UtilityPerformance profile
Branson 4820R
The Branson 4820R is a compact yet powerful tractor designed for various farming tasks. It features a 48 hp diesel engine made by Kukje, which is liquid-cooled for better performance. The engine has 4 cylinders and a displacement of 139.5 ci, providing a good balance of power and efficiency. With a synchronized shuttle transmission, this tractor offers smooth gear changes and easy operation. Measuring 127.4 inches long, 64.9 inches wide, and 98.4 inches tall, the 4820R is well-suited for working in tight spaces. It weighs 3,831 lb, making it sturdy enough for tough jobs while still being manageable. The tractor comes with agricultural tires on both front and rear, ensuring good traction in various field conditions. For safety, it's equipped with a Roll Over Protection Structure (ROPS). Additional features include an air cleaner and available emission information, showing Branson's commitment to clean operation and air quality.
ManufacturerBransonPower48 hpEngine4-cylTransSynchronized Shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 48hp
- Operating Weight
- 3,831 lb
- Transmission
- Synchronized Shuttle
At a glance
How the 4820R compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
48 hp · 43rd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 4820R ranks at the 43rd percentile for engine power among recorded utility tractors.
Overview
About the Branson 4820R
The Branson 4820R is a compact yet powerful tractor designed for various farming tasks. It features a 48 hp diesel engine made by Kukje, which is liquid-cooled for better performance. The engine has 4 cylinders and a displacement of 139.5 ci, providing a good balance of power and efficiency. With a synchronized shuttle transmission, this tractor offers smooth gear changes and easy operation. Measuring 127.4 inches long, 64.9 inches wide, and 98.4 inches tall, the 4820R is well-suited for working in tight spaces. It weighs 3,831 lb, making it sturdy enough for tough jobs while still being manageable. The tractor comes with agricultural tires on both front and rear, ensuring good traction in various field conditions. For safety, it's equipped with a Roll Over Protection Structure (ROPS). Additional features include an air cleaner and available emission information, showing Branson's commitment to clean operation and air quality.
Full specifications
Every recorded spec
General
| Manufacturer | Branson |
|---|---|
| Model | 4820R |
| Category | Utility tractor |
| Operating weight | 3,831lb |
Engine
| Make | Kukje |
|---|---|
| Power | 48hp |
| Cylinders | 4 |
| Displacement | 139.5ci |
| Bore | 3.47in |
| Stroke | 3.7in |
Transmission
| Type | Synchronized Shuttle |
|---|
Chassis & drive
| Cab | ROPS (Roll Over Protection Structure) |
|---|
Dimensions
| Length | 127.4in |
|---|---|
| Width | 64.9in |
| Height | 98.4in |
| Operating weight | 3,831lb |
Head to head
4820R vs. Utility median
How the Branson 4820R compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 48 hp | 55 hp | -13% | 43rd |
| Engine Displacement | 140 ci | 183 ci | -24% | 35th |
| Cylinders | 4 | 4 | at median | 50th |
| Operating Weight | 3,831 lb | 5,303 lb | -28% | 34th |
| Length | 127 in | 137 in | -7% | 38th |
| Width | 64.9 in | 66 in | -2% | 48th |
| Height | 98.4 in | 94.1 in | +5% | 62nd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Branson tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Branson 4815CH | 48 hp | 3,664 lb | — | Compare → |
| Branson 4820C | 48 hp | 4,349 lb | — | Compare → |
| Branson 4820H | 48 hp | 3,831 lb | — | Compare → |
| Branson 4520C | 47 hp | 4,118 lb | — | Compare → |
| Branson 4815H | 47 hp | 3,278 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro Tigrone 5800 | 48 hp | 3,417 lb | — | Compare → |
| Antonio Carraro Tigrone Jona 5800 | 48 hp | — | — | Compare → |
| AGCO ST47A | 47.5 hp | 3,600 lb | — | Compare → |
| AGCO ST60A | 46.4 hp | 4,078 lb | — | Compare → |
| Allis Chalmers 5050 | 50 hp | 4,410 lb | 1977–1983 | Compare → |
Explore
Branson siblings
Explore
Similar-spec models
Gallery
Branson 4820R photos
FAQ
Common questions
What is the engine power output of the Branson 4820R?
Rated engine output for the Branson 4820R is 48 hp, delivered by a 4-cylinder engine. The engine displaces 139.5 ci.
What is the operating weight of the Branson 4820R?
In working trim, the Branson 4820R comes in at roughly 3,831 lb.
Which transmission does the Branson 4820R use?
The Branson 4820R is equipped with a Synchronized Shuttle transmission.
How do I maintain a Branson 4820R?
Routine service for the Branson 4820R covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
