CaseIH Quadtrac Steiger 530QT
The CaseIH Quadtrac Steiger 530QT is a powerful tractor built for big jobs. It has a strong Cummins QSX15 engine with 6 cylinders and 535 horsepower. This engine is turbocharged and diesel-powered, giving it lots of strength for tough farm work. The tractor has a full powershift transmission with 16 forward gears and 2 reverse gears, making it easy to change speeds. This tractor is very heavy, weighing 52,410 pounds. It uses hydrostatic power steering, which helps the driver control it easily. The engine has 24 valves and is cooled by liquid to keep it running smoothly. It starts with a 24-volt electric starter. The Quadtrac Steiger 530QT also has special features like dual paper elements in its air cleaner and a high engine compression ratio of 17:1. These features help the tractor work better and last longer.
ManufacturerCaseIHPower535 hpEngine6-cylTransFull powershift
Quick specs
- Category
- Articulated
- Engine Power Output
- 535hp
- Operating Weight
- 52,410 lb
- Transmission
- Full powershift
At a glance
How the Quadtrac Steiger 530QT compares
vs. Articulated medianDistribution
Engine Power (hp)
Across all Articulated tractors
535 hp · 81st
This model
180
Median 450 hp
541
This modelArticulated tractorsMediann = 62
The Quadtrac Steiger 530QT ranks at the 81st percentile for engine power among recorded articulated tractors.
Overview
About the CaseIH Quadtrac Steiger 530QT
The CaseIH Quadtrac Steiger 530QT is a powerful tractor built for big jobs. It has a strong Cummins QSX15 engine with 6 cylinders and 535 horsepower. This engine is turbocharged and diesel-powered, giving it lots of strength for tough farm work. The tractor has a full powershift transmission with 16 forward gears and 2 reverse gears, making it easy to change speeds. This tractor is very heavy, weighing 52,410 pounds. It uses hydrostatic power steering, which helps the driver control it easily. The engine has 24 valves and is cooled by liquid to keep it running smoothly. It starts with a 24-volt electric starter. The Quadtrac Steiger 530QT also has special features like dual paper elements in its air cleaner and a high engine compression ratio of 17:1. These features help the tractor work better and last longer.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | Quadtrac Steiger 530QT |
| Category | Articulated tractor |
| Operating weight | 52,410lb |
Engine
| Make | Cummins |
|---|---|
| Model | QSX15 |
| Power | 535hp |
| Cylinders | 6 |
| Displacement | 912ci |
| Bore | 5.39in |
| Stroke | 6.65in |
Transmission
| Type | Full powershift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 2 |
Chassis & drive
| Steering | Hydrostatic power |
|---|
Dimensions
| Operating weight | 52,410lb |
|---|
Head to head
Quadtrac Steiger 530QT vs. Articulated median
How the CaseIH Quadtrac Steiger 530QT compares to other Articulated tractors
| Spec | This model | Articulated median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 535 hp | 450 hp | +19% | 81st |
| Engine Displacement | 912 ci | 827 ci | +10% | 67th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 52,410 lb | 51,335 lb | +2% | 52nd |
Medians and percentiles are computed from the articulated tractors in our database with a recorded value for each spec (sample sizes 57–62 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH Steiger 535QT Quadtrac | 535 hp | 52,410 lb | — | Compare → |
| CaseIH Steiger 540 Quadtrac | 535 hp | 47,780 lb | — | Compare → |
| CaseIH Steiger 550 Quadtrac | 550 hp | 53,804 lb | — | Compare → |
| CaseIH Steiger 500 Quadtrac | 500 hp | 54,290 lb | — | Compare → |
| CaseIH STX500QT Quadtrac | 500 hp | 53,264 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Challenger MT865C | 533.87 hp | 43,125 lb | — | Compare → |
| Baldwin DM525 | 525 hp | — | — | Compare → |
| Baldwin DP525 | 525 hp | — | — | Compare → |
| Big Bud 525/20 | 525 hp | — | — | Compare → |
| Big Bud 525/50 | 525 hp | 52,000 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Similar spec
Similar specGallery
CaseIH Quadtrac Steiger 530QT photos
FAQ
Common questions
What is the engine power output of the CaseIH Quadtrac Steiger 530QT?
Rated engine output for the CaseIH Quadtrac Steiger 530QT is 535 hp, delivered by a 6-cylinder engine. The engine displaces 912 ci.
Which transmission does the CaseIH Quadtrac Steiger 530QT use?
The CaseIH Quadtrac Steiger 530QT is equipped with a Full powershift transmission with 16 forward gears.
What is the operating weight of the CaseIH Quadtrac Steiger 530QT?
In working trim, the CaseIH Quadtrac Steiger 530QT comes in at roughly 52,410 lb.
How do I maintain a CaseIH Quadtrac Steiger 530QT?
Routine service for the CaseIH Quadtrac Steiger 530QT covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
