UtilityPerformance profile
Cabelas LM45
The Cabela's LM45 is a utility tractor built for tough jobs on the farm. It has a strong 4-wheel drive system and power steering, making it easy to handle in various conditions. The tractor offers two transmission options: a 16-speed synchronized shuttle or a smooth hydrostatic drive. This gives farmers flexibility in how they operate the machine. Under the hood, the LM45 has a Yanmar diesel engine with four cylinders. The engine is liquid-cooled and uses modern fuel injection for better performance. It produces 46 horsepower, which is about average for tractors in its class. The tractor weighs 3,770 pounds and has agricultural tires for good traction in fields. It also comes with a Category I rear hitch for attaching various implements. The open operator station with ROPS (Roll-Over Protective Structure) keeps the driver safe while working.
ManufacturerCabelasPower46 hpEngine4-cylTransSynchronized Shuttle / Hydrostatic
Quick specs
- Category
- Utility
- Engine Power Output
- 46hp
- Operating Weight
- 3,770 lb
- Transmission
- Synchronized Shuttle / Hydrostatic
At a glance
How the LM45 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
46 hp · 40th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The LM45 ranks at the 40th percentile for engine power among recorded utility tractors.
Overview
About the Cabelas LM45
The Cabela's LM45 is a utility tractor built for tough jobs on the farm. It has a strong 4-wheel drive system and power steering, making it easy to handle in various conditions. The tractor offers two transmission options: a 16-speed synchronized shuttle or a smooth hydrostatic drive. This gives farmers flexibility in how they operate the machine. Under the hood, the LM45 has a Yanmar diesel engine with four cylinders. The engine is liquid-cooled and uses modern fuel injection for better performance. It produces 46 horsepower, which is about average for tractors in its class. The tractor weighs 3,770 pounds and has agricultural tires for good traction in fields. It also comes with a Category I rear hitch for attaching various implements. The open operator station with ROPS (Roll-Over Protective Structure) keeps the driver safe while working.
Full specifications
Every recorded spec
General
| Manufacturer | Cabelas |
|---|---|
| Model | LM45 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 3,770lb |
Engine
| Make | Yanmar |
|---|---|
| Model | 4TNV88T-CR |
| Power | 46hp |
| Cylinders | 4 |
| Displacement | 133.6ci |
| Bore | 3.46in |
| Stroke | 3.54in |
Transmission
| Type | Synchronized Shuttle / Hydrostatic |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Open (ROPS) |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 141.3in |
|---|---|
| Width | 63.8in |
| Height | 102.1in |
| Operating weight | 3,770lb |
Capacities
| Cooling system | 2.25gal |
|---|
Head to head
LM45 vs. Utility median
How the Cabelas LM45 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 46 hp | 55 hp | -16% | 40th |
| Engine Displacement | 134 ci | 183 ci | -27% | 31st |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 3,770 lb | 5,303 lb | -29% | 33rd |
| Length | 141 in | 137 in | +3% | 57th |
| Width | 63.8 in | 66 in | -3% | 44th |
| Height | 102 in | 94.1 in | +9% | 71st |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Cabelas tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Cabelas LM43 | 42.7 hp | 3,640 lb | — | Compare → |
| Cabelas LM50 | 50.7 hp | 3,640 lb | — | Compare → |
| Cabelas LM55 | 55.1 hp | 4,415 lb | — | Compare → |
| Cabelas LM35 | 35 hp | 3,140 lb | — | Compare → |
| Cabelas LM36 | 34.2 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST60A | 46.4 hp | 4,078 lb | — | Compare → |
| Ag King AK4540 | 45 hp | 4,650 lb | — | Compare → |
| Apollo 454 | 45 hp | 4,365 lb | — | Compare → |
| Ascot Universal 445 | 45 hp | 4,500 lb | — | Compare → |
| Barreiros 5000 VR | 45 hp | 4,080 lb | — | Compare → |
Explore
Cabelas siblings
Explore
Similar-spec models
Gallery
Cabelas LM45 photos
FAQ
Common questions
How much horsepower does the Cabelas LM45 have?
The Cabelas LM45 produces 46 hp from its 4-cylinder engine. Engine displacement is 133.6 ci.
What hydraulics does the Cabelas LM45 have?
The Cabelas LM45 uses an Open Center hydraulic system.
What three-point hitch category does the Cabelas LM45 use?
The Cabelas LM45 has a Category I three-point hitch.
How much does the Cabelas LM45 weigh?
The Cabelas LM45 weighs about 3,770 lb in operating condition.
What transmission is in the Cabelas LM45?
Transmission on the Cabelas LM45 is Synchronized Shuttle / Hydrostatic, with 16 forward speeds.
What maintenance does the Cabelas LM45 require?
Like any tractor, the Cabelas LM45 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
