Ag King AK4540

Last Updated: June 2024

Overview

The Ag King AK4540 is a diesel-powered utility tractor designed for various farm operations. Equipped with a Jinma 310 engine, it offers a power output of 45 horsepower and a 185.2 cubic-inch displacement. The liquid-cooled engine maintains optimal temperatures during prolonged work and operates at a rated 2400 RPM. The tractor features a 4x4 MFWD 4WD chassis, which provides it with enhanced traction on different terrains. The manual transmission system consists of 16 forward gears and 8 reverse gears, allowing a range of speed options for different tasks. The tractor's wheelbase is 76.5 inches, giving it a stable footprint on the ground. With dimensions of 135 inches in length, 63 inches in width, and 105 inches in height, and an operating weight of 4650 lbs, this tractor is built to handle substantial workloads. The AK4540's overall design focuses on simplicity and functionality, essential for daily farm activities.
Show more...

Key Specifications

Category: Utility

Power Output: 45

Transmission: Manual

Drive Type: 4WD

Operating Weight: 4650

Fuel Type: Diesel

Ag King AK4540 vs. Similar Tractors

Power Output
Average
Greater than 43% of similar tractors.
Operating Weight
Average
Greater than 41% of similar tractors.

Technical Specifications

Engine

Manufacturer
Jinma
Model
310
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
3
Displacement (ci)
185.2
Bore (in)
-
Stroke (in)
-
Rated RPM
2400
Power Output (hp)
45

Transmission

Type
Manual
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
135
Width (in)
63
Height (in)
105
Operating Weight (lb)
4650

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
13.2
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 1
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
