UtilityPerformance profile
CaseIH D35
The CaseIH D35 is a utility tractor built for everyday farm tasks. It has a 2WD drive system and power steering, making it easy to handle. The tractor uses a synchronized shuttle transmission with 12 forward and 12 reverse gears, giving the driver lots of options for different jobs. Under the hood, the D35 has a Shibaura diesel engine with 3 cylinders. The engine is liquid-cooled and naturally aspirated, producing 35 hp at 2600 rpm. While the engine power is below average for tractors, it's enough for many farm chores. The tractor has a 12-volt electrical system and uses an electric starter with glow plugs for cold starts. It's equipped with agricultural tires and a three-point hitch at the rear, perfect for attaching various implements. The open operator station with ROPS keeps the driver safe while working in the fields.
ManufacturerCaseIHPower35 hpEngine3-cylTransSynchronized shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 35hp
- Operating Weight
- 2,947 lb
- Transmission
- Synchronized shuttle
At a glance
How the D35 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
35 hp · 28th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The D35 ranks at the 28th percentile for engine power among recorded utility tractors.
Overview
About the CaseIH D35
The CaseIH D35 is a utility tractor built for everyday farm tasks. It has a 2WD drive system and power steering, making it easy to handle. The tractor uses a synchronized shuttle transmission with 12 forward and 12 reverse gears, giving the driver lots of options for different jobs. Under the hood, the D35 has a Shibaura diesel engine with 3 cylinders. The engine is liquid-cooled and naturally aspirated, producing 35 hp at 2600 rpm. While the engine power is below average for tractors, it's enough for many farm chores. The tractor has a 12-volt electrical system and uses an electric starter with glow plugs for cold starts. It's equipped with agricultural tires and a three-point hitch at the rear, perfect for attaching various implements. The open operator station with ROPS keeps the driver safe while working in the fields.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | D35 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 2,947lb |
Engine
| Make | Shibaura |
|---|---|
| Power | 35hp |
| Cylinders | 3 |
| Displacement | 101.4ci |
| Bore | 3.31in |
| Stroke | 3.94in |
Transmission
| Type | Synchronized shuttle |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | Open (ROPS) |
Dimensions
| Length | 116.3in |
|---|---|
| Width | 61.3in |
| Height | 94in |
| Operating weight | 2,947lb |
Head to head
D35 vs. Utility median
How the CaseIH D35 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 35 hp | 55 hp | -36% | 28th |
| Engine Displacement | 101 ci | 183 ci | -45% | 24th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 2,947 lb | 5,303 lb | -44% | 22nd |
| Length | 116 in | 137 in | -15% | 22nd |
| Width | 61.3 in | 66 in | -7% | 40th |
| Height | 94 in | 94.1 in | 0% | 50th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH DX35 | 35 hp | 3,252 lb | — | Compare → |
| CaseIH Farmall 35 | 35 hp | 2,526 lb | — | Compare → |
| CaseIH Farmall 35A Series II | 35 hp | 3,067 lb | — | Compare → |
| CaseIH Farmall DX34 | 35 hp | 2,526 lb | — | Compare → |
| CaseIH Farmall 35C | 36.2 hp | 3,218 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Ag King AK3540 | 35 hp | 3,895 lb | — | Compare → |
| Apollo 354 | 35 hp | — | — | Compare → |
| Barreiros R-335 S | 35 hp | — | — | Compare → |
| Allis Chalmers WD | 34.63 hp | — | 1948–1953 | Compare → |
| Allis Chalmers U | 34.12 hp | 5,030 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH D35 photos
FAQ
Common questions
How much horsepower does the CaseIH D35 have?
The CaseIH D35 produces 35 hp from its 3-cylinder engine. Engine displacement is 101.4 ci.
How much does the CaseIH D35 weigh?
The CaseIH D35 weighs about 2,947 lb in operating condition.
What transmission is in the CaseIH D35?
Transmission on the CaseIH D35 is Synchronized shuttle, with 12 forward speeds.
What three-point hitch category does the CaseIH D35 use?
The CaseIH D35 has a Category I three-point hitch.
What maintenance does the CaseIH D35 require?
Like any tractor, the CaseIH D35 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
