Ascot Universal A1800A

The Ascot Universal A1800A is a powerful 4-wheel drive tractor built for tough farm work. It has a strong 6-cylinder diesel engine made by Universal. This engine, called the D-131, can produce 180 horsepower at 2100 RPM, making it great for heavy-duty tasks. The A1800A has a constant mesh transmission with 12 forward gears and 2 reverse gears. This gives the driver lots of options for different jobs. The tractor is quite heavy, weighing 21,400 pounds. This weight helps it grip the ground well when pulling big loads. With its 4x4 chassis and 4WD drive type, this tractor can handle rough terrain and tough field conditions easily.

ManufacturerAscot UniversalPower180 hp(134.2 kW)Class150–300 HP tractors →Engine6-cylinderTransmissionConstant Mesh
Ascot Universal A1800A

Key specifications

Category
Agricultural
Engine power
180hp
Operating weight
21,400 lb
Transmission
Constant Mesh
Compare this model

Category comparison

A1800A compared with its category

vs. Agricultural median

Distribution

Engine Power (hp)

All recorded Agricultural tractors

180 hp · 77th

This model

13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028

The A1800A ranks at the 77th percentile for engine power among recorded agricultural tractors.

Overview

About the Ascot Universal A1800A

The Ascot Universal A1800A is a powerful 4-wheel drive tractor built for tough farm work. It has a strong 6-cylinder diesel engine made by Universal. This engine, called the D-131, can produce 180 horsepower at 2100 RPM, making it great for heavy-duty tasks. The A1800A has a constant mesh transmission with 12 forward gears and 2 reverse gears. This gives the driver lots of options for different jobs. The tractor is quite heavy, weighing 21,400 pounds. This weight helps it grip the ground well when pulling big loads. With its 4x4 chassis and 4WD drive type, this tractor can handle rough terrain and tough field conditions easily.

Full specifications

Recorded specifications

General

ManufacturerAscot Universal
ModelA1800A
CategoryAgricultural tractor
Type4x4
Operating weight21,400lb(9,707 kg)

Engine

MakeUniversal
ModelD-131
Power180hp(134.2 kW)
Cylinders6

Transmission

TypeConstant Mesh
Forward gears12
Reverse gears2

Chassis & drive

Chassis4x4
Drive4WD

Dimensions

Operating weight21,400lb(9,707 kg)

Closest alternatives

A1800A compared with the nearest models by horsepower

The closest agricultural models to the Ascot Universal A1800A by rated horsepower are the Hurlimann H-1800 SX and the Massey Ferguson 1500. The Hurlimann H-1800 SX matches it on rated power and weighs 5,750 lb less, carrying 87 lb per horsepower against 119 lb. The Massey Ferguson 1500 matches it on rated power and weighs 4,200 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. Of the 3 models, the A1800A has the highest weight per horsepower at 119 lb per hp.

Ascot Universal A1800A compared with Hurlimann H-1800 SX and Massey Ferguson 1500
SpecAscot Universal A1800AHurlimann H-1800 SXMassey Ferguson 1500
Engine power180 hp134.2 kW180 hp134.2 kW180 hp134.2 kW
Operating weight21,400 lb9,707 kg15,655 lb7,101 kg17,200 lb7,802 kg
Weight per hp119 lb/hp72 kg/kW87 lb/hp53 kg/kW96 lb/hp58 kg/kW
Displacement-366.1 ci6 L573 ci9.39 L
Cylinders668
TransmissionConstant Mesh-Gear
Drive4WD2WD-

Calculators

Calculators for the A1800A

Parts and manuals

Parts and manuals for the Ascot Universal A1800A

Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.

Filters

Manuals

Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure

Category medians

A1800A vs. Agricultural median

Ascot Universal A1800A compared with other Agricultural tractors

SpecThis modelAgricultural medianDifferencePercentile
Engine Power180 hp110 hp+64%77th
Cylinders65.5+9%74th
Forward Gears1216-25%33rd
Operating Weight21,400 lb10,914 lb+96%87th

Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 971–1,130 models).

Same manufacturer

Other Ascot Universal models

All Ascot Universal models →

Other manufacturers

Models with similar horsepower

FAQ

Frequently asked questions

How much horsepower does the Ascot Universal A1800A have?

The Ascot Universal A1800A produces 180 hp from its 6-cylinder engine.

How much does the Ascot Universal A1800A weigh?

The Ascot Universal A1800A weighs about 21,400 lb in operating condition.

What transmission is in the Ascot Universal A1800A?

Transmission on the Ascot Universal A1800A is Constant Mesh, with 12 forward speeds.

What maintenance does the Ascot Universal A1800A require?

The Ascot Universal A1800A needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
