UtilityPerformance profile
Yanmar AF-160
The Yanmar AF-160 is a compact utility tractor made from 1997 to 2000. It's small but strong, perfect for farms and big gardens. This tractor has four-wheel drive, which helps it work well on different types of ground. The AF-160 has a Yanmar 3TNE72 engine with three cylinders. It's diesel-powered and cooled by liquid. The engine is small compared to many other tractors, but it still gives 15.8 horsepower. It has a shuttle transmission with 8 forward and 8 reverse gears, making it easy to change direction while working. The tractor is light, weighing 1,587 pounds, which is less than most tractors. It's 103.2 inches long, 43.3 inches wide, and 73.6 inches tall, so it can fit in tight spaces. The AF-160 has farm tires on both front and back, and it starts with an electric starter.
ManufacturerYanmarPower15.8 hpEngine3-cylTransShuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 16hp
- Operating Weight
- 1,587 lb
- Transmission
- Shuttle
At a glance
How the AF-160 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
15.8 hp · 3rd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The AF-160 ranks at the 3rd percentile for engine power among recorded utility tractors.
Overview
About the Yanmar AF-160
The Yanmar AF-160 is a compact utility tractor made from 1997 to 2000. It's small but strong, perfect for farms and big gardens. This tractor has four-wheel drive, which helps it work well on different types of ground. The AF-160 has a Yanmar 3TNE72 engine with three cylinders. It's diesel-powered and cooled by liquid. The engine is small compared to many other tractors, but it still gives 15.8 horsepower. It has a shuttle transmission with 8 forward and 8 reverse gears, making it easy to change direction while working. The tractor is light, weighing 1,587 pounds, which is less than most tractors. It's 103.2 inches long, 43.3 inches wide, and 73.6 inches tall, so it can fit in tight spaces. The AF-160 has farm tires on both front and back, and it starts with an electric starter.
Full specifications
Every recorded spec
General
| Manufacturer | Yanmar |
|---|---|
| Model | AF-160 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Years built | 1997–2000 |
| Operating weight | 1,587lb |
Engine
| Make | Yanmar |
|---|---|
| Model | 3TNE72 |
| Power | 15.8hp |
| Cylinders | 3 |
| Displacement | 59.1ci |
| Bore | 2.83in |
| Stroke | 3.07in |
Transmission
| Type | Shuttle |
|---|---|
| Forward gears | 8 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | MFWD 4WD |
Dimensions
| Length | 103.2in |
|---|---|
| Width | 43.3in |
| Height | 73.6in |
| Operating weight | 1,587lb |
Head to head
AF-160 vs. Utility median
How the Yanmar AF-160 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 15.8 hp | 55 hp | -71% | 3rd |
| Engine Displacement | 59.1 ci | 183 ci | -68% | 5th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 1,587 lb | 5,303 lb | -70% | 7th |
| Length | 103 in | 137 in | -24% | 11th |
| Width | 43.3 in | 66 in | -34% | 7th |
| Height | 73.6 in | 94.1 in | -22% | 19th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Yanmar tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Yanmar AF-16 | 15.8 hp | 1,609 lb | 1992–1996 | Compare → |
| Yanmar FX16 | 16 hp | — | — | Compare → |
| Yanmar Ke-160 | 16 hp | 1,279 lb | — | Compare → |
| Yanmar YM1601 | 16 hp | 1,477 lb | — | Compare → |
| Yanmar YM1602 | 16 hp | 1,521 lb | 1982–1983 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Agria Hispania 7100 | 16 hp | — | — | Compare → |
| Bolens QS-16 | 16 hp | 849 lb | 1974–1977 | Compare → |
| Allis Chalmers 616 | 16.5 hp | 1,499 lb | 1972–1973 | Compare → |
| Bolens G152 | 15 hp | 1,034 lb | — | Compare → |
| Bolens G154 | 15 hp | 1,124 lb | — | Compare → |
Explore
Yanmar siblings
Explore
Similar-spec models
Gallery
Yanmar AF-160 photos
FAQ
Common questions
What years was the Yanmar AF-160 manufactured?
Production of the Yanmar AF-160 ran from 1997 through 2000.
What type of transmission does the Yanmar AF-160 have?
The Yanmar AF-160 uses a Shuttle transmission offering 8 forward gears.
How powerful is the Yanmar AF-160?
The Yanmar AF-160 has an engine power output of 15.8 hp. It is powered by a 3-cylinder engine displacing 59.1 ci.
What is the working weight of the Yanmar AF-160?
The operating weight of the Yanmar AF-160 is approximately 1,587 lb.
What routine service does the Yanmar AF-160 need?
Regular maintenance for the Yanmar AF-160 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
