UtilityPerformance profile

Cabelas LM25

The Cabela's LM25 is a small but mighty utility tractor perfect for various tasks around the farm or property. This sub-compact tractor features a 4-wheel drive system and power steering, making it easy to maneuver in tight spaces. It's powered by a Yanmar 3TNV80F diesel engine with three cylinders and liquid cooling, providing 24 horsepower at 3000 RPM. At just over 100 inches long and 45.8 inches wide, the LM25 is compact enough to fit in most storage areas. It has a hydrostatic transmission for smooth operation and an open center hydraulic system. The tractor rides on 20-inch front tires and larger 27-inch rear tires, giving it good stability and traction. With an operating weight of 1610 lbs, it's sturdy enough for many jobs but won't heavily compact your soil. While its engine displacement is below average for tractors, its high rated RPM allows it to perform efficiently for its size.

ManufacturerCabelasPower24 hpEngine3-cylTransHydrostatic
Jump to specs ↓Compare →
Cabelas LM25
Jump to Full Specifications List

Quick specs

Category
Utility
Engine Power Output
24hp
Transmission
Hydrostatic
Compare this model

At a glance

How the LM25 compares

vs. Utility median

Distribution

Engine Power (hp)

Across all Utility tractors

24 hp · 14th

This model

9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383

The LM25 ranks at the 14th percentile for engine power among recorded utility tractors.

Overview

About the Cabelas LM25

The Cabela's LM25 is a small but mighty utility tractor perfect for various tasks around the farm or property. This sub-compact tractor features a 4-wheel drive system and power steering, making it easy to maneuver in tight spaces. It's powered by a Yanmar 3TNV80F diesel engine with three cylinders and liquid cooling, providing 24 horsepower at 3000 RPM. At just over 100 inches long and 45.8 inches wide, the LM25 is compact enough to fit in most storage areas. It has a hydrostatic transmission for smooth operation and an open center hydraulic system. The tractor rides on 20-inch front tires and larger 27-inch rear tires, giving it good stability and traction. With an operating weight of 1610 lbs, it's sturdy enough for many jobs but won't heavily compact your soil. While its engine displacement is below average for tractors, its high rated RPM allows it to perform efficiently for its size.

Full specifications

Every recorded spec

General

ManufacturerCabelas
ModelLM25
CategoryUtility tractor
Type4x4 MFWD 4WD

Engine

MakeYanmar
Model3TNV80F
Power24hp
Cylinders3
Displacement77.2ci
Bore3.15in
Stroke3.31in

Transmission

TypeHydrostatic

Chassis & drive

Chassis4x4 MFWD 4WD
Drive4WD
SteeringPower steering

Hydraulics

TypeOpen Center

Dimensions

Length100.9in
Width45.8in
Height92in

Capacities

Cooling system1.05gal

Head to head

LM25 vs. Utility median

How the Cabelas LM25 compares to other Utility tractors

SpecThis modelUtility medianDifferencePercentile
Engine Power24 hp55 hp-56%14th
Engine Displacement77.2 ci183 ci-58%11th
Cylinders34-25%23rd
Length101 in137 in-26%9th
Width45.8 in66 in-31%11th
Height92 in94.1 in-2%45th

Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).

Explore

Cabelas siblings

All Cabelas models →

Explore

Similar-spec models

FAQ

Common questions

What is the engine power output of the Cabelas LM25?

Rated engine output for the Cabelas LM25 is 24 hp, delivered by a 3-cylinder engine. The engine displaces 77.2 ci.

Which transmission does the Cabelas LM25 use?

The Cabelas LM25 is equipped with a Hydrostatic transmission.

What hydraulics does the Cabelas LM25 have?

The Cabelas LM25 uses an Open Center hydraulic system.

How do I maintain a Cabelas LM25?

Routine service for the Cabelas LM25 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
