Challenger 85C
The Challenger 85C is a powerful tractor built for tough farm work. It has a strong Caterpillar engine that can produce 355 horsepower. This engine has 6 cylinders and runs on diesel fuel. It's turbocharged and intercooled, which helps it work better. The tractor has a full power shift transmission with 10 forward gears and 2 reverse gears. This makes it easy to change speeds for different jobs. The Challenger 85C is big and heavy, weighing 33,645 pounds. It's 232 inches long, 120 inches wide, and 128 inches tall. The tractor has a closed center hydraulic system and an electric starter to help it run smoothly. Challenger is known for making strong tractors for farms. This model, the 85C, is designed to handle big tasks on large farms. Its size and power make it a good choice for farmers who need to work on big fields or pull heavy equipment.

Key specifications
- Category
- Crawler
- Engine power
- 355hp
- Operating weight
- 33,645 lb
- Transmission
- Full power shift
Category comparison
85C compared with its category
vs. Crawler medianDistribution
Engine Power (hp)
All recorded Crawler tractors
This model
The 85C ranks at the 72nd percentile for engine power among recorded crawler tractors.
Overview
About the Challenger 85C
The Challenger 85C is a powerful tractor built for tough farm work. It has a strong Caterpillar engine that can produce 355 horsepower. This engine has 6 cylinders and runs on diesel fuel. It's turbocharged and intercooled, which helps it work better. The tractor has a full power shift transmission with 10 forward gears and 2 reverse gears. This makes it easy to change speeds for different jobs. The Challenger 85C is big and heavy, weighing 33,645 pounds. It's 232 inches long, 120 inches wide, and 128 inches tall. The tractor has a closed center hydraulic system and an electric starter to help it run smoothly. Challenger is known for making strong tractors for farms. This model, the 85C, is designed to handle big tasks on large farms. Its size and power make it a good choice for farmers who need to work on big fields or pull heavy equipment.
Full specifications
Recorded specifications
General
| Manufacturer | Challenger |
|---|---|
| Model | 85C |
| Category | Crawler tractor |
| Operating weight | 33,645lb(15,260 kg) |
Engine
| Make | Caterpillar |
|---|---|
| Model | 3176 ATAAC |
| Power | 355hp(264.7 kW) |
| Cylinders | 6 |
| Displacement | 629ci(10.31 L) |
| Bore | 4.92in(125 mm) |
| Stroke | 5.51in(140 mm) |
Transmission
| Type | Full power shift |
|---|---|
| Forward gears | 10 |
| Reverse gears | 2 |
Hydraulics
| Type | Closed center |
|---|
Dimensions
| Length | 232in(5,893 mm) |
|---|---|
| Width | 120in(3,048 mm) |
| Height | 128in(3,251 mm) |
| Operating weight | 33,645lb(15,260 kg) |
Capacities
| Cooling system | 20gal(75.71 L) |
|---|
Closest alternatives
85C compared with the nearest models by horsepower
The closest crawler models to the Challenger 85C by rated horsepower are the John Deere 8370RT and the John Deere 9400T. The John Deere 8370RT is rated 4.5 hp higher. The John Deere 9400T makes 8.5 hp less and weighs 8,980 lb more, so it carries more weight per horsepower, which helps traction in draft work.
| Spec | Challenger 85C | John Deere 8370RT | John Deere 9400T |
|---|---|---|---|
| Engine power | 355 hp264.7 kW | 359.5 hp268.1 kW | 346.5 hp258.4 kW |
| Operating weight | 33,645 lb15,261 kg | - | 42,620 lb19,332 kg |
| Weight per hp | 95 lb/hp58 kg/kW | - | 123 lb/hp75 kg/kW |
| Displacement | 629 ci10.31 L | 548 ci8.98 L | 765 ci12.54 L |
| Cylinders | 6 | 6 | 6 |
| Transmission | Full power shift | Selective gear fixed ratio with full range operator-controlled power shift (e23 Transmission) | Partial power shift |
| Drive | - | 4WD | Track |
Calculators
Calculators for the 85C
PTO power
About 295 to 320 PTO hp
Estimated from the 355 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 355 hp tractor can run
Maximum size is about a 42 ft rotary cutter or a 36 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
110 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
355 hp is 264.7 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the Challenger 85C
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Caterpillar 3176 ATAACAmazon
Fits the Caterpillar 3176 ATAAC 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Caterpillar 3176 ATAACAmazon
Fits the Caterpillar 3176 ATAAC 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Caterpillar 3176 ATAACAmazon
Fits the Caterpillar 3176 ATAAC 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Caterpillar 3176 ATAACAmazon
Fits the Caterpillar 3176 ATAAC 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Challenger 85C service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Challenger 85C operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Challenger 85C service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
85C vs. Crawler median
Challenger 85C compared with other Crawler tractors
| Spec | This model | Crawler median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 355 hp | 200 hp | +78% | 72nd |
| Engine Displacement | 629 ci | 468 ci | +34% | 67th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 10 | 10 | at median | 50th |
| Operating Weight | 33,645 lb | 23,320 lb | +44% | 70th |
| Length | 232 in | 146 in | +59% | 83rd |
| Width | 120 in | 79.5 in | +51% | 88th |
| Height | 128 in | 90.6 in | +41% | 78th |
Medians and percentiles are calculated from the crawler tractors in the database that have a recorded value for each specification (sample size 134–192 models).
Same manufacturer
Other Challenger models
Other manufacturers
Models with similar horsepower
Gallery
Challenger 85C photos





FAQ
Frequently asked questions
What is the engine power output of the Challenger 85C?
Rated engine output for the Challenger 85C is 355 hp, delivered by a 6-cylinder engine. The engine displaces 629 ci.
Which transmission does the Challenger 85C use?
The Challenger 85C is equipped with a Full power shift transmission with 10 forward gears.
What hydraulics does the Challenger 85C have?
The Challenger 85C uses a Closed center hydraulic system.
What is the operating weight of the Challenger 85C?
The Challenger 85C has an operating weight of about 33,645 lb.
How do I maintain a Challenger 85C?
Routine service for the Challenger 85C covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
