AgriculturalPerformance profile
CaseIH 856 XL
The CaseIH 856 XL is a powerful 2WD tractor built for farm work. It has a strong engine made by International Harvester. This engine is turbocharged and has 4 cylinders. It can produce 85 horsepower, which is good for many farm tasks. The tractor runs on diesel fuel and has a liquid cooling system to keep it from getting too hot. This tractor has a special transmission called IH-Total-synchron. It has 16 forward gears and 8 reverse gears, giving the driver lots of options for different jobs. The CaseIH 856 XL is big and strong, weighing 8,465 pounds. It's about 12 feet long and almost 9 feet tall. The tractor has standard farm tires on both the front and back. It also has a Type II hitch on the back for attaching tools. The electric starter makes it easy to turn on and get to work.
ManufacturerCaseIHPower85 hpEngine4-cylTransIH-Total-synchron
Quick specs
- Category
- Agricultural
- Engine Power Output
- 85hp
- Operating Weight
- 8,465 lb
- Transmission
- IH-Total-synchron
At a glance
How the 856 XL compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
85 hp · 32nd
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The 856 XL ranks at the 32nd percentile for engine power among recorded agricultural tractors.
Overview
About the CaseIH 856 XL
The CaseIH 856 XL is a powerful 2WD tractor built for farm work. It has a strong engine made by International Harvester. This engine is turbocharged and has 4 cylinders. It can produce 85 horsepower, which is good for many farm tasks. The tractor runs on diesel fuel and has a liquid cooling system to keep it from getting too hot. This tractor has a special transmission called IH-Total-synchron. It has 16 forward gears and 8 reverse gears, giving the driver lots of options for different jobs. The CaseIH 856 XL is big and strong, weighing 8,465 pounds. It's about 12 feet long and almost 9 feet tall. The tractor has standard farm tires on both the front and back. It also has a Type II hitch on the back for attaching tools. The electric starter makes it easy to turn on and get to work.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | 856 XL |
| Category | Agricultural tractor |
| Type | 2WD |
| Operating weight | 8,465lb |
Engine
| Make | International Harvester |
|---|---|
| Model | DT-239 |
| Power | 85hp |
| Cylinders | 4 |
| Displacement | 239ci |
| Bore | 3.87in |
| Stroke | 5.06in |
Transmission
| Type | IH-Total-synchron |
|---|---|
| Forward gears | 16 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 2WD |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 144.9in |
|---|---|
| Height | 104.9in |
| Operating weight | 8,465lb |
Capacities
| Cooling system | 5.55gal |
|---|
Head to head
856 XL vs. Agricultural median
How the CaseIH 856 XL compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 85 hp | 110 hp | -23% | 32nd |
| Engine Displacement | 239 ci | 336 ci | -29% | 24th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 8,465 lb | 10,914 lb | -22% | 34th |
| Length | 145 in | 173 in | -16% | 22nd |
| Height | 105 in | 111 in | -5% | 36th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 795–1,130 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH JX1095N | 91 hp | 5,820 lb | — | Compare → |
| CaseIH Farmall 75N | 76 hp | 5,027 lb | — | Compare → |
| CaseIH 956 XL | 95 hp | 9,458 lb | — | Compare → |
| CaseIH Farmall 95N | 95 hp | 5,820 lb | — | Compare → |
| CaseIH JX1075N | 75 hp | 5,027 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Agco LT90 | 85 hp | 8,980 lb | — | Compare → |
| Apollo 854 | 85 hp | 10,360 lb | — | Compare → |
| AGCO LT85 | 85.4 hp | 8,450 lb | — | Compare → |
| AGCO GT75 | 83 hp | 5,511 lb | 2004–2007 | Compare → |
| Agco GT75A | 83 hp | 6,040.7 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH 856 XL photos
FAQ
Common questions
How powerful is the CaseIH 856 XL?
The CaseIH 856 XL has an engine power output of 85 hp. It is powered by a 4-cylinder engine displacing 239 ci.
What is the working weight of the CaseIH 856 XL?
The operating weight of the CaseIH 856 XL is approximately 8,465 lb.
What type of transmission does the CaseIH 856 XL have?
The CaseIH 856 XL uses an IH-Total-synchron transmission offering 16 forward gears.
What routine service does the CaseIH 856 XL need?
Regular maintenance for the CaseIH 856 XL includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
