
FAQ
Common questions
What is the engine power output of the Volvo T36?
Rated engine output for the Volvo T36 is 41.9 hp, delivered by a 3-cylinder engine. The engine displaces 205 ci.
Which transmission does the Volvo T36 use?
The Volvo T36 is equipped with a Gear transmission with 5 forward gears.
What three-point hitch category does the Volvo T36 use?
The Volvo T36 has a Category Category 3 three-point hitch.
What is the operating weight of the Volvo T36?
In working trim, the Volvo T36 comes in at roughly 5,424 lb.
How do I maintain a Volvo T36?
Routine service for the Volvo T36 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
