Same brandCaseIH Quadtrac 9380QT
The CaseIH Quadtrac 9380QT is a powerful tractor built for big jobs on the farm. It has a strong Cummins N14 engine with 6 cylinders and 400 horsepower. This engine is turbocharged and runs on diesel fuel, giving it lots of power for tough work. This tractor is big and heavy, weighing 44,000 pounds. It's 120 inches wide and 140.4 inches tall. The Quadtrac 9380QT has a full power shift transmission with 12 forward gears and 3 reverse gears, making it easy to change speeds. It also has a rear hitch and a closed center hydraulic system, which helps it work with many different tools. The tractor has a comfortable cab for the driver and starts with an electric starter.

Key specifications
- Category
- Articulated
- Engine power
- 400hp
- Operating weight
- 44,000 lb
- Transmission
- Full power shift
Category comparison
Quadtrac 9380QT compared with its category
vs. Articulated medianDistribution
Engine Power (hp)
All recorded Articulated tractors
This model
The Quadtrac 9380QT ranks at the 33rd percentile for engine power among recorded articulated tractors.
Overview
About the CaseIH Quadtrac 9380QT
The CaseIH Quadtrac 9380QT is a powerful tractor built for big jobs on the farm. It has a strong Cummins N14 engine with 6 cylinders and 400 horsepower. This engine is turbocharged and runs on diesel fuel, giving it lots of power for tough work. This tractor is big and heavy, weighing 44,000 pounds. It's 120 inches wide and 140.4 inches tall. The Quadtrac 9380QT has a full power shift transmission with 12 forward gears and 3 reverse gears, making it easy to change speeds. It also has a rear hitch and a closed center hydraulic system, which helps it work with many different tools. The tractor has a comfortable cab for the driver and starts with an electric starter.
Full specifications
Recorded specifications
General
| Manufacturer | CaseIH |
|---|---|
| Model | Quadtrac 9380QT |
| Category | Articulated tractor |
| Operating weight | 44,000lb(19,960 kg) |
Engine
| Make | Cummins |
|---|---|
| Model | N14 |
| Power | 400hp(298.3 kW) |
| Cylinders | 6 |
| Displacement | 855ci(14.01 L) |
| Bore | 5.5in(139.7 mm) |
| Stroke | 6in(152.4 mm) |
Transmission
| Type | Full power shift |
|---|---|
| Forward gears | 12 |
| Reverse gears | 3 |
Chassis & drive
| Cab | Cab |
|---|
Hydraulics
| Type | Closed center |
|---|
Dimensions
| Width | 120in(3,048 mm) |
|---|---|
| Height | 140.4in(3,566 mm) |
| Operating weight | 44,000lb(19,960 kg) |
Closest alternatives
Quadtrac 9380QT compared with the nearest models by horsepower
Among articulated tractors, the Challenger MT765E and the John Deere 9RX 540 are closest to the CaseIH Quadtrac 9380QT in rated horsepower. The Challenger MT765E makes 5 hp more and weighs 10,770 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The John Deere 9RX 540 is rated 9.3 hp higher and weighs 12,320 lb more, at 138 lb per horsepower against 110 lb.
| Spec | CaseIH Quadtrac 9380QT | Challenger MT765E | John Deere 9RX 540 |
|---|---|---|---|
| Engine power | 400 hp298.3 kW | 405 hp302 kW | 409.3 hp305.2 kW |
| Operating weight | 44,000 lb19,958 kg | 33,235 lb15,075 kg | 56,320 lb25,546 kg |
| Weight per hp | 110 lb/hp67 kg/kW | 82 lb/hp50 kg/kW | 138 lb/hp84 kg/kW |
| Displacement | 855 ci14.01 L | 599 ci9.82 L | 826.9 ci13.55 L |
| Cylinders | 6 | 7 | 6 |
| Transmission | Full power shift | Selective gear fixed ratio with full range operator-controlled power shift | Selective gear fixed ratio with full range operator-controlled power shift |
Calculators
Calculators for the Quadtrac 9380QT
PTO power
About 332 to 360 PTO hp
Estimated from the 400 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 400 hp tractor can run
Maximum size is about a 47.5 ft rotary cutter or a 40.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
128 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
400 hp is 298.3 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the CaseIH Quadtrac 9380QT
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Cummins N14Amazon
Fits the Cummins N14 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Cummins N14Amazon
Fits the Cummins N14 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Cummins N14Amazon
Fits the Cummins N14 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Cummins N14Amazon
Fits the Cummins N14 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- CaseIH Quadtrac 9380QT service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- CaseIH Quadtrac 9380QT operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- CaseIH Quadtrac 9380QT service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Quadtrac 9380QT vs. Articulated median
CaseIH Quadtrac 9380QT compared with other Articulated tractors
| Spec | This model | Articulated median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 400 hp | 450 hp | -11% | 33rd |
| Engine Displacement | 855 ci | 827 ci | +3% | 55th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 12 | 16 | -25% | 11th |
| Operating Weight | 44,000 lb | 51,335 lb | -14% | 32nd |
| Width | 120 in | 100 in | +20% | 72nd |
Medians and percentiles are calculated from the articulated tractors in the database that have a recorded value for each specification (sample size 41–62 models).
Same manufacturer
Other CaseIH models
Other manufacturers
Models with similar horsepower
Gallery
CaseIH Quadtrac 9380QT photos


FAQ
Frequently asked questions
How much horsepower does the CaseIH Quadtrac 9380QT have?
The CaseIH Quadtrac 9380QT produces 400 hp from its 6-cylinder engine. Engine displacement is 855 ci.
How much does the CaseIH Quadtrac 9380QT weigh?
The CaseIH Quadtrac 9380QT weighs about 44,000 lb in operating condition.
What transmission is in the CaseIH Quadtrac 9380QT?
Transmission on the CaseIH Quadtrac 9380QT is Full power shift, with 12 forward speeds.
What type of hydraulic system does the CaseIH Quadtrac 9380QT use?
Hydraulics on the CaseIH Quadtrac 9380QT are Closed center.
What maintenance does the CaseIH Quadtrac 9380QT require?
The CaseIH Quadtrac 9380QT needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
