Claas Challenger 45
The Claas Challenger 45 is a powerful crawler tractor built for tough farm work. It has a strong Caterpillar engine with 240 horsepower, which is above average for tractors. This engine has 6 cylinders and uses diesel fuel. The tractor is big and heavy, weighing 22,700 pounds, which helps it grip the ground well. This tractor is special because it moves on tracks instead of wheels. It comes with different track options, either 18 inches or 16 inches wide. The tracks can be set at various widths to fit different farm needs. The Challenger 45 has a comfortable cab for the driver and a three-point hitch at the back for attaching tools. It also has a smart hydraulic system that adjusts to the work being done. With its 16-speed transmission, this tractor can handle many different jobs on the farm.

Key specifications
- Category
- Crawler
- Engine power
- 240hp
- Operating weight
- 22,700 lb
- Transmission
- 16-speed full power shift
Category comparison
Challenger 45 compared with its category
vs. Crawler medianDistribution
Engine Power (hp)
All recorded Crawler tractors
This model
The Challenger 45 ranks at the 56th percentile for engine power among recorded crawler tractors.
Overview
About the Claas Challenger 45
The Claas Challenger 45 is a powerful crawler tractor built for tough farm work. It has a strong Caterpillar engine with 240 horsepower, which is above average for tractors. This engine has 6 cylinders and uses diesel fuel. The tractor is big and heavy, weighing 22,700 pounds, which helps it grip the ground well. This tractor is special because it moves on tracks instead of wheels. It comes with different track options, either 18 inches or 16 inches wide. The tracks can be set at various widths to fit different farm needs. The Challenger 45 has a comfortable cab for the driver and a three-point hitch at the back for attaching tools. It also has a smart hydraulic system that adjusts to the work being done. With its 16-speed transmission, this tractor can handle many different jobs on the farm.
Full specifications
Recorded specifications
General
| Manufacturer | Claas |
|---|---|
| Model | Challenger 45 |
| Category | Crawler tractor |
| Type | Crawler |
| Operating weight | 22,700lb(10,300 kg) |
Engine
| Make | Caterpillar |
|---|---|
| Model | 3116 |
| Power | 240hp(179 kW) |
| Cylinders | 6 |
| Displacement | 403ci(6.6 L) |
| Bore | 4.13in(104.9 mm) |
| Stroke | 5in(127 mm) |
Transmission
| Type | 16-speed full power shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 9 |
Chassis & drive
| Chassis | Crawler |
|---|---|
| Steering | Differential power |
| Cab | Cab |
Hydraulics
| Type | Variable-displacement load-sensing pressure-compensated |
|---|
Dimensions
| Length | 211in(5,359 mm) |
|---|---|
| Width | 91in(2,311 mm) |
| Height | 125in(3,175 mm) |
| Operating weight | 22,700lb(10,300 kg) |
Capacities
| Cooling system | 8.6gal(32.55 L) |
|---|
Closest alternatives
Challenger 45 compared with the nearest models by horsepower
The closest crawler models to the Claas Challenger 45 by rated horsepower are the Caterpillar AG6 and the Challenger MT575E. The Caterpillar AG6 matches it on rated power and weighs 9,900 lb more, at 136 lb per horsepower against 95 lb. The Challenger MT575E matches it on rated power.
| Spec | Claas Challenger 45 | Caterpillar AG6 | Challenger MT575E |
|---|---|---|---|
| Engine power | 240 hp179 kW | 240 hp179 kW | 240 hp179 kW |
| Operating weight | 22,700 lb10,297 kg | 32,600 lb14,787 kg | - |
| Weight per hp | 95 lb/hp58 kg/kW | 136 lb/hp83 kg/kW | - |
| Displacement | 403 ci6.6 L | 638 ci10.45 L | 449 ci7.36 L |
| Cylinders | 6 | 6 | 6 |
| Transmission | 16-speed full power shift | Sliding Gear | CVT |
Calculators
Calculators for the Challenger 45
PTO power
About 199 to 216 PTO hp
Estimated from the 240 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 240 hp tractor can run
Maximum size is about a 28.5 ft rotary cutter or a 24.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
110 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
240 hp is 179.0 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the Claas Challenger 45
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Caterpillar 3116Amazon
Fits the Caterpillar 3116 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Caterpillar 3116Amazon
Fits the Caterpillar 3116 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Caterpillar 3116Amazon
Fits the Caterpillar 3116 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Caterpillar 3116Amazon
Fits the Caterpillar 3116 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Claas Challenger 45 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Claas Challenger 45 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Claas Challenger 45 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Challenger 45 vs. Crawler median
Claas Challenger 45 compared with other Crawler tractors
| Spec | This model | Crawler median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 240 hp | 200 hp | +20% | 56th |
| Engine Displacement | 403 ci | 468 ci | -14% | 45th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 16 | 10 | +60% | 69th |
| Operating Weight | 22,700 lb | 23,320 lb | -3% | 49th |
| Length | 211 in | 146 in | +45% | 77th |
| Width | 91 in | 79.5 in | +14% | 55th |
| Height | 125 in | 90.6 in | +38% | 76th |
Medians and percentiles are calculated from the crawler tractors in the database that have a recorded value for each specification (sample size 134–192 models).
Same manufacturer
Other Claas models
Other manufacturers
Models with similar horsepower
Gallery
Claas Challenger 45 photos





FAQ
Frequently asked questions
How much horsepower does the Claas Challenger 45 have?
The Claas Challenger 45 produces 240 hp from its 6-cylinder engine. Engine displacement is 403 ci.
How much does the Claas Challenger 45 weigh?
The Claas Challenger 45 weighs about 22,700 lb in operating condition.
What transmission is in the Claas Challenger 45?
Transmission on the Claas Challenger 45 is 16-speed full power shift, with 16 forward speeds.
What hydraulics does the Claas Challenger 45 have?
The Claas Challenger 45 uses a Variable-displacement load-sensing pressure-compensated hydraulic system.
What three-point hitch category does the Claas Challenger 45 use?
The Claas Challenger 45 has a Category III/II three-point hitch.
What maintenance does the Claas Challenger 45 require?
The Claas Challenger 45 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
