Sub-CompactPerformance profile
CaseIH D25
The CaseIH D25 is a compact 2WD tractor designed for small-scale farming and light fieldwork. It features a 4x2 chassis and a 9-speed gear transmission, giving farmers 9 forward and 3 reverse gears to choose from. This versatility allows for smooth operation in various tasks around the farm. Under the hood, the D25 is powered by a Shibaura 3-cylinder diesel engine. This liquid-cooled engine has a displacement of 81.2 ci and produces 25 hp at 2600 rpm. The tractor is equipped with an electric starter and glow plugs for easy starting in cold weather. It also has a dual element air cleaner to protect the engine from dust and debris. The D25 comes with agricultural tires, with 5.5-inch front tread width and 11.2-inch rear tread width. For added functionality, it features a Category I rear hitch, making it compatible with a range of implements.
ManufacturerCaseIHPower25 hpEngine3-cylTrans9-speed gear
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 25hp
- Transmission
- 9-speed gear
At a glance
How the D25 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
25 hp · 46th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The D25 ranks at the 46th percentile for engine power among recorded sub-compact tractors.
Overview
About the CaseIH D25
The CaseIH D25 is a compact 2WD tractor designed for small-scale farming and light fieldwork. It features a 4x2 chassis and a 9-speed gear transmission, giving farmers 9 forward and 3 reverse gears to choose from. This versatility allows for smooth operation in various tasks around the farm. Under the hood, the D25 is powered by a Shibaura 3-cylinder diesel engine. This liquid-cooled engine has a displacement of 81.2 ci and produces 25 hp at 2600 rpm. The tractor is equipped with an electric starter and glow plugs for easy starting in cold weather. It also has a dual element air cleaner to protect the engine from dust and debris. The D25 comes with agricultural tires, with 5.5-inch front tread width and 11.2-inch rear tread width. For added functionality, it features a Category I rear hitch, making it compatible with a range of implements.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | D25 |
| Category | Sub-Compact tractor |
| Type | 4x2 2WD |
Engine
| Make | Shibaura |
|---|---|
| Power | 25hp |
| Cylinders | 3 |
| Displacement | 81.2ci |
Transmission
| Type | 9-speed gear |
|---|---|
| Forward gears | 9 |
| Reverse gears | 3 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Head to head
D25 vs. Sub-Compact median
How the CaseIH D25 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 25 hp | 26.9 hp | -7% | 46th |
| Engine Displacement | 81.2 ci | 91.4 ci | -11% | 42nd |
| Cylinders | 3 | 3 | at median | 50th |
| Forward Gears | 9 | 9 | at median | 50th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 616–816 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH DX25 | 25 hp | — | — | Compare → |
| CaseIH DX25E | 25 hp | 1,318 lb | 2005–2007 | Compare → |
| CaseIH Farmall DX25E | 25 hp | 1,323 lb | — | Compare → |
| CaseIH Farmall 25SC | 24.7 hp | 1,444 lb | — | Compare → |
| CaseIH 1140 | 27 hp | 2,060 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5020 | 25 hp | 2,060 lb | 1977–1985 | Compare → |
| Allis Chalmers FD3 | 25 hp | 3,150 lb | — | Compare → |
| Apollo 254 | 25 hp | — | — | Compare → |
| Belarus 254 | 25 hp | — | — | Compare → |
| Bobcat CT1025 | 24.5 hp | 1,488 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH D25 photos
FAQ
Common questions
What is the engine power output of the CaseIH D25?
Rated engine output for the CaseIH D25 is 25 hp, delivered by a 3-cylinder engine. The engine displaces 81.2 ci.
What hitch category is the CaseIH D25?
The CaseIH D25 uses a Category I hitch.
Which transmission does the CaseIH D25 use?
The CaseIH D25 is equipped with a 9-speed gear transmission with 9 forward gears.
How do I maintain a CaseIH D25?
Routine service for the CaseIH D25 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
