AgriculturalPerformance profile
CaseIH Farmall 95N
The CaseIH Farmall 95N is a powerful orchard and vineyard tractor designed for agricultural use. It features a 4-wheel drive system and hydrostatic power steering, making it easy to maneuver in tight spaces. The tractor is equipped with a mechanical shuttle transmission that offers 16 forward and 16 reverse gears, giving operators plenty of options for different tasks. Under the hood, the Farmall 95N boasts a robust FPT engine with four cylinders and turbocharging. The engine displaces 274 cubic inches, which is very high compared to other tractors in its class. It produces 95 horsepower at 2300 RPM, providing above-average power for its size. The tractor's operating weight of 5820 pounds is also above average, giving it good stability and traction. With its compact size of 158 inches long, 53.4 inches wide, and 91.6 inches tall, this tractor is well-suited for working in orchards and vineyards where space may be limited.
ManufacturerCaseIHPower95 hpEngine4-cylTransMechanical shuttle
Quick specs
- Category
- Agricultural
- Engine Power Output
- 95hp
- Operating Weight
- 5,820 lb
- Transmission
- Mechanical shuttle
At a glance
How the Farmall 95N compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
95 hp · 40th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The Farmall 95N ranks at the 40th percentile for engine power among recorded agricultural tractors.
Overview
About the CaseIH Farmall 95N
The CaseIH Farmall 95N is a powerful orchard and vineyard tractor designed for agricultural use. It features a 4-wheel drive system and hydrostatic power steering, making it easy to maneuver in tight spaces. The tractor is equipped with a mechanical shuttle transmission that offers 16 forward and 16 reverse gears, giving operators plenty of options for different tasks. Under the hood, the Farmall 95N boasts a robust FPT engine with four cylinders and turbocharging. The engine displaces 274 cubic inches, which is very high compared to other tractors in its class. It produces 95 horsepower at 2300 RPM, providing above-average power for its size. The tractor's operating weight of 5820 pounds is also above average, giving it good stability and traction. With its compact size of 158 inches long, 53.4 inches wide, and 91.6 inches tall, this tractor is well-suited for working in orchards and vineyards where space may be limited.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | Farmall 95N |
| Category | Agricultural tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 5,820lb |
Engine
| Make | FPT |
|---|---|
| Power | 95hp |
| Cylinders | 4 |
| Displacement | 274ci |
| Bore | 4.1in |
| Stroke | 5.2in |
Transmission
| Type | Mechanical shuttle |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 158in |
|---|---|
| Width | 53.4in |
| Height | 91.6in |
| Operating weight | 5,820lb |
Head to head
Farmall 95N vs. Agricultural median
How the CaseIH Farmall 95N compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 95 hp | 110 hp | -14% | 40th |
| Engine Displacement | 274 ci | 336 ci | -18% | 41st |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 5,820 lb | 10,914 lb | -47% | 19th |
| Length | 158 in | 173 in | -9% | 36th |
| Width | 53.4 in | 79.5 in | -33% | 18th |
| Height | 91.6 in | 111 in | -17% | 22nd |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH 956 XL | 95 hp | 9,458 lb | — | Compare → |
| CaseIH Farmall 100N | 98 hp | — | — | Compare → |
| CaseIH JX1095N | 91 hp | 5,820 lb | — | Compare → |
| CaseIH 5240 Maxxum | 100 hp | 9,787 lb | 1992–1997 | Compare → |
| CaseIH MX100 Maxxum | 100 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro SRX 10400 | 95 hp | 4,718 lb | — | Compare → |
| Antonio Carraro TGF 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRG 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRX 10400 | 95 hp | 4,828 lb | — | Compare → |
| Antonio Carraro TTR 10400 | 95 hp | 4,806 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH Farmall 95N photos
FAQ
Common questions
How powerful is the CaseIH Farmall 95N?
The CaseIH Farmall 95N has an engine power output of 95 hp. It is powered by a 4-cylinder engine displacing 274 ci.
What hydraulics does the CaseIH Farmall 95N have?
The CaseIH Farmall 95N uses an Open center hydraulic system.
What three-point hitch category does the CaseIH Farmall 95N use?
The CaseIH Farmall 95N has a Category II three-point hitch.
What is the working weight of the CaseIH Farmall 95N?
The operating weight of the CaseIH Farmall 95N is approximately 5,820 lb.
What type of transmission does the CaseIH Farmall 95N have?
The CaseIH Farmall 95N uses a Mechanical shuttle transmission offering 16 forward gears.
What routine service does the CaseIH Farmall 95N need?
Regular maintenance for the CaseIH Farmall 95N includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
