Sub-CompactPerformance profile
CaseIH D29
The CaseIH D29 is a compact tractor designed for small farms and light-duty work. It features a 2-wheel drive (2WD) system and a gear transmission with 9 forward and 3 reverse speeds. This setup gives the driver good control over the tractor's movement in various conditions. Under the hood, the D29 is powered by a Shibaura diesel engine. This 3-cylinder, liquid-cooled engine has a displacement of 81.2 cubic inches and produces 29 horsepower at 2800 RPM. The tractor comes with a Category I rear hitch, making it compatible with many common farm implements. It also has an electric starter system that runs on 12 volts, ensuring easy starts even in cold weather. Additional features include a dual-element air cleaner for better engine protection and a glow plug pre-heating system to help with cold starts. The D29 offers versatility with tire options for agriculture, lawn/turf, and industrial use.
ManufacturerCaseIHPower29 hpEngine3-cylTransGear
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 29hp
- Transmission
- Gear
At a glance
How the D29 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
29 hp · 55th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The D29 ranks at the 55th percentile for engine power among recorded sub-compact tractors.
Overview
About the CaseIH D29
The CaseIH D29 is a compact tractor designed for small farms and light-duty work. It features a 2-wheel drive (2WD) system and a gear transmission with 9 forward and 3 reverse speeds. This setup gives the driver good control over the tractor's movement in various conditions. Under the hood, the D29 is powered by a Shibaura diesel engine. This 3-cylinder, liquid-cooled engine has a displacement of 81.2 cubic inches and produces 29 horsepower at 2800 RPM. The tractor comes with a Category I rear hitch, making it compatible with many common farm implements. It also has an electric starter system that runs on 12 volts, ensuring easy starts even in cold weather. Additional features include a dual-element air cleaner for better engine protection and a glow plug pre-heating system to help with cold starts. The D29 offers versatility with tire options for agriculture, lawn/turf, and industrial use.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | D29 |
| Category | Sub-Compact tractor |
| Type | 4x2 2WD |
Engine
| Make | Shibaura |
|---|---|
| Power | 29hp |
| Cylinders | 3 |
| Displacement | 81.2ci |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 9 |
| Reverse gears | 3 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Head to head
D29 vs. Sub-Compact median
How the CaseIH D29 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 29 hp | 26.9 hp | +8% | 55th |
| Engine Displacement | 81.2 ci | 91.4 ci | -11% | 42nd |
| Cylinders | 3 | 3 | at median | 50th |
| Forward Gears | 9 | 9 | at median | 50th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 616–816 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH 1140 | 27 hp | 2,060 lb | — | Compare → |
| CaseIH Farmall 31 | 31 hp | 2,511 lb | — | Compare → |
| CaseIH D25 | 25 hp | — | — | Compare → |
| CaseIH DX25 | 25 hp | — | — | Compare → |
| CaseIH DX25E | 25 hp | 1,318 lb | 2005–2007 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D10 | 28.57 hp | 2,700 lb | 1959–1967 | Compare → |
| AGCO ST28A | 28.4 hp | 2,400 lb | — | Compare → |
| AGCO ST30x | 28.4 hp | 1,984 lb | — | Compare → |
| AGCO ST30 | 30.3 hp | 2,594 lb | — | Compare → |
| Allis Chalmers D272 | 27.5 hp | 2,060 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH D29 photos
FAQ
Common questions
How much horsepower does the CaseIH D29 have?
The CaseIH D29 produces 29 hp from its 3-cylinder engine. Engine displacement is 81.2 ci.
What hitch category is the CaseIH D29?
The CaseIH D29 uses a Category I hitch.
What transmission is in the CaseIH D29?
Transmission on the CaseIH D29 is Gear, with 9 forward speeds.
What maintenance does the CaseIH D29 require?
Like any tractor, the CaseIH D29 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
