CrawlerPerformance profile
CaseIH Steiger 500 Quadtrac
The CaseIH Steiger 500 Quadtrac is a powerful articulated crawler tractor built for heavy-duty farm work. It features a strong Iveco engine with 6 cylinders and 500 horsepower, making it capable of handling tough jobs. The engine is diesel-powered and uses a turbocharger to boost performance. It meets Interim Tier 4 emissions standards, using a special system called selective catalytic reduction to reduce pollution. This tractor has a full power shift transmission with 16 forward gears and 2 reverse gears, giving the driver lots of control. It weighs 54,290 pounds, which is about average for its class. The Steiger 500 Quadtrac has a closed center hydraulic system and electro-hydraulic wet disc brakes for reliable operation. It also has a category 4N rear hitch for attaching large implements. With its crawler tracks and articulated design, this tractor can handle various terrains and provide excellent traction in the field.
ManufacturerCaseIHPower500 hpEngine6-cylTransFull power shift
Quick specs
- Category
- Crawler
- Engine Power Output
- 500hp
- Operating Weight
- 54,290 lb
- Transmission
- Full power shift
At a glance
How the Steiger 500 Quadtrac compares
vs. Crawler medianDistribution
Engine Power (hp)
Across all Crawler tractors
500 hp · 87th
This model
18
Median 200 hp
508
This modelCrawler tractorsMediann = 142
The Steiger 500 Quadtrac ranks at the 87th percentile for engine power among recorded crawler tractors.
Overview
About the CaseIH Steiger 500 Quadtrac
The CaseIH Steiger 500 Quadtrac is a powerful articulated crawler tractor built for heavy-duty farm work. It features a strong Iveco engine with 6 cylinders and 500 horsepower, making it capable of handling tough jobs. The engine is diesel-powered and uses a turbocharger to boost performance. It meets Interim Tier 4 emissions standards, using a special system called selective catalytic reduction to reduce pollution. This tractor has a full power shift transmission with 16 forward gears and 2 reverse gears, giving the driver lots of control. It weighs 54,290 pounds, which is about average for its class. The Steiger 500 Quadtrac has a closed center hydraulic system and electro-hydraulic wet disc brakes for reliable operation. It also has a category 4N rear hitch for attaching large implements. With its crawler tracks and articulated design, this tractor can handle various terrains and provide excellent traction in the field.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | Steiger 500 Quadtrac |
| Category | Crawler tractor |
| Type | Articulated crawler |
| Operating weight | 54,290lb |
Engine
| Make | Iveco |
|---|---|
| Power | 500hp |
| Cylinders | 6 |
| Displacement | 787ci |
| Bore | 5.32in |
| Stroke | 5.91in |
Transmission
| Type | Full power shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | Articulated crawler |
|---|---|
| Brakes | Electro-hydraulic wet discs |
Hydraulics
| Type | Closed center pressure flow compensated (PFC) |
|---|
Dimensions
| Operating weight | 54,290lb |
|---|
Head to head
Steiger 500 Quadtrac vs. Crawler median
How the CaseIH Steiger 500 Quadtrac compares to other Crawler tractors
| Spec | This model | Crawler median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 500 hp | 200 hp | +150% | 87th |
| Engine Displacement | 787 ci | 468 ci | +68% | 81st |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 16 | 10 | +60% | 69th |
| Operating Weight | 54,290 lb | 23,320 lb | +133% | 94th |
Medians and percentiles are computed from the crawler tractors in our database with a recorded value for each spec (sample sizes 142–192 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH STX500QT Quadtrac | 500 hp | 53,264 lb | — | Compare → |
| CaseIH STX480QT Quadtrac | 480 hp | 54,000 lb | — | Compare → |
| CaseIH Quadtrac Steiger 530QT | 535 hp | 52,410 lb | — | Compare → |
| CaseIH Steiger 535QT Quadtrac | 535 hp | 52,410 lb | — | Compare → |
| CaseIH Steiger 540 Quadtrac | 535 hp | 47,780 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Big Bud 500 | 500 hp | — | — | Compare → |
| Challenger MT851 | 504.2 hp | 42,000 lb | — | Compare → |
| Challenger 1050 | 485 hp | 31,615 lb | 2017+ | Compare → |
| Challenger MT865E | 521.27 hp | 44,550 lb | — | Compare → |
| Challenger MT865 | 523.6 hp | 44,220 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH Steiger 500 Quadtrac photos
FAQ
Common questions
How much horsepower does the CaseIH Steiger 500 Quadtrac have?
The CaseIH Steiger 500 Quadtrac produces 500 hp from its 6-cylinder engine. Engine displacement is 787 ci.
What transmission is in the CaseIH Steiger 500 Quadtrac?
Transmission on the CaseIH Steiger 500 Quadtrac is Full power shift, with 16 forward speeds.
What type of hydraulic system does the CaseIH Steiger 500 Quadtrac use?
Hydraulics on the CaseIH Steiger 500 Quadtrac are Closed center pressure flow compensated (PFC).
What hitch category is the CaseIH Steiger 500 Quadtrac?
The CaseIH Steiger 500 Quadtrac uses a Category 4N hitch.
How much does the CaseIH Steiger 500 Quadtrac weigh?
The CaseIH Steiger 500 Quadtrac weighs about 54,290 lb in operating condition.
What maintenance does the CaseIH Steiger 500 Quadtrac require?
Like any tractor, the CaseIH Steiger 500 Quadtrac needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
